Artificial Neural Networks

Notes based on Nilsson and Mitchell’s

Machine learning


Outline

Outline

  • Perceptrons (LTU)

  • Gradient descent

  • Multi-layer networks

  • Backpropagation


Biological neural systems

Biological Neural Systems

  • Neuron switching time : > 10-3 secs

  • Number of neurons in the human brain: ~1010

  • Connections (synapses) per neuron : ~104–105

  • Face recognition : 0.1 secs

  • High degree of parallel computation

  • Distributed representations


Properties of artificial neural nets anns

Properties of Artificial Neural Nets (ANNs)

  • Many simple neuron-like threshold switching units

  • Many weighted interconnections among units

  • Highly parallel, distributed processing

  • Learning by adaptation of the connection weights


Appropriate problem domains for neural network learning

Appropriate Problem Domains for Neural Network Learning

  • Input is high-dimensional discrete or real-valued (e.g. raw sensor input)

  • Output is discrete or real valued

  • Output is a vector of values

  • Form of target function is unknown

  • Humans do not need to interpret the results (black box model)


Artificial neural networks notes based on nilsson and mitchell s machine learning

  • General Idea

  • A network of neurons. Each neuron is characterized by:

    • number of input/output wires

    • weights on each wire

    • threshold value

  • These values are not explicitly programmed, but they evolve through a training process.

  • During training phase, labeled samples are presented. If the network classifies correctly, no weight changes. Otherwise, the weights are adjusted.

  • backpropagation algorithm used to adjust weights.


Alvinn carnegie mellon univ

ALVINN (Carnegie Mellon Univ)

Automated driving at 70 mph on a public highway

Camera


30 outputs

for steering

30x32 weights

into one out of

four hidden

unit

4 hidden

units

30x32 pixels

as inputs


Artificial neural networks notes based on nilsson and mitchell s machine learning

  • Another Example

  • NETtalk – Program that learns to pronounce English text. (Sejnowski and Rosenberg 1987).

  • A difficult task using conventional programming models.

  • Rule-based approaches are too complex since pronunciations are very irregular.

  • NETtalk takes as input a sentence and produces a sequence of phonemes and an associated stress for each letter.


Artificial neural networks notes based on nilsson and mitchell s machine learning

NETtalk

A phoneme is a basic unit of sound in a language.

Stress – relative loudness of that sound.

Because the pronunciation of a single letter depends upon its context and the letters around it, NETtalk is given a seven character window.

Each position is encoded by one of 29 symbols, (26 letters and 3 punctuations.)

Letter in each position activates the corresponding unit.


Artificial neural networks notes based on nilsson and mitchell s machine learning

NETtalk

The output units encode phonemes using 21 different features of human articulation.

Remaining five units encode stress and syllable boundaries.

NETtalk also has a middle layer (hidden layer) that has 80 hidden units and nearly 18000 connections (edges).

NETtalk is trained by giving it a 7 character window so that it learns the pronounce the middle character.

It learns by comparing the computed pronunciation to the correct pronunciation.


Handwritten character recognition

Handwritten character recognition

  • This is another area in which neural networks have been successful.

  • In fact, all the successful programs have a neural network component.


Threshold logic unit tlu

x1

x2

xn

Threshold Logic Unit (TLU)

inputs

weights

w1

output

activation

w2

y

q

.

.

.

a=i=1n wi xi

wn

1 if a q

y=

0 if a< q

{


Activation functions

Activation Functions

threshold

linear

y

y

a

a

sigmoid

piece-wise linear

y

y

a

a


Decision surface of a tlu

Decision Surface of a TLU

1

1

Decision line

w1 x1 + w2 x2 = q

x2

w

1

0

0

0

x1

1

0

0


Scalar products projections

Scalar Products & Projections

v

v

v

w

w

w

j

j

j

w • v > 0

w • v = 0

w • v < 0

v

w

j

w • v = |w||v| cos j


Geometric interpretation

Geometric Interpretation

The relation w•x=q defines the decision line

x2

Decision line

w

w•x=q

y=1

|xw|=q/|w|

xw

x1

x

y=0


Geometric interpretation1

Geometric Interpretation

  • In n dimensions the relation w • x=q defines a n-1 dimensional hyper-plane, which is perpendicular to the weight vector w.

  • On one side of the hyper-plane (w • x > q) all patterns are classified by the TLU as “1”, while those that get classified as “0” lie on the other side of the hyper-plane.

  • If patterns can be not separated by a hyper-plane then they cannot be correctly classified with a TLU.


Linear separability

Linear Separability

x2

w1=?

w2=?

q= ?

w1=1

w2=1

q=1.5

0

1

0

1

x1

x1

1

0

0

0

Logical XOR

Logical AND


Threshold as weight

x1

x2

xn

Threshold as Weight

q=wn+1

1 if a 0

y =

0 if a<0

xn+1=-1

w1

wn+1

w2

y

.

