Chapter 5 weathering and soil

GEOL 101

Introductory Geology

Chapter 5Weathering and Soil


Earth s external processes

Earth’s external processes

  • Weathering – the physical breakdown (disintegration) and chemical alteration (decomposition) or rock at or near Earth’s surface

  • Mass wasting – the transfer of rock and soil downslope under the influence of gravity (Chapter 9)

  • Erosion – the physical removal of material by mobile agents such as water, wind, ice, or gravity


Weathering

Weathering

  • Types of weathering

    • Mechanical weathering

    • Chemical weathering

    • Other function together

  • Weathering Processes

    • Dissolution

    • Oxidation

    • Hydrolysis


  • Weathering1

    Mechanical & chemical processes work together

    Weathering

    Solid rock

    Chemical weathering attacks susceptible minerals

    Rock crumbles by mechanical weathering

    Chemical/mechanical processes form clay and disperse minerals


    Mechanical weathering

    Mechanical Weathering

    Increased surface area


    Types of weathering

    Types ofWeathering

    • Mechanical weathering – breaking of rocks into smaller pieces

      • Frost wedging – freezing/thawing of water in fractures, disintegration of rocks

      • Unloading – exfoliation of igneous and metamorphic rocks at the Earth’s surface due to a reduction in confining pressure

      • Thermal expansion – expansion and contraction due to heating and cooling

      • Biological activity – disintegration resulting from plants and animals


    Frost wedging

    Frost Wedging


    Unloading exfoliation

    Unloading - Exfoliation


    Exfoliation

    Exfoliation


    Thermal expansion

    Thermal Expansion


    Biological

    Biological


    Chemical weathering

    Chemical Weathering

    • Breaks down rock components and internal structures of minerals

    • Most important agent involved in chemical weathering is water (responsible for transport of ions and molecules involved in chemical processes)


    Chemical weathering processes

    Chemical Weathering Processes

    • Dissolution

      • Aided by small amounts of acid in the water

      • Soluble ions are retained in the underground water supply

  • Oxidation

    • Chemical reaction where compound or radical loses electrons

    • Important in decomposing ferromagnesian minerals

  • Hydrolysis

    • The reaction of any substance with water

    • Hydrogen ion attacks and replaces other positive ions


  • Simple dissolution

    Simple Dissolution

    Halite (salt) dissolving in water


    Dissolution by acidic water

    Dissolution by Acidic Water

    • Marble and limestone (calcium carbonate) decompose due to acidic water

    Calcium Carbonate + Acidic Water

    CaCO3 + 2[H+(H2O)]

    Ca2+ + CO2 + 3(H2O)

    Soluble Calcium + Carbon Dioxide + Water

    • Acid rain caused by air pollution


    Oxidation

    • Iron (Fe) minerals rust when exposed to water and oxygen

    • Oxidation: loss of electron from element

    • Iron oxidation produces

      • Hematite (Fe2O3): reddish brown rust

      • Limonite [FeO(OH)]: yellowish rust

    Oxidation

    Iron + Oxygen

    4Fe3+ + 3O22-2Fe2O3

    Hematite (iron oxide)


    Hydrolysis

    Hydrolysis

    • Silicate minerals decomposed by water due to hydrolysis

    • Produces clay, soluble salt, silica

    Potassium Feldspar + Carbonic Acid + Water

    2KAlSi3O8 + 2(H+ + HCO3-) + H2O

    Al2Si2O5(OH)4 + 2K+ + 2HCO3 -) + 4SiO2

    Kaolinite + Potassium + Bicarbonate + Silica

    (clay)(salt)

    in solution


    Chapter 5 weathering and soil

    Products Weathering


    Chemical weathering alternations

    Chemical Weathering Alternations

    • Decomposition of unstable minerals

    • Generation or retention of materials that are stable

    • Physical changes such as the rounding of corners or edges


    Weathering factors

    Weathering Factors

    • Rates of weathering

      • Advanced mechanical weathering aids chemical weathering by increasing the surface area

  • Rock characteristics

    • Rocks w/ calcite (marble and limestone) readily dissolve in weakly acidic solutions

    • Silicate minerals weather in the same order as their order of crystallization

  • Climate

    • Temperature and moisture, most crucial factors

    • Chemical weathering is most effective in areas of warm, moist climates


  • Chemical weathering rate variation by rock type

    Chemical WeatheringRate variation by rock type

    Granite

    Marble


    Weathering rates

    Weatheringrates

    • organic activity - organic acids

      • raises wtr rates by orders of magnitude

    • climate - temp and amount of water

    • water flow through rock

    • bedrock composition

    • topography: groundwater flow

    • time - to equilibrium?


