Xilinx FPGA Board. MB-EVL-X2S200A-V10. Microblaze Software CPU 發展板 32 位元處理器的發展平台 提供 EDK 發展工具的應用例子 FPGA 包含 200K Gate Count 邏輯閘 128 x 64 pixel 液晶顯示螢幕 RS232 介面供串列傳輸與偵錯之用 4 個 DIP Switch 與 8 個 LED 介面 單一電源 (+5V/3A) 輸入 PROM 插座 (Optional) 64kBytes 的外部記憶體介面 JTAG 介面 , 方便使用者重新規劃內容

vaughan
Download Presentation

Xilinx FPGA Board

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Xilinx FPGA Board

  2. MB-EVL-X2S200A-V10 • Microblaze Software CPU發展板 • 32位元處理器的發展平台 • 提供EDK發展工具的應用例子 • FPGA包含200K Gate Count邏輯閘 • 128 x 64 pixel 液晶顯示螢幕 • RS232 介面供串列傳輸與偵錯之用 • 4個DIP Switch與8個LED介面 • 單一電源(+5V/3A)輸入 • PROM插座(Optional) • 64kBytes的外部記憶體介面 • JTAG介面,方便使用者重新規劃內容 • 2個Liner_Driver與Line Receiver介面 • 4個+24V輸入與4個+24V輸出的介面 • 萬用板設計，方便使用者增加電路 • 板子尺寸:160mm x 130mm

  3. MB-EVL-X2S200A-V10

  4. Project Setting • Set project properties as the following window

  5. Pin Assignment
