1. DA TA MODELLING INTRODUCTION

2. THANK YOU

3. WHAT IS DATA MODELL ING

4. WHY DO WE NEED TO CREATE DATA MODELS? TO AID IN THE DEVELOPMENT OF A SOUND DATABASE DESIGN THAT DOES NOT ALLOW ANOMALIES OR INCONSISTENCIES GOAL: TO CREATE DATABASE TABLES THAT DO NOT CONTAIN DUPLICATE DATA VALUES THAT CAN BECOME INCONSISTENT

5. YPES OF DATA MODELS ENTITY-RELATIONSHIP (E-R) MODEL ONLY ADDRESSES DATA AND RELATIONSHIPS CLASSIC, SIMPLEST BEST FOR DERIVING A SOUND TABLE DESIGN MANY EXTENSIONS/VARIATIONS EXIST BASIS FOR MOST OTHER MODELING APPROACHES UML (UNIFIED MODELING LANGUAGE) CLASS MODELS GOES BEYOND DATA, ALSO MODELS BEHAVIORS

6. CREATING AN ENTITY-RELATIONSHIP MODEL IDENTIFY ENTITIES IDENTIFY ENTITY ATTRIBUTES AND PRIMARY KEYS SPECIFY RELATIONSHIPS

7. DATA ENTITIES ENTITY A "THING" ABOUT WHICH YOU WANT TO STORE DATA IN AN APPLICATION MULTIPLE EXAMPLES (INSTANCES) OF THE ENTITY MUST EXIST GOAL: STORE DATA ABOUT EACH ENTITY IN A SEPARATE TABLE DO NOT STORE DUPLICATE DATA IN MULTIPLE TABLES OR RECORDS EXAMPLES: CUSTOMER, PRODUCT www.yourwebsite.com

8. DATA ENTITY INSTANCES ENTITY INSTANCE A SPECIFIC OCCURRENCE (DATA VALUE) OF AN ENTITY AN ENTITY MUST HAVE MULTIPLE ENTITY INSTANCES OR IT IS NOT REALLY AN ENTITY! EXAMPLES: BOBBY BON BONS, CELESTIAL CASHEW CRUNCH