    Rock characteristics

    Rock Characteristics

    Bowen’s Reaction Series


    Weathering processes

    Weathering Processes

    • Reaction rates and weathering susceptibilities approximate a “backwards Bowen’s Reaction Series”

      • first minerals (highest P/T) to crystallize are least stable (first to weather)

      • last minerals (lowest P/T) to crystallize are most stable (last to weather)

    • Residual material is altered to a stable composition and physical form


    Differential weathering

    Differential Weathering

    • Masses of rock do not weather uniformly due to regional and local factors

    • Results in many unusual and spectacular rock formations and landforms


    Differential weathering1

    Differential Weathering


    Differential weathering2

    Controlled by jointing patterns

    Differential weathering


    Joint controlled weathering in igneous rocks

    Joint-controlled weathering in igneous rocks


    Chapter 5 weathering and soil

    Soil

    • Soil is a combination of mineral and organic mater, water, and air

      • Results from weathering

      • Regolith: rock and mineral fragments produced by weathering (weathered debris)

      • Soil supports the growth of plants

      • Good soil: mix of decomposed rock and humus (decay plant and animal)


    Typical soil components

    Typical soil components


    Chapter 5 weathering and soil

    Soil

    • Soil Formation

    • Soil Profile

    • Soil Types

    • Soil Erosion


    Soil formation

    Soil Formation

    • Parent material

      • Residual soil – parent material is the underlying bedrock

      • Transported soil – forms in place on parent material that has been carried from elsewhere and deposited

  • Time

    • Important in all geologic processes

    • Amount of time for soil formation varies for different soils depending on geologic and climatic conditions


  • Soil formation1

    Soil Formation

    • Parent material

      • Residual soil: parent material is the underlying bedrock

      • Transported soil: forms in place on parent material that has been carried from elsewhere and deposited

    • Time

      • Important in all geologic processes

      • time for soil formation varies depending on geologic and climatic conditions


    Soil formation2

    Soil Formation

    • Climate

      • Most influential control of soil formation

      • Key factors: temperature and precipitation

    • Plants and animals

      • Organisms influence the soil’s physical and chemical properties

      • Also furnish organic matter to the soil

    • Slope

      • Steep slopes often have poorly developed soils

      • Optimum terrain is flat-to-undulating upland surface


    Soil formation3

    Soil Formation


    Soil development variations due to topography

    Soil development variations due to topography


    Soil profile

    Soil Profile

    • Soil forming processes operate from the surface downward

    • Vertical differences are called horizons – zones or layers of soil


    Chapter 5 weathering and soil

    Soil Profile

    • O horizon – organic matter

    • A horizon – organic and mineral matter

      • High biological activity

      • O and A horizons together make up the topsoil

    • E horizon – little organic matter

      • Zone of eluviation and leaching

      • The O, A, E, and B horizons together are called the solum (“true soil”)

    • B horizon – zone of accumulation

    • C horizon – partially altered parent material


    Idealized soil profile

    Idealized soil profile

    O

    A

    E

    B

    C

    Parent


    Soil profile showing horizons

    Soil Profile showing horizons

    O

    A

    E

    B

    C

    Parent


    Soil profile showing solum

    Soil profile showing Solum

    O

    A

    E

    B


    Soil development

    Soil Development


    Soil types

    Soil Types

    • Characteristics of each soil type primarily depend on prevailing climatic conditions

    • Climate conditions relate to vegetation

    • Three generic soil types

      • Pedalfer

      • Pedocal

      • Laterite


    Soil types1

    Soil Types

    • Pedalfer

      • Humid (>63 cm rainfall), temperate

      • Forest vegetation

      • Fe oxides and Al-rich clays in the B horizon

    • Pedocal

      • Arid (<63 cm rainfall), temperate

      • Dry grasslands and brush vegetation

      • High accumulations of calcium carbonate

    • Laterite

      • Tropical climates, hot and wet

      • Lush grasslands and trees vegetation

      • Intense chemical weathering


    Soil types2

    Soil Types

    Pedalfer

    Pedocol

    Laterite

    Arid

    Tropical

    Humid


    Soil erosion

    Soil Erosion

    • Constant recycling of Earth materials, part of rock cycle

    • Water and wind are powerful erosion forces that move soil components

    • Raindrop like tiny bomb to soil particles

      • sheet erosion: thin sheets of water

      • rills: tiny channels

      • gullies: deeper cuts

  • Sediment: soil that reaches a stream


  • Soil erosion1

    Soil Erosion

    • Natural rates of soil erosion depend on

      • Soil characteristics

      • Climate

      • Slope

      • Type of vegetation

    • In many regions, rate of soil erosion is significantly > rate of soil formation

    • Sedimentation and chemical pollution

      • Related to excessive soil erosion

      • Occasionally soil particles are contaminated with pesticides, industrial pollutants etc.


    Soil erosion2

    Soil Erosion

    • Good soil development critical for agriculture and forestry

    • Agricultural soil conservation measures

      • Planting trees as windbreaks

      • Plowing hill contours and terracing

      • Crop rotation

    • Forestry soil conservation measures

      • Eliminate clear cutting (selective harvest)

      • Careful design of logging roads

      • Harvest away from drainage area
