Presentation Transcript


6306020

  • Republic of Iraq Ministry Of Industry & Minerals

STATE COMPANY FOR IRON AND STEEL (SCIS)

Iraqi Ministry of Industry & Minerals

جمهورية العراقوزارة الصناعة والمعادن

BASRAH –IRAQ


6306020

Republic of Iraq Ministry Of Industry & Minerals

جمهورية العراق وزارة الصناعة والمعادن

Plants History

* Completely owned by the government.

* Specialized in producing re-bars and sections.

* Constructed at the beginning of the

seventieth by a French company

(Creusot – Liore) and commissioned in 1980.

* Because of the embargo of (1991 -2003 ) the

production was very limited .

* Completely stopped due to the events

of 2003 happened in Iraq.


6306020

جمهورية العراق وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

UTILITIES

1-Electrical power units:

*Two power transmission lines of KhorAlzubair 400/132 KV from

power station through the national grid.

* It is located 8 Km to the south of the company.

* These lines are capable for power

transmission of about 200 MVA .


6306020

Republic of Iraq Ministry Of Industry & Minerals

جمهورية العراق وزارة الصناعة والمعادن

2-Raw water unit

* The Company owns a separate

raw water pumping station for

in Abu-Alkhaseeb city.

* The station capacity is up to 6000

M3/hr.

* Two separate pipe lines (700

, and 900 mm pipe dia , of

each of about 35 Km ).


6306020

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

3- Natural gas unit:

* A separate pipe line for natural gas that is connected to the main line of Khor-Al- Zubair network.

* The available gas pressure is 37 Kg/cm2 and Gas quantity can reach up to 75 million cubic feet/ day.

4- Shades and buildings:

The company comprises many production workshops, for

services, stores, and others, are in a very good conditions.


Republic of iraq ministry of industry minerals

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

Unloading sea yard :-

- A special yards in Khor-Al-Zubair

seaport for transformation iron ore pellets ,

sponge iron and scrap.

- These yards are connected to the site

through a double road of about 7 Km

length.

6


Republic of iraq ministry of industry minerals1

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

Transportation unit 5-

Railways and streets:

* Separate railway line connected to

Basrah - Um Qaser line.

* A complete network of railways

inside the company site including stores, scrap yards and lime kiln

yard.

* Also a separate motorway road

connecting the company to Um-

Qaser high way.


Plant data

Republic of Iraq Ministry Of Industry & Minerals

جمهوريه العراق

وزارة الصناعة والمعادن

Plant Data

The company consists mainly of the followings:

1- Melt shop plant: four electric arc furnaces each of 70 tons capacity,

casting machines 35 MVA transformer and 2 X 6 strands continues

for billet size ( 100, 120, 150) mm. The design capacity is supposed to

be 440,000 tons / year of billets , lime kiln scrap preparation and

charging section.

2- DRI plant (direct reduced Iron): Two units (Big and Small unit) each of

tow modules, four reactors each (HYL1 process) and other

The total production is 1.2 million tons /year. facilities.


Republic of iraq ministry of industry minerals2

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

3- Rolling Mill plant: With two lines, one for re-bars and light

sections (Including a wire rod production line of dia 8,10 mm)

, the other for medium sections. The total productivity is

400,000 tons/year as finished products.

4- Supporting departments: including the quality control , central , quality management, enviromental …….etcworkshope

9


Republic of iraq ministry of industry minerals3

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

Product range

- * Light section:

Deformed and round bar 12 - 32 mm dia

Equi- angle section 20 - 50 mm

6- 50 × 5 mm ×25 strip –section square bar –section 10, 12, 16 mm

mm20× U- channel 40

*Medium section: -

I- beam 100, 120, 140, 160 mm

U- channel 80, 100, 120,140,160 mm

mm6 × 60 , 6 ×70,1070 × ، 80 × 10, 8 ×Equi- angle 80


Republic of iraq ministry of industry minerals4

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

Spirally Welded Steel Pipe Plant

* It is established in the seventieth, in UM QASER city comprising

two production machines, the plant had been upgraded in the

eighteenths through installing a third production machine and PE

coating line by a productivity of 90,000 t/y.

* Now the plant is working after complete rehabilitation by installing

new production line imported from (W&K) a German company using

technology "double stage method" in which forming of pipe and final

welding is done in a separate machines, the new productivity reachs up

to 200,000 t/y.


Republic of iraq ministry of industry minerals5

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

Investment projects

*Iocal or /and foreign invistors are inviteded to participate in

a complete job for upgrading and rehabilitation of production

units and other services of the existing workshops by utilizing

the existing infrastructure.

* This call represents a part of the ministry policy to promote

and encourage investment in different industrial branches.


Republic of iraq ministry of industry minerals6

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of IraqMinistry Of Industry & Minerals

Projects under investment

1-Steel making plants:

*steel manufacturing is considered as one of the most important

industrial branches for and infrastructure will be an essential part

of Iraqi reconstruction program.

* An investment contract with (UP HOLDING) a Turkish company

on development 6/11/2013.

* The contract includes the upgrading of existing plants by installing

new production equipments and utilities to reach a capacity of

1 million t/y. the project include also an electrial power station.


Republic of iraq ministry of industry miner als

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

* The period of rehabilitation will be

3 years.

* Overall contract period is 21 years.

* Equipments will be supplied from

Danieli or SMS compantes.

  • .


Republic of iraq ministry of industry minerals7

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

2-An investment opportunity for pipe mill, is under

negotiation with specialized companies that had

participated in the tender and the offers are under final

evaluation now.

3- In addition there is a tendency to go with a production

partnership from as a specialized pipe companies.


Republic of iraq ministry of industry minerals8

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq Ministry Of Industry & Minerals

Complex Project For Iron & Steel in

The Industrial City of Basrah

* The aim is to build a modern steel plant.

* factories and their descriptions listed .

* The project consists of energies also comes to keep abreast of

world and the advancement of heavy industry development in the

.local consumers and meet the needs of the


Factories are proposed

جمهوريه العراق

وزارة الصناعة والمعادن

Republic of Iraq

Ministry Of Industry & Minerals

Factories are proposed

1 - steel wires plant 150 thousand tons per year .2 - heavy sections iron + Railway plant 600 000 tons per year. .3 - medium sections plant 750 thousand tons per year .4 - HRC+ Plate plant 1300 thousand tons per year 5- spiral pipe welding or seamless pipe plant 200 thousand tons

per year. 6 - longitudinally welding pipe plant 300 thousand tons per year. 7 - power generation 500 megabytes .


Republic of iraq

جمهوريه العراق

وزارة الصناعة والمعادن

Ministry Of Industry & Minerals

Republic of Iraq

Contact Details

Investment Directorate

Ministry of Industry & Minerals / Baghdad

e-mail:- [email protected]

Tel: 00964 (1) 8162006 Ext. 3127 , 3122

Mobile: 00964 7901 371 867

SCIS

e-mail: [email protected]

Mobile : 00964 (0) 7801 011 626


6306020

ذ

Thanks
