Presentation Transcript
Programming logic and design fifth edition comprehensive l.jpg

Programming Logic and DesignFifth Edition, Comprehensive

Chapter 2

Understanding Structure


Objectives l.jpg
Objectives

  • Learn about the features of unstructured spaghetti code

  • Understand the three basic structures: sequence, selection, and loop

  • Use a priming read

  • Appreciate the need for structure

  • Recognize structure

  • Learn about three special structures: case, do-while, and do-until

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding unstructured spaghetti code l.jpg
Understanding Unstructured Spaghetti Code

  • Spaghetticode: logically snarled program statements

    • Can be the result of poor program design

  • Spaghetti code programs often work, but are difficult to read and maintain

  • Convoluted logic usually requires more code

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding unstructured spaghetti code continued l.jpg
Understanding Unstructured Spaghetti Code (continued)

  • Example: College Admissions

    • Admit students who score >= 90 on admissions test if upper 75 percent of high-school graduating class

    • Admit students who score >= 80 on test if upper 50 percent of high-school graduating class

    • Admit students who score >= 70 on admission test if upper 25 percent of high-school graduating class

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding unstructured spaghetti code continued5 l.jpg
Understanding Unstructured Spaghetti Code (continued)

Figure 2-2 Spaghetti code example

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures l.jpg
Understanding the Three Basic Structures

  • Structure: basic unit of programming logic

  • Any program can be constructed from only three basic types of structures

    • Sequence

      • Perform actions in order

      • No branching or skipping any task

    • Selection (decision)

      • Ask a question, take one of two actions

      • Dual-alternative or single-alternative

    • Loop

      • Repeat actions based on answer to a question

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued l.jpg
Understanding the Three Basic Structures (continued)

  • Sequence structure

Figure 2-3 Sequence structure

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued8 l.jpg
Understanding the Three Basic Structures (continued)

  • Selection structure

Figure 2-4 Selection structure

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued9 l.jpg
Understanding the Three Basic Structures (continued)

  • Dual-alternative if: contains two alternatives

if someCondition is true then

do oneProcess

else

do theOtherProcess

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued10 l.jpg
Understanding the Three Basic Structures (continued)

  • Single-alternative if: contains one alternative

Figure 2-5 Single-alternative selection structure

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued11 l.jpg
Understanding the Three Basic Structures (continued)

  • Single-alternative if

  • Else clause is not required

  • Null case: situation where nothing is done

if employee belongs to dentalPlan then

deduct $40 from employeeGrossPay

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued12 l.jpg
Understanding the Three Basic Structures (continued)

  • Loop structure

    • Repeats a set of actions based on the answer to a question

    • Also called repetition or iteration

    • Question is asked first in the most common form of loop

Figure 2-6 Loop structure

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued13 l.jpg
Understanding the Three Basic Structures (continued)

  • Loop structure

while testCondition continues to be true

do someProcess

while quantityInInventory remains low

continue to orderItems

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued14 l.jpg
Understanding the Three Basic Structures (continued)

  • All logic problems can be solved using only these three structures

  • Structures can be combined in an infinite number of ways

  • Stacking: attaching structures end-to-end

  • End-structure statements: indicate the end of a structure

    • Theendifstatement ends an if-then-else structure

    • Theendwhile ends a loop structure

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued15 l.jpg
Understanding the Three Basic Structures (continued)

Figure 2-7 Structured flowchart and pseudocode

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued16 l.jpg
Understanding the Three Basic Structures (continued)

  • Any individual task or step in a structure can be replaced by a structure

  • Nesting: placing one structure within another

  • Indent the nested structure’s statements

  • Block: group of statements that execute as a single unit

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued17 l.jpg
Understanding the Three Basic Structures (continued)

Figure 2-8 Flowchart and pseudocode showing a sequence nested within a selection

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued18 l.jpg
Understanding the Three Basic Structures (continued)

Figure 2-9 Selection in a sequence within a selection

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued19 l.jpg
Understanding the Three Basic Structures (continued)

Figure 2-10 Flowchart and pseudocode for loop within selection within sequence within selection

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the three basic structures continued20 l.jpg
Understanding the Three Basic Structures (continued)

  • Each structure has one entry and one exit point

  • Structures attach to others only at entry or exit points

Figure 2-11 The three structures

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read l.jpg
Using the Priming Read

  • Priming read (or priming input):

    • Reads the first input data record

    • Outside the loop that reads the rest of the records

    • Helps keep the program structured

  • Analyze a flowchart for structure one step at a time

  • Watch for unstructured loops that do not follow this order:

    • First ask a question

    • Take action based on the answer

    • Return to ask the question again

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued l.jpg
Using the Priming Read (continued)

  • Unstructured loop

Figure 2-12 Unstructured flowchart of a number-doubling program

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued23 l.jpg
Using the Priming Read (continued)

  • Structured but nonfunctional loop

Figure 2-15 Structured, but nonfunctional, flowchart of number-doubling problem

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued24 l.jpg
Using the Priming Read (continued)

  • Functional but nonstructured loop

Figure 2-16 Functional, but nonstructured, flowchart

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued25 l.jpg
Using the Priming Read (continued)

  • Functional and structured loop

Figure 2-17 Functional, structured flowchart and pseudocode for the number-doubling problem

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued26 l.jpg
Using the Priming Read (continued)

  • Priming read sets up the process so the loop can be structured

  • To analyze a flowchart’s structure, try writing pseudocode for it

start

get inputNumber

while not eof

calculatedAnswer = inputNumber * 2

print calculatedAnswer

get inputNumber

endwhile

stop

Programming Logic and Design, Fifth Edition, Comprehensive


Using the priming read continued27 l.jpg
Using the Priming Read (continued)

  • What is wrong with this design?

