Presentation Transcript

  1. KAVITSU LEADING GEARBOX MANUFACTURING

  2. ABOUT US • Welcome to KAVITSU • KAVITSU - Aiming to be a Global Leader in Gear & Slew Bearing Technology. In 1992 Kavitsu Techniques an entrepreneurship was established by Mr. Vasant Phadtare, which was converted in Private Limited Company namely Kavitsu Transmissions Pvt. Ltd. since last 30 years, Kavitsu is manufacturing Industrial Transmissions. Pioneering the range of Planetary Gearboxes is very wide.

  3. One of the pioneers of Planetary Gear Technology in India. • The company is engaged in manufacturing and supply of Bevel Gear Boxes. • Planetary Gear Boxes, Worm Gear Boxes, Mechanical Power Transmission Systems, Planetary Speed Reducers, Industrial Gear Boxes, Planetary Winches, as well as Geared motors, Electric Motors and Slew Bearings. • It offers a wide range of gearboxes handling the power inputs up to 1250 kW. The speed reduction ratios are up to 100,000:1. The weights of the gear boxes range from 150 gms to 43,000 Kg (single gear box weight). • The sectors served by the company are Steel, Chemical, Textile, Printing & packaging, Mining & earth moving , Wind mills, Machine tools etc.

  4. PLANETARY GEARBOXES • Planetary Gearboxes: • consists of three major components: • Sun gear • Planet gear • Ring gear The sun gear is meshed around with the planet gears, which in turn are meshed with ring gear. Planet gears are connected to each other by a carrier, which helps them to rotate around the sun gear

  5. Advantages of Planetary system over helical gearbox: • They are compact and take less space and are light weight, as the load is shared between the planet gears. • The noise and vibration is reduced as the load is shared. This also increases efficiency • Since the shafts are inline and concentric, bending moment is absent. • The manufacturing of these components is relatively cheaper due to smaller size as compared to parallel axis gearboxes.

  6. Disadvantages: • The gear system is complex and needs precision manufacturing • Teeth ratios are specific and assemble is according to them. • Calculations of efficiency are a bit difficult.

  7. Application examples for planetary gears • Back gauge drive for press brakes. Press brakes are used for bending sheet metal. • IML robot. In the in-mould labelling process (IML), pre-cut plastic films are inserted into an injection mould using a handling device. • Axis drive for laser cutting machines.

  8. Reaching our officefind our location Visit our office Email us Call us Kavitsu Transmissions Pvt. Ltd.W-85, additional MIDC Satara 415004 Maharashtra, India marketing@kavitsu.com +91 9096469696
