carrier ethernet access technology shoot out copper pdh vs active fiber vs pon
Carrier Ethernet Access Technology Shoot-Out

Copper PDH vs. Active Fiber vs. PON

panelists

Panelists:

Ralph Santitoro

Chair, MEF Web Marketing Committee

Director of Carrier Ethernet Solutions

Ralph@Marcom-Services.net

Wolfgang Fischer

Senior Manager, Business Development wfischer@cisco.com

Dr. Michael Ritter

Vice President Business Management Ethernet Access

MRitter@advaoptical.com

Gerlinde Bedö

Head of Broadband Access Marketing

Gerlinde.bedoe@nsn.com

access shoot out introduction panel moderator

Access Shoot Out IntroductionPanel Moderator:

Greg Poggi

Vice President of Sales

gpoggi@omnitron-systems.com

carrier ethernet in the access metro global networks
Carrier Ethernet in the Access, Metro & Global Networks
  • Carrier Ethernet Services operate independently of the physical networks they run across making expansion to new technologies easy
  • Creates a single service connection from Enterprise or business office, in a single person office, or home or on the road.
  • In the Metro and First Mile, Ethernet is becoming the network of choice with migration from Frame Services
ethernet over different access network technologies
Ethernet over Different Access Network Technologies

WiFi /

WiMax

10/100BT

GigE

GBE

or 100FX

(Standard or WDM)

EoCopper

Service

Provider Network

(Hybrid of Ethernet and TDM)

EoPDH

10/100BT

PON

GBE

or 100FX

(Standard or WDM)

PON

HFC: Hybrid Fiber and Coax

Coax

10/100BT

carrier ethernet scope and reach
Carrier Ethernet Scope and Reach

Carrier Ethernet

Carrier Ethernet wire-line and mobile backhaul

with copper, fiber , cable, wireless access network delivery

Enterprise Clients

Small/Medium Business

SoHo & Residential Triple-Play

Mobile data/video

Internet information & Software apps

HD TV, TVoD, VoD, Content Providers

Host applications, Consolidated Servers

Voice/Video

Telephony

Gaming, DR, ERP

Video

Source

carrier ethernet in access networks
Carrier Ethernet in Access Networks
  • Active areas in Carrier Ethernet development
    • Ethernet Access for Mobile Backhaul
    • Ethernet over Active Fiber
    • Ethernet over Passive Fiber (PON)
    • Ethernet over Copper PDH (E1/DS1)
    • Ethernet over Copper DSL
    • Ethernet over Hybrid Fiber Coax (HFC)
converged ethernet ip services over copper pdh access networks

Converged Ethernet/IP Services over Copper PDH Access Networks

Ralph Santitoro

Chair, MEF Web Marketing Committee

Director of Carrier Ethernet Solutions

Ralph@Marcom-Services.net

delivering ubiquitous ethernet services the access network challenge
Delivering Ubiquitous Ethernet Services- The Access Network Challenge

Fiber

Fiber

Ethernet Service Provider

Fiber

Fiber

  • Ethernet over Fiber (EoF) access networks
    • The optimal technology for delivery of Ethernet services
  • Unfortunately, not all Enterprise sites have fiber access
    • However, they all have access to copper/PDH circuits

How does a service provider deliver Ethernet services to all Enterprise locations?

what is ethernet over pdh eopdh
What is Ethernet over PDH (EoPDH)?
  • Technology that enables delivery of Ethernet services over PDH (E1/DS1, E3/DS3) access networks
  • Service Bandwidth Granularity
    • N x 2Mbps (N bonded E1s), N x 1.5Mbps (N bonded DS1s)
    • N x 32Mbps (N bonded E3s), N x 45Mbps (N bonded DS3s)
    • Example: 5 bonded E1s provide a 10Mbps Ethernet service
  • Supports same MEF service attributes as EoF services
    • Ethernet UNI to subscriber
    • Granular bandwidth and QoS per service
    • Fault Management and Performance Management for SLAs

EoPDH enables a common Ethernet service offering and SLA over both copper and fiber access networks

PDH (Plesiochronous Digital Hierarchy): Term to collectively refer to E1/E3 and DS1/DS3 copper access network circuits

how does eopdh work
How does EoPDH work?