.

.

a= i=1n+1 wi xi

wn

{


Geometric interpretation2

Geometric Interpretation

The relation w • x=0 defines the decision line

x2

Decision line

w

w•x=0

y=1

x1

y=0

x


Training anns

Training ANNs

  • Training set S of examples {x, t}

    • x is an input vector and

    • t the desired target vector

    • Example: Logical And

      S = {(0,0),0}, {(0,1),0}, {(1,0),0}, {(1,1),1}

  • Iterative process

    • Present a training example x , compute network output y, compare output y with target t, adjust weights and thresholds

  • Learning rule

    • Specifies how to change the weights w and thresholds q of the network as a function of the inputs x, output y and target t.


Adjusting the weight vector

Adjusting the Weight Vector

x

x

w’ = w + ax

j>90

ax

w

w

Target t=1

Output y=0

Move w in the direction of x

x

x

w

-ax

j<90

w

w’ = w - ax

Target t=0

Output y=1

Move w away from the direction of x


Perceptron learning rule

Perceptron Learning Rule

  • w’= w + a (t-y) x

    Or in components

  • w’i = wi + Dwi = wi + a (t-y) xi (i=1..n+1)

    With wn+1 = q and xn+1= –1

  • The parameter a is called the learning rate. It determines the magnitude of weight updates Dwi .

  • If the output is correct (t = y) the weights are not changed (Dwi =0).

  • If the output is incorrect (t  y) the weights wi are changed such that the output of the TLU for the new weights w’i is closer/further to the input xi.


Perceptron training algorithm

Perceptron Training Algorithm

repeat

for each training vector pair (x,t)

evaluate the output y when x is the input

if yt then

form a new weight vector w’ according

to w’=w + a (t-y) x

else

do nothing

end if

end for

until y=t for all training vector pairs


Perceptron convergence theorem

Perceptron Convergence Theorem

  • The algorithm converges to the correct classification

    • if the training data is linearly separable

    • and a is sufficiently small

  • If two classes of vectors X1 and X2 are linearly separable, the application of the perceptron training algorithm will eventually result in a weight vector w0, such that w0 defines a TLU whose decision hyper-plane separates X1 and X2 (Rosenblatt 1962).

  • Solution w0 is not unique, since if w0 x =0 defines a hyper-plane, so does w’0= k w0.


Example

Example

  • x1 x2 output

  • 1 1

  • 9.4 6.4 -1

  • 2.5 2.1 1

  • 8.0 7.7 -1

  • 0.5 2.2 1

  • 7.9 8.4 -1

  • 7.0 7.0 -1

  • 2.8 0.8 1

  • 1.2 3.0 1

  • 7.8 6.1 -1

Initial weights: (0.75, -0.5, -0.6)


Linear unit

x1

x2

xn

Linear Unit

inputs

weights

w1

output

activation

w2

y

.

.

.

y= a = i=1n wi xi

a=i=1n wi xi

wn


Gradient descent learning rule

Gradient Descent Learning Rule

  • Consider linear unit without threshold and continuous output o (not just –1,1)

    • 0 =w0 + w1 x1 + … + wn xn

  • Train the wi’s such that they minimize the squared error

    • e = aD (fa-da)2

      where D is the set of training examples

      Here fa is the actual output, da is the desired output.


Artificial neural networks notes based on nilsson and mitchell s machine learning

  • Gradient Descent rule:

  • We want to choose the weights wi so that e is minimized. Recall that

    e = aD (fa – da)2

    Since our goal is to work this error function for one input at a time, let us consider a fixed input x in D, and define

    e = (fx – dx)2

    We will drop the subscript and just write this as:

  • e = (f – d)2

  • Our goal is to find the weights that will minimize this expression.


Artificial neural networks notes based on nilsson and mitchell s machine learning

e/W= [e/w1,… e/wn+1]

Since s, the threshold function, is given by s = X . W, we have:

e/W = e/s*s/W. However, s/W = X. Thus,

e/W = e/s * X

Recall from the previous slide that e = (f – d)2

So, we have: e/s = 2(f – d)* f /s (note: d is constant)

This gives the expression:

e/W = 2(f – d)* f /s * X

A problem arises when dealing with TLU, namely f is not a continuous function of s.


Artificial neural networks notes based on nilsson and mitchell s machine learning

  • For a fixed input x, suppose the desired output is d, and the actual output is f, then the above expression becomes:

  • w= - 2(d – f) x

  • This is what is known as the Widrow-Hoff procedure, with 2 replaced by c:

  • The key idea is to move the weight vector along the gradient.

  • When will this converge to the correct weights?

  • We are assuming that the data is linearly separable.

