What are endoscopes used for?. TOTAL INTERNAL REFLECTION. TIR occurs in optical fibres , these are used in endoscopes. Inside Glass. Optical fibres are made of pure glass They are flexible Light is reflected when it strikes the inside surface of the fibre.