Ethernet Frame at UNI

Bonded E1s

Channelized STM-1

S-VLAN Tagged Ethernet Frame (EVC)

Ethernet Transport Network

IP

IP

IP

ETH

ETH

IP

GFP

GFP

ETH

ETH

EoPDH

Aggregator

Enterprise Subscriber

EoPDH

CLE

Copper PDH Access Network

  • Ethernet Frames enter UNI on EoPDH CLE and encapsulated in GFP
  • Access Network multiplexes E1s into channelized STM-1 circuits
  • E1s in STM-1 circuits terminated on EoPDH Aggregator
    • GFP terminated, Ethernet frames reconstructed
  • EoPDH Aggregator adds S-VLAN tag (QinQ) and passes Ethernet Service Frames to Ethernet Transport Network
ethernet l2 services and ethernet access to ip services over e1s pdh circuits pmo
Ethernet L2 Services and Ethernet Access to IP Services over E1s PDH circuits: PMO

TDM

Customer Premise

SDH

ADM

Local Switching Office (LSO)

PDH/SDH

Access Network

CE

EoPDH CLE

Ethernet handoff to customer

Ethernet

over E1s

Ethernet over

E1s in Channelized STM-1s

SDH

IP Service Edge

DCS

SDH

ADM

PE

Router

L2

switch

PDH Aggregation

Router

Ethernet

Ethernet

Ethernet over E1s in Channelized STM-1s

TDM PDH circuits from Customer Premise to IP Service Edge

fmo step 1 in network evolution to carrier ethernet
FMO Step 1 in Network Evolution to Carrier Ethernet

TDM

EoPDH

Aggregator

Ethernet over

E1s in Channelized STM-1s

Ethernet

Ethernet over SDH

Carrier Ethernet

IP Service Edge

IP Service Edge

DCS

PE

Router

PE

Router

L2

switch

L2

switch

PDH Aggregation

Router

Ethernet

Ethernet

Ethernet

Ethernet over E1s in Channelized STM-1s

Customer Premise

SDH

ADM

Local Switching Office (LSO)

PDH/SDH

Access Network

CE

EoPDH CLE

Ethernet handoff to customer

Ethernet

over E1s

SDH

SDH

ADM

  • EoPDH aggregator terminates PDH circuits and provides Ethernet to backhaul network resulting in improved bandwidth utilization
  • DCS and PDH Aggregation Router eliminated at IP Service Edge since PDH circuits terminated at LSO
fmo step 2 in network evolution to carrier ethernet
FMO Step 2 in Network Evolution to Carrier Ethernet

TDM

SDH

ADM

EoPDH CLE

Ethernet over

E1s in Channelized STM-1s

Ethernet

SDH

  • Converged Services
    • Ethernet L2 VPNs
      • MEF E-Line, E-LAN
    • Internet Access
    • VoIP
    • IP VPN

Ethernet over SDH

Ethernet

Carrier Ethernet

IP Service Edge

PE

Router

L2

switch

SDH

ADM

Ethernet

Customer Premise

Managed

CLE

PDH/SDH

Access Network

Local Switching Office (LSO)

EoPDH

Aggregator

CE

Ethernet handoff to customer

Ethernet

over E1s

  • SDH ADMs / Transport replaced by Ethernet Transport
  • Shortest possible Ethernet over E1 (PDH) loops
  • CLE at customer premise enables converged Ethernet and IP services
ethernet over pdh benefits
Ethernet over PDH Benefits
  • Simplifies Enterprise subscriber’s WAN connectivity
    • Provides “IT friendly” Ethernet (UNI) instead of E1 TDM circuit
  • Simplifies Provider’s Access/Aggregation Network
    • Terminates TDM PDH circuits as close to subscriber as possible
      • “Media conversion” (EthernetTDMEthernet) performed between EoPDH CLE and Aggregation Device
    • Improves backhaul bandwidth utilization

EoPDH enables ubiquitous, global Ethernet services over existing copper PDH access network facilities

ethernet point to point

Ethernet Point-to-Point

Wolfgang Fischer

Senior Manager, Business Development wfischer@cisco.com

a technology fairy tale
A technology fairy tale

Once upon a time in the last century...

  • Fiber was expensive and had to be shared
  • Optical transceivers were expensive and had to be shared
  • Few 10s of Mbit/s were considered more than enough to satisfy everybody’s bandwidth appetite
  • ITU-T and IEEE developed various flavours of PON

In the world as we know it today...