  • We are also assuming that the desired output from the linear threshold gate is available for the training set.

  • Under these conditions, perceptron convergence theorem shows that the above procedure will converge to the correct weights after a finite number of iterations.


Neuron with sigmoid function

x1

x2

xn

Neuron with Sigmoid-Function

inputs

weights

w1

output

activation

w2

y

.

.

.

a=i=1n wi xi

wn

y=s(a) =1/(1+e-a)


Sigmoid unit

x1

x2

xn

Sigmoid Unit

x0=-1

w1

a=i=0n wi xi

w0

y=(a)=1/(1+e-a)

w2

y

.

.

.

(x) is the sigmoid function: 1/(1+e-x)

wn

d(x)/dx= (x) (1- (x))

Derive gradient descent rules to train:


Artificial neural networks notes based on nilsson and mitchell s machine learning

Sigmoid function

f

s


Gradient descent rule for sigmoid output function

Gradient Descent Rule for Sigmoid Output Function

s

sigmoid

Ep[w1,…,wn] = (tp-yp)2

Ep/wi = /wi (tp-yp)2

= /wi(tp- s(Si wi xip))2

= (tp-yp) s’(Si wi xip) (-xip)

for y=s(a) = 1/(1+e-a)

s’(a)= e-a/(1+e-a)2=s(a) (1-s(a))

a

s’

a

w’i= wi + wi = wi + a y(1-y)(tp-yp) xip


Presentation of training examples

Presentation of Training Examples

  • Presenting all training examples once to the ANN is called an epoch.

  • In incremental stochastic gradient descent training examples can be presented in

    • Fixed order (1,2,3…,M)

    • Randomly permutated order (5,2,7,…,3)

    • Completely random (4,1,7,1,5,4,……) (repetitions allowed arbitrarily)


Capabilities of threshold neurons

Capabilities of Threshold Neurons

  • The threshold neuron can realize any linearly separable function Rn  {0, 1}.

  • Although we only looked at two-dimensional input, our findings apply to any dimensionality n.

  • For example, for n = 3, our neuron can realize any function that divides the three-dimensional input space along a two-dimension plane.


Capabilities of threshold neurons1

Capabilities of Threshold Neurons

  • What do we do if we need a more complex function?

  • We can combinemultiple artificial neurons to form networks with increased capabilities.

  • For example, we can build a two-layer network with any number of neurons in the first layer giving input to a single neuron in the second layer.

  • The neuron in the second layer could, for example, implement an AND function.


Capabilities of threshold neurons2

  • o1

  • o1

  • o1

  • o2

  • o2

  • o2

  • oi

  • .

  • .

  • .

Capabilities of Threshold Neurons

  • What kind of function can such a network realize?


Capabilities of threshold neurons3

  • 2nd comp.

  • 1st comp.

Capabilities of Threshold Neurons

  • Assume that the dotted lines in the diagram represent the input-dividing lines implemented by the neurons in the first layer:

  • Then, for example, the second-layer neuron could output 1 if the input is within a polygon, and 0 otherwise.


Capabilities of threshold neurons4

Capabilities of Threshold Neurons

  • However, we still may want to implement functions that are more complex than that.

  • An obvious idea is to extend our network even further.

  • Let us build a network that has three layers, with arbitrary numbers of neurons in the first and second layers and one neuron in the third layer.

  • The first and second layers are completely connected, that is, each neuron in the first layer sends its output to every neuron in the second layer.


Capabilities of threshold neurons5

  • o1

  • o1

  • o1

  • o2

  • o2

  • o2

  • oi

  • .

  • .

  • .

  • .

  • .

  • .

Capabilities of Threshold Neurons

  • What type of function can a three-layer network realize?


Capabilities of threshold neurons6

  • 2nd comp.

  • 1st comp.

Capabilities of Threshold Neurons

  • Assume that the polygons in the diagram indicate the input regions for which each of the second-layer neurons yields output 1:

  • Then, for example, the third-layer neuron could output 1 if the input is within any of the polygons, and 0 otherwise.


Capabilities of threshold neurons7

Capabilities of Threshold Neurons

  • The more neurons there are in the first layer, the more vertices can the polygons have.

  • With a sufficient number of first-layer neurons, the polygons can approximate any given shape.

  • The more neurons there are in the second layer, the more of these polygons can be combined to form the output function of the network.

  • With a sufficient number of neurons and appropriate weight vectors wi, a three-layer network of threshold neurons can realize any function Rn  {0, 1}.


Terminology

Terminology

  • Usually, we draw neural networks in such a way that the input enters at the bottom and the output is generated at the top.

  • Arrows indicate the direction of data flow.

  • The first layer, termed input layer, just contains the input vector and does not perform any computations.

  • The second layer, termed hidden layer, receives input from the input layer and sends its output to the output layer.

