Rain Drop Detection Sensor Module

A rain sensor module is an easy tool for rain detection. It can be used as a switch when a raindrop falls through the raining board or for measuring rainfall intensity. The module features, a rain board and a control board that is separate for more convenience.

tomsonelectronics
Download Presentation

Rain Drop Detection Sensor Module

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. ADIY Rain Drop Detection Sensor Module

  2. ADIY Rain Drop Detection Sensor Module A rain sensor module is an easy tool for rain detection. It can be used as a switch when a raindrop falls through the raining board or for measuring rainfall intensity. The module features, a rain board and a control board that is separate for more convenience, power indicator LED and an adjustable sensitivity through a potentiometer.

  3. ADIY Rain Drop Detection Sensor Module The analog output is used in the detection of drops in the amount of rainfall. Connected to a 5V power supply, the LED will turn on when induction board has no raindrop, and DO output is high. When dropping a little amount water, DO output is low, the switch indicator will turn on. Brush off the water droplets, and when restored to the initial state, outputs high level.

  4. ADIY Rain Drop Detection Sensor Module It includes a printed circuit board (control board) that collects the raindrops. As raindrops are collected on the circuit board, they create paths of parallel resistance that are measured via the op-amp. The lower the resistance (or the more water), the lower the voltage output. Conversely, the less water, the greater the output voltage on the analog pin. A completely dry board, for example, will cause the module to output 5V.

  5. +91 86066 50999 www.tomsonelectronics.com