  • Fiber is cheap
  • Optical transceivers for FE and GE are cheap
  • Typical access bitrates grow 50% YoY reaching 100Mbit/s before the end of this decade and 1Gbit/s before the end of the next decade
  • Compelling reason for PON?
what is ethernet point to point
What is Ethernet Point-to-Point?

IP/MPLS

Edge/core

Ethernet/MPLS

Aggregation Network

FTTx

Access Network

PE-AGG

Access

Switch

E-FTTH

N-PE

STB

  • Direct star connectivity between POP and subscriber
    • topology similar to telephone access network
  • Using standard Ethernet technology (FE, GE, ...) over single strand of single-mode fiber
benefits of ethernet point to point
Benefits of Ethernet point-to-point
  • Simplicity
  • Virtually unlimited bitrate per subscriber
  • Fiber is neutral with respect to transmission technology
  • Migration to higher speeds or new technologies on a per-customer basis
  • Pay as you grow
  • Open Access to fiber inherently embedded in the architecture
  • Flexible, Future Proof
what about fiber management space
What about fiber management / space?
  • ODF for 2304 fiber terminations
  • Rack for 1502 active fiber interfaces
    • 50% take rate
    • up to 100% take rate achievable with second switch rack

Source: Huber & Suhner

but i want to share fiber
But I want to share fiber!
  • Most natural way of sharing a fiber is in wavelength-domain
  • DWDM-PON
    • technology available
    • economically viable within 2 years
  • Ethernet Point-to-Point per wavelength
  • Combines best of both worlds
ethernet over wdm pon

Ethernet over WDM-PON

Dr. Michael Ritter

Vice President Business Management Ethernet Access

MRitter@advaoptical.com

wdm pon network architecture
WDM PON network architecture

l1

FTTC

VDSL

l2

l3

l1 . . . ln

Ethernet

CentralOffice

FTTC

PassiveRemoteNode

ln

FTTB

FTTH

benefits of wdm pon technology
Benefits of WDM PON technology
  • Scalability through bitrate and protocol independency
  • Upgrade path on a per service level
  • High degree of security and privacy
  • Simple and straightforward network planning
  • Geographical flexibility with long reach capability
  • Architecture supporting open access networking
  • Standard Ethernet technology and inter-working
wdm pon options
WDM PON options
  • Power splitters vs. filters in remote node
  • Lambda grid options – DWDM, CWDM, …
  • Bit rate per wavelength – 1G, 2G5, 4G3, 10G
  • Colored or colorless ONU design
  • Underlying TDM scheme for high fan out
  • Protection options for highest availability
  • Optional amplification for extended reach
optical access applications
Optical access applications

residential services

access

business servicesaccess

infrastructure

backhaul

FTTN

FTTH

FTTC

FTTB

FTTO

FTTB

opticalbackhaul

activeEthernet

E/GPON

opticalbackhaul

opticalbackhaul

activeEthernet

passiveWDM

opticalbackhaul

all access technologies need efficient high-capacity backhaul

eliminating active equipment and freeing up real estate
Eliminating active equipment and freeing up real estate

CP

Curb

LO

CO

FTTC/VDSL

25…50 Mbps

per user

VDSL

DSLAM

aggregationswitch

opticaltransport

aggregationswitch

FTTB/H GPON

<100 Mbps

per user

passiveopticalsplitter

OLT

aggregationswitch

aggregationswitch

opticaltransport

FTTB Passive WDM

1++ Gbps

per user

passiveWDM

opticaltransport

smart service termination
Smart service termination

Optojack - loop, plug, device

  • Potential demarcation layers
    • fiber availability
    • optical performance
    • coding integrity
    • protocol statistics
    • Ethernet virtual circuit statistics
  • Loop: passive pilot tone
  • Plug: active intelligent transceiver
  • Device: active demarcation unit

OJ - Loop

Application

SFP

OJ - Plug

Application

SFP

OJ - Device

Application

SFP

SFP

SFP

summary
Summary
  • Simple, open and dedicated point-to-point connectivity
  • Efficient and future-proof transport architecture optimized for access networks
  • Utilized leading edge technology to reduce both capital and operational cost
ethernet over pon

Ethernet over PON

Gerlinde Bedö

Head of Broadband Access Marketing

Gerlinde.bedoe@nsn.com

there is no doubt world goes fiber
There is no doubt: World goes fiber
  • “The results [of the research evaluating the sustainability and environmental impact of fiber networks] clearly demonstrate the overall service and environmental benefits of FTTH. The findings stand as testament that fiber is a sustainable and future-proof technology for the 21st century.”
  • Joeri Van Bogaert, president FTTH Council, 2008

“Fiber right now is not just a means to get bits to the subscriber,it is also a potentially effective marketing tool.”