  • After applying their activation function, the neurons in the output layer contain the output vector.


Terminology1

Terminology

  • output vector

  • output layer

  • Example:Network function f: R3  {0, 1}2

  • hidden layer

  • input layer

  • input vector


Multi layer networks

Multi-Layer Networks

output layer

hidden layer

input layer


Training rule for weights to the output layer

Training-Rule for Weights to the Output Layer

Ep[wij] = ½ j (tjp-yjp)2

yj

Ep/wij = /wij ½ Sj (tjp-yjp)2

= …

= - yjp(1-ypj)(tpj-ypj) xip

wji

xi

wij = a yjp(1-yjp) (tpj-yjp) xip

= adjp xip

with djp := yjp(1-yjp) (tpj-yjp)


Training rule for weights to the hidden layer

Training-Rule for Weights to the Hidden Layer

yj

Credit assignment problem:

No target values t for hidden layer units.

dj

wjk

xk

Error for hidden units?

dk

dk = Sj wjkdj yj (1-yj)

wki

wki = a xkp(1-xkp) dkp xip

xi


Training rule for weights to the hidden layer1

Training-Rule for Weights to the Hidden Layer

yj

Ep[wki] = ½ j (tjp-yjp)2

dj

wjk

Ep/wki = /wki ½ Sj (tjp-yjp)2

=/wki ½Sj (tjp-s(Skwjk xkp))2

=/wki ½Sj (tjp-s(Skwjks(Siwki xip)))2

= -j (tjp-yjp) s’j(a) wjks’k(a) xip

= -jdj wjks’k(a) xip

= -jdj wjk xk (1-xk) xip

xk

dk

wki

xi

wki = adk xip

withdk = jdj wjkxk(1-xk)


Backpropagation

Backpropagation

Backward step:

propagate errors from output to hidden layer

yj

dj

wjk

xk

dk

wki

Forward step:

Propagate activation

from input to output layer

xi


Backpropagation algorithm

Backpropagation Algorithm

  • Initialize weights wij with a small random value

  • repeat

    for each training pair {(x1,…xn)p,(t1,...,tm)p} Do

    • Present (x1,…,xn)p to the network and compute the outputs yj (forward step)

    • Compute the errors dj in the output layer and propagate them to the hidden layer (backward step)

    • Update the weights in both layers according to

      wki = adk xi

      end for loop

      until overall error E becomes acceptably low


Backpropagation algorithm1

Backpropagation Algorithm

  • Initialize each wi to some small random value

  • Until the termination condition is met, Do

    • For each training example <(x1,…xn),t> Do

      • Input the instance (x1,…,xn) to the network and compute the network outputs yk

      • For each output unit k

        • k=yk(1-yk)(tk-yk)

      • For each hidden unit h

        • h=yh(1-yh) k wh,k k

      • For each network weight wi,j Do

      • wi,j=wi,j+wi,j where

        wi,j=  j xi,j


Backpropagation1

Backpropagation

  • Gradient descent over entire network weight vector

  • Easily generalized to arbitrary directed graphs

  • Will find a local, not necessarily global error minimum

    -in practice often works well (can be invoked multiple times with different initial weights)

  • Often include weight momentum term

    wi,j(n)=  j xi,j +  wi,j (n-1)

  • Minimizes error training examples

    • Will it generalize well to unseen instances (over-fitting)?

  • Training can be slow typical 1000-10000 iterations

    (Using network after training is fast)


Backpropagation2

Backpropagation

  • Easily generalized to arbitrary directed graphs without clear layers.

  • BP finds a local, not necessarily global error minimum

    - in practice often works well (can be invoked multiple times with different initial weights)

  • Minimizes error over training examples

    • How does it generalize to unseen instances ?

  • Training can be slow typical 1000-10000 iterations

    (use more efficient optimization methods than gradient descent)

  • Using network after training is fast


Convergence of backprop

Convergence of Backprop

Gradient descent to some local minimum perhaps not global minimum

  • Add momentum term: wki(n)

    • wki(n) = adk(n) xi (n) + l Dwki(n-1)

      with l [0,1]

  • Stochastic gradient descent

  • Train multiple nets with different initial weights

    Nature of convergence

  • Initialize weights near zero

  • Therefore, initial networks near-linear

  • Increasingly non-linear functions possible as training progresses


Expressive capabilities of ann

Expressive Capabilities of ANN

Boolean functions

  • Every boolean function can be represented by network with single hidden layer

  • But might require exponential (in number of inputs) hidden units

    Continuous functions

  • Every bounded continuous function can be approximated with arbitrarily small error, by network with one hidden layer [Cybenko 1989, Hornik 1989]

  • Any function can be approximated to arbitrary accuracy by a network with two hidden layers [Cybenko 1988]


  • Login
