Presentation Transcript


Whmis

WHMIS


Whscc cssiat

WHSCC/Cssiat

W

H

M

I

S

Workplace

Hazardous

Materials

Information

System

2003 2


Introduction to whmis

Introduction to Whmis

WHMIS is Canada-wide legislation, dealing with controlled products in the workplace.

*A controlledproduct is ‘any product, material or substance included in any one of the classes listed in the Hazardous Products Act (HPA).’

2003 3


Whmis is designed to solve the problem of

WHMIS is Designed to Solve the Problem of:

  • Unlabelled materials in the workplace

  • Inadequate or contradictory information being given to employers/workers regarding identification, hazardous properties and precautions to be taken with hazardous materials used in the workplace

2003 4


Three components of whmis

Three Components of WHMIS

  • Labels on hazardous materials or their containers

  • MSDS or material safety data sheets which are technical bulletins providing more detailed information than the label

  • Worker education, providing instruction on hazards and safe work procedures

2003 5


Flow of information

JHSC

input

Producer

Supplier label

Supplier

Informed worker

Employer

Worker Training

MSDS

Importer

Flow of Information

2003 6


Labels

Labels

Two Types:

  • Supplier labels (developed and provided by the supplier)

  • Workplace labels (developed and used in the workplace)

2003 7


Supplier label design and application

Supplier label: Design and Application

1 of 3

  • Content layout: not legislated

  • Border: specific

  • Colour: not legislated

  • Legibility: distinct; good contrast

  • Durability: able to withstand normal use

  • Application: imprinted; stenciled; attached

  • Language: English and French

2003 8


Supplier label required statements

Supplier Label: Required Statements

2 of 3

1. Product Identifier

2. Hazard Symbols

3. Risk Phrases

4. Precautions

5. First Aid

6. Supplier Information

7. Reference to MSDS

2003 9


Supplier label

Supplier Label

3 of 3

2003 10


What does this symbol mean

What Does This Symbol Mean?

1 of 2

2003 11


What do we know

What Do We Know?

2 of 2

Compressed Gas

(Class A):

  • Poses an explosion danger because the gas is under pressure

  • Container may explode if heated in a fire, or dropped

  • examples include: compressed air, carbon dioxide, propane, oxygen, ethylene oxide, and welding gases

2003 12


What does this symbol mean1

What Does This Symbol Mean?

1 of 2

2003 13


What do we know1

What Do We Know?

2 of 2

Combustible and Flammable Material

(Class B):

  • Will burn and is therefore a potential fire hazard

  • May burn at relatively low temperatures; flammable materials catch fire at lower temperatures than combustible materials

  • May burst into flame spontaneously in air, or release a flammable gas on contact with water

  • May cause a fire when exposed to heat, sparks, or flames, or as a result of friction

  • Common examples include: propane, butane, acetylene, ethanol, acetone, turpentine, toluene, kerosene, Stoddard solvent, spray paints and varnish.

2003 14


What does this symbol mean2

What Does This Symbol mean?

1 of 2

2003 15


What do we know2

What Do We Know?

2 of 2

Oxidizing Material

(Class C):

  • Poses a fire and/or explosion risk in the presence of flammable or combustible material

  • May react violently when it comes into contact with combustible materials such as fuels or wood

  • May burn skin and eyes upon contact

  • Oxidizers can also be in the form of gases (oxygen, ozone), liquids (nitric acid, perchloric acid solutions) and solids (potassium permanganate, sodium chlorite).

2003 16


What does this symbol mean3

What Does This Symbol Mean?

1 of 2

2003 17


What do we know3

What Do We Know?

2 of 2

Poisonous and Infectious Material

(Class D, Division 1):

  • Is a potentially fatal poisonous substance

  • May be fatal or cause permanent damage if it is inhaled or swallowed or if it enters the body through skin contact

  • May burn eyes or skin upon contact

  • Examples of some D-1 materials include carbon monoxide, sodium cyanide, sulphuric acid, toluene-2,4-diisocyanate (TDI), and acrylonitrile.

2003 18


What does this symbol mean4

What Does This Symbol Mean?

1 of 2

2003 19


What do we know4

What Do We Know?