Telecom Strategy Partners, 2008

but which technology fulfills best all requirements
But which technology fulfills best all requirements?
  • Which technology addresses better IPTV and VoIP? What about legacy & TDM?
  • Bandwidth availability & flexibility, capacity upgrade possibilities
  • Maintenance & fault isolation
  • Interoperability & multi-vendor networks
  • SLA assurance, service protection, and their associated costs
  • How to maximize the use of existing infrastructure?
  • The access network and future applications: network dimension & bandwidth simulation

Fiber

Active Ethernet

GEPON

FTTC / VDSL

GPON

pon is becoming a leading fibre technology
PON is becoming a leading fibre technology

GPON will dominate in the US, since it is now certain to be used by both the major ILECs and many independent telcos. Active Ethernet has some limited support in the US, but it will remain a minority technology, taking declining share in the overall market

FTTH Worldwide technology update & market forecast

Because GE-PON is currently the technology ofchoice in Japan,it will dominate overall global FTTH deployments over next few years.

FTTH Worldwide technology update & market forecast

all over the world operators go for pon pon subscribers will dominate ptp subscribers
All over the world operators go for PONPON subscribers will dominate ptp subscribers

60.000

50.000

Subscribers (000)

40.000

PON

30.000

P2P

20.000

10.000

-

2006

2007

2008

2009

2010

2011

2012

Source: Broadbandtrends, 10/2007

Worldwide fiber deployments

what is pon
What is PON?

FTTH

  • Created by the FSAN organization (driven by service providers & operators); Standardized by ITU-T (A/BPON, GPON) or IEEE (EPON)
  • Bandwidth >100Mbit/s per subscriber through DBA
  • PON optimized for multicast and „downstream intensive“ traffic
  • Cost-optimized support of multiple (legacy and new) services through various subscriber interfaces: VoIP (SIP, H.248), video (IPTV, cable TV), data
  • Support of all types on in-house cabling: copper TP, CAT5, fiber
  • Real multi-service platform: in the 1st mile and in the CO
  • Easy upgrade to more subscribers and higher bandwidth
  • Clear migration path to NG-PON
  • PON is a „green“ technology

Carrier Network

Passive Optical splitter

Passive Optical splitter

ONT SFU

Metro

MPLS / VPLS

2.5Gbps DS

1.25Gbps US

TDM Network

1:16 Optical splitter

Multi-Dwelling Unit

FTTB

pon is the ideal solution to backhaul mobile traffic
PON is the ideal solution to backhaul mobile traffic

SDH

RNC

Node-B/BTS

STM 1/4

Mobile core

1/10 GE

E1/TDM

E1/TDM

Ethernet

TDMoIP

GPON is the ideal platform to backhaul mobile traffic (from 2G to LTE)

  • Through built in synchronization capabilities in OLT
  • Support of all relevant BTS interfaces: E1, Ethernet
  • Sufficient bandwidth for LTE traffic
the tco advantage of gpon
The TCO advantage of GPON

Point-to-point Ethernet

GPON

  • Realistic deployment
  • 5000 subscribers connected to CO
  • PON splitting ratio 1:32
  • Fibre terminations per ODF rack: 1,440(10 shelves holding 144 fibres)
  • Power consumption figures and ports per cage based on real product specs

19.6

5000

x 6.7

38

x 31.8

x 3.6

Ethernet

GPON

10

2.9

157

Patch cords

Power[kW]

CO Space[M2]

q and a shootout

Greg Poggi

Vice President of Sales

gpoggi@omnitron-systems.com

Q and A“Shootout”

Ralph Santitoro

Chair, MEF Web Marketing Committee

Director of Carrier Ethernet Solutions

Ralph@Marcom-Services.net

Wolfgang Fischer

Senior Manager, Business Development wfischer@cisco.com

Dr. Michael Ritter

Vice President Business Management Ethernet Access

MRitter@advaoptical.com

Gerlinde Bedö

Head of Broadband Access Marketing

Gerlinde.bedoe@nsn.com
