  1. Performance Characterization of Voice over Wireless LANs Lionel PEREZ xxxxxx, 2005

  2. Agenda • Introduction to IEEE 802.11 • Different MAC mechanisms • Quality of Service and 802.11e • Related Work • How does our solution work? • Modelisation • Measurements • Simulation

  3. Logical Link Control (LLC) Datalink Medium Access Control (MAC) Physical IEEE 802.11 • 1997 • WLAN or Wi-Fi • RFCs • Defines PHY and Data Link Layers

  4. PHY Layer • DSSS • FHSS • Infrared • 802.11 • 802.11b • 802.11g • 802.11a

  5. Data Link Layer • MAC and LLC • LLC • MAC • DCF • PCF

  6. DCF • CSMA CA • Parameters: • DIFS • SIFS • Slot duration • Cwmin • CWmax

  7. PCF • Above DCF • Polling • Parameters: • PIFS • SIFS

  8. Compatibility with Voice • Naive calculation: 85 VoIP calls • In reality, 6 or 7.. 20 ?! • General frame structure • Encapsulation overhead • Intrinsic Overhead • Transmission time

  9. QoS and 802.11e • New MAC Mechanism • HCF • EDCF + EPCF

  10. Related Work • Model, Measure, and Simulate • DCF, PCF and 802.11e • Performance in terms of: • Capacity (Number of connections) • Delay, Jitter, throughput • Voice Quality • Enhancements • Nothing specific to VoIP traffic yet !! (seen as payload in RTP over UDP over IP packets)

  11. Related Work cont’d • In details: • Markov chain • Petri Nets • Entry Parameters: • Cwmin • IFS times • Codec

  12. Alcatel’s solution • Architecture: • Infrastructure mode • Partners: • Aruba • Spectralink • Proprietary protocols and QoS mechanisms • How to measure and predict QoS ?

  13. Traffic Analysis • Identify the QoS mechanism • Modified DCF? Expectations not true • Voice only: • polling (PCF) • Voice + Data: • Ixchariot • PCF • Propose a model

  14. Frame Analysis • Frame structure • Open system • WEP • WPA

  15. Measurement Plan • Open system: • Capacity measurements • Voice + Data: • Voice capacity and Data throughput

  16. Model accuracy • With our QoS scheme (PCF), G.711 • The key factor is framing: 30 ms !!! • Calculations: • Open system capacity • Residual Data throughput • With WEP • With WPA (prioritisation problem)

  17. Thank you.