Figure 2-18 Structured but incorrect solution to the number-doubling problem

Programming Logic and Design, Fifth Edition, Comprehensive


Understanding the reasons for structure l.jpg
Understanding the Reasons for Structure

  • Provides clarity

  • Professionalism

  • Efficiency

  • Ease of maintenance

  • Supports modularity

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure l.jpg
Recognizing Structure

  • Any set of instructions can be expressed in structured format

  • Any task to which you can apply rules can be expressed logically using sequence, selection, loop

  • It can be difficult to detect whether a flowchart is structured

Programming Logic and Design, Fifth Edition, Comprehensive


Slide30 l.jpg

Recognizing Structure (continued)

  • Is this flowchart structured?

Figure 2-22 Example 2

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued l.jpg
Recognizing Structure (continued)

  • Is this flowchart structured?

Figure 2-23 Example 3

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued32 l.jpg
Recognizing Structure (continued)

  • Single process like A is part of an unacceptable structure

    • At least the beginning of a sequence structure

Figure 2-24 Untangling Example 3, first step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued33 l.jpg
Recognizing Structure (continued)

  • B begins a selection structure

    • Sequences never have decisions in them

    • Logic never returns to B

Figure 2-25 Untangling Example 3, second step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued34 l.jpg
Recognizing Structure (continued)

  • Pull up on the flowline from the left side of B

Figure 2-26 Untangling Example 3, third step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued35 l.jpg
Recognizing Structure (continued)

  • Next, pull up the flowline on the right side of B

Figure 2-27 Untangling Example 3, fourth step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued36 l.jpg
Recognizing Structure (continued)

  • Pull up the flowline on the left side of D and untangle it from the B selection by repeating C

Figure 2-28 Untangling Example 3, fifth step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued37 l.jpg
Recognizing Structure (continued)

  • Now pull up the flowline on the right side of D

Figure 2-29 Untangling Example 3, sixth step

Programming Logic and Design, Fifth Edition, Comprehensive


Recognizing structure continued38 l.jpg
Recognizing Structure (continued)

  • Bring together the loose ends of D and of B

Figure 2-30 Finished flowchart and pseudocode for untangling Example 3

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until l.jpg
Three Special Structures – CASE, DO-WHILE, and DO-UNTIL

  • Many languages allow three additional structures:

    • Thecase structure

    • The do-while structure

    • The do-until structure

  • CASE Structure:

    • Decisions with more than two alternatives

    • Tests a variable against a series of values and takes action based on a match

    • Nested if-then-else statements will do what a case structure does

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • Using nested if-then-else for multiple alternatives

Figure 2-31 Flowchart and pseudocode of tuition decisions

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued41 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • Using a case structure for multiple alternatives

Figure 2-32 Flowchart and pseudocode of case structure

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued42 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • do-while and do-until loops

    • Question is asked at the end of the loop structure

    • Loop statements always used at least once

Figure 2-33 The while loop, which is a pretest loop

Figure 2-34 Structure of a do-while or do-until loop, which are posttest loops

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued43 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • do-while: executes as long as the question’s answer is Yes or True

  • do-until: executes as long as the question’s answer is No or False

do

wash a dish

until all dishes are washed

do

wash a dish

while more dishes remain to be washed

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued44 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • while loop with question at beginning is called a pretest loop

  • do-while and do-until with question at end are called posttest loops

    • Posttest loop can be replaced with a sequence followed by a pretest while loop

pay a bill

while there are more bills to pay

pay a bill

endwhile

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued45 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

Figure 2-35 Flowchart and pseudocode for do-while loop

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued46 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

Figure 2-36 Flowchart and pseudocode for sequence followed by while loop

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued47 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • How can this design be made structured?

Figure 2-37 Unstructured loop

Programming Logic and Design, Fifth Edition, Comprehensive


Three special structures case do while and do until continued48 l.jpg
Three Special Structures – Case, DoWhile, and DoUntil (continued)

  • Repeat the needed step to enforce structure

Figure 2-38 Sequence and structured loop that accomplish the same tasks as Figure 2-37

Programming Logic and Design, Fifth Edition, Comprehensive


Summary l.jpg
Summary

  • Spaghetti code: snarled program logic

  • Three basic structures: sequence, selection, loop

    • Combined by stacking and nesting

  • Priming read: statement that reads the first input data record

  • Structured techniques promote clarity, professionalism, efficiency, and modularity

  • Flowchart can be made structured by untangling

Programming Logic and Design, Fifth Edition, Comprehensive


Summary continued l.jpg
Summary (continued)

  • case structure: questions with multiple alternatives

  • while loop: a pretest loop asks the question first

  • while loop statements never execute if the answer is No

  • do-while and do-until loops: posttest loops that ask the question last

  • do-while and do-until loop statements are always executed at least once

    • Posttest loop can be replaced by a sequence followed by a while loop

Programming Logic and Design, Fifth Edition, Comprehensive


ad