2 of 2

Poisonous and Infectious Material: Other Toxic Effects (Class D, Division 2):

  • Not immediately dangerous to health

  • May cause death or permanent damage as a result of repeated exposure over time

  • May be a sensitizer, which produces an allergy

  • May cause cancer, birth defects, or sterility

  • Examples include: asbestos fibres, mercury, acetone, benzene, quartz silica (crystalline), lead and cadmium.

2003 20


What does this symbol mean5

What Does This Symbol Mean?

1 of 2

2003 21


What do we know5

What Do We Know?

2 of 2

Poisonous and Infectious Material: Biohazardous, infectious material

(Class D, Division 3):

  • May cause a serious disease resulting in illness (AIDS, Hepatitis) or death

  • Can also include tetanus protection

  • Examples of biohazardous infectious materials include the AIDS/HIV virus, Hepatitis B and salmonella.

2003 22


What does this symbol mean6

What Does This Symbol Mean?

1 of 2

2003 23


What do we know6

What do We Know?

2 of 2

Corrosive Material

(Class E):

  • Causes severe eye and skin irritation upon contact

  • Causes severe tissue damage with prolonged contact

  • Often produces vapor or fumes that may be harmful if inhaled

  • Common corrosives include acids such as sulphuric and nitric acids, bases such as ammonium hydroxide and caustic soda and other materials such as ammonia gas, chlorine, and nitrogen dioxide.

2003 24


What does this symbol mean7

What Does This Symbol Mean?

1 of 2

2003 25


What do we know7

What Do We Know?

2 of 2

Dangerously Reactive Material

(Class F):

  • Is very unstable

  • May react with water to release a toxic or flammable gas

  • May explode as a result of shock, friction or an increase in temperature

  • May explode if heated when in a closed container

  • Undergoes vigorous polymerization

  • Examples of these products are ethyl acrylate, vinyl chloride, ethylene oxide, picric acid and anhydrous aluminum chloride.

2003 26


Workplace labels

Workplace Labels

1 of 2

  • Methanol

  • Avoid inhaling vapours, handle with care

  • Flammable

  • Avoid eye and skin contact

  • See MSDS for more information

  • Product Identifier

  • Information on safe handling of the product

  • Reference to MSDS

2003 27


Workplace labels1

Workplace Labels

2 of 2

  • Must be displayed to give clear warning to employees

  • May be a label, tag, sign or other

  • Is not required to be bilingual; can be in the language of the workplace

2003 28


Material safety data sheets

Material Safety Data Sheets

1 of 3

The MSDS is:

  • A technical information reference for worker education and control measures

  • A document which can be distributed

2003 29


Material safety data sheets1

Material Safety Data Sheets

2 of 3

The MSDS is NOT:

  • All the information needed for the safe use of a product in every possible situation

  • A document only to be read and filed

2003 30


Msds required criteria

MSDS Required Criteria

3 of 3

1.Product Identifier

2.Ingredients

3.Physical Data

4.Fire and Explosion Hazards

5.Reactivity Data

6.Toxicological Properties

7.Preventive Measures

8.First Aid Measures

9.Preparation Information

2003 31


Worker education

Worker Education

1 of 2

Anyone working with or nearby controlled products must be trained in hazard information and procedures regarding:

  • Safe use

  • Storage

  • Handling

  • Disposal

  • Emergency procedures

2003 32


Supplier responsibilities

Supplier Responsibilities

Supplier responsibilities are found under the Hazardous Products Act

(Federal Bill C-07)

Suppliers Must:

I. Label controlled products intended for workplace use

II. Supply MSDS with each controlled product

2003 33


Employer responsibilities

Employer Responsibilities

  • The employer’s WHMIS responsibilities are outlined in Provincial Regulation 88-221:

  • To obtain MSDS from supplier

  • Ensure appropriate labeling (supplier and workplace)

  • Provide adequate instruction and training to employees

  • Sort and file the MSDS in a clearly indicated and easily accessible area

2003 34


Summary

Summary

1 of 2

  • Labels

  • MSDS

  • Worker Education

WHMIS has three components:

  • Compressed Gas

  • Flammable

  • Oxidizers

  • Poisons

  • Corrosives

  • Reactive

WHMIS is a hazard class driven system

2003 35


Summary1

Summary

2 of 2

Employers must train their workers to use the information provided by

  • Labels

  • MSDS

Training should be reviewed and/or updated

Yearly, or as conditions change

2003 36
