From Ink-Jet Technology to Nano Array Writing Technology By Szu-kang Hsien Ayodeji Coker OVERVIEW Objective. Approach. Our Nano Array Writing Device. Conclusion. Acknowledgements. OBJECTIVE The use of nano-technology and microfabrication techniques for nano array writing.

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'From Ink-Jet Technology to Nano Array Writing Technology' - Anita


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
overview
OVERVIEW
  • Objective.
  • Approach.
  • Our Nano Array Writing Device.
  • Conclusion.
  • Acknowledgements.
objective
OBJECTIVE
  • The use of nano-technology and microfabrication techniques for nano array writing.
  • Replacing conventional lithography methods with nano array writing capable of producing 30nm line widths.
  • The independent control of each AFM tip used in the nano-array writing technology using comb-drive actuators.
approach
APPROACH
  • Using the concept employed in Dip Pen Nanolithography (DPN) for nano array writing.
  • Using ink-jet technology as a mode of delivering ink to an AFM tip capable of writing line widths on the order of nano-meters.
  • Motion control in the x-y-z plane is done using comb-drive and electrostatic actuators.
ink jet technology
INK JET TECHNOLOGY
  • Drop On Demand (DOD) ink-jet printing is to be utilized in our device.
  • A high voltage is to be applied to a PZT crystal causing it to bend. This effect in turn applies a pressure on the ink reservoir.
  • As a result of the applied pressure, the reservoir jets out ink on demand, in our case to coat the AFM tip.
ink jet technology7
INK JET TECHNOLOGY
  • A change in voltage gives rise to a corresponding change in force and the resulting dimensional change in length.
  • V=dijFjx/(orA)
  • F will be 0.11 N using PZT film dimension 100m*100m, er=3000, d11=370 pC/N, d31=110 pC/N, V=10V and x = 2m.
  • The displacement of the crystal, L= LV/(td31), will be around 0.2m.
  • So we can stack around 5 PZT crystals together in order to have 1m pressing into the ink
dip pen nanolithography dpn
DIP-PEN NANOLITHOGRAPHY (DPN)
  • Old technique of dip pen writing.
  • In place of the nib used in the regular dip-pen, an AFM tip is employed.
  • Using ink-jet technology, “ink” is transported to the AFM tip, which it coats.
  • The ink is delivered to the substrate, by choosing an “ink” and substrate that have an affinity for one another e.g ODT and Au.
atomic force microscope afm
ATOMIC FORCE MICROSCOPE (AFM)
  • AFM relies on a scanning technique to to produce very high resolution 3-D images of sample surfaces.
  • There are three methods used in AFM applications. They are the contact mode, the intermittent contact mode and the non contact imaging.
  • The method employed NAWT is the intermittent contact mode method.
comb drive and electrostatic actuators
COMB DRIVE AND ELECTROSTATIC ACTUATORS
  • A large number of fine interdigiated fingers are actuated by applying a voltage between them.
  • This will provide the x-y motion for our device.
  • The z-motion is achieved by electrostatically actuating the cantilever on which the AFM is attached.
our nano array writing device
Our Nano Array Writing Device
  • Ink Jet Structure.
  • Scream Process for the fabrication of the comb drive actuators.
  • AFM tip fabrication.
  • 3-D image of our nano array writing device.
conclusion
Conclusion
  • Technology is feasible.
  • NAWT is a faster way of doing lithography.
  • Comb drive in Collaboration with electrostatic cantilever deflection is a good method of control in all 3 dimentions.
acknowledgements
Acknowledgements.
  • Prof. Horacio Espinosa for his guidance and advice.
  • Prof. Chad Mirkin for taking time to provide us with all the necessary information on DPN.
  • Zhu the TA for all the literature and help he gave us.
