  1. SCOTIA Middle East Limited. Tracking Vehicles/Handset Throughout Nigeria Presentation.

  2. Agenda • Scotia Client Base • Technical Description of Vehicle Tracking. • Technical Operations through our IP Server. • Service Options/ Features • Quotation / Proposal. • Any Other Questions.

  3. “Scotia Client Base – Experience”

  4. Login Page to track your vehicles, devices. Username: online Password: online Use the demo username and password to see online demo. Login and track the demo vehicles and access reports for the same. Please go through next slide for complete description of Dashboard.

  5. New Dashboard For GPS Integrated Menu Options for user To Make the system User-Friendly Menus are provided. User can himself manage the settings and make use of menus provided on Dashboard.

  6. New Dashboard of GPS Integrated Dashboard gives you and general description and activity of vehicle. Complete identification like Vehicle Name, Device ID, GSM number of device, Max Speed of vehicle, distance and time taken, stationary hours of vehicle and average speed of vehicle for day is described here. You will get tool tip once you move your cursor on the particular area New Features like Vehicle servicing, Vehicle tyre change will be introduced soon for fleet Owners

  7. Max Speed, Motion Hours, distance travelled, average speed and stationary hours of vehicle shown. GSM number and Device Number (MEI) Active Vehicle Last updated status of vehicle displayed on Dashboard Reports Section Inactive Vehicle New Features LOW battery Alerts GPS Availability status Over Speed Alerts Geo-Fencing Alerts SOS Alerts

  8. Tracking can be classified as below. 1. Web Based Tracking. 2. Desktop Based Tracking. 3. Status On Maps 3. Handset Based Tracking • Web Based tracking : Click on Google Map or Virtual Earth and will respectively open new window and can see the track sin terms of balloons in GMap and Pin point in Virtual Earth Maps. Can be done using Google maps and Virtual earth Maps. Both the options are provided on Dashboard. • Desktop Based tracking: In desktop based tracking two options are provided Live Tracking and BETA. Both options will download a .kml file and open with Google earth, LIVE Tracking provides you complete log history of the vehicle starting from start of Vehicle till last update of the vehicle. The display rate for this is after every 3-5 minutes. Last Status: In Beta you will only get the last status of Vehicle and wont get all the previous logs. Display rate for the same is after every 30 secs and can see the vehicle icon moving on Maps after every 30 secs. 3.Status on Maps: this will display all the vehicles in single window. This is type of WAP enabled service and display will be same on Cell phones too. • Handset Based Tracking: Handset based tracking can be done in two types. WAP enabled and Graphical tracking. In WAP enabled services you will get last status of vehicle with date, location ,device ID, speed and Motion for more information logon to the link provider http://info.gpsintegrated.com/support/cellphone/wap-browsing/ Graphical Tracking: Maps needs to be installed on your handset, Google maps are freely downloadable and can track vehicles on maps. For more information go through the link provided http://info.gpsintegrated.com/support/cellphone/maps-on-cellphone/tracking-on-handset

  9. 1. Web Based tracking : Click on Google Map or Virtual Earth and will respectively open new window and can see the track sin terms of balloons in Google Map and Pin point in Virtual Earth Maps. Can be done using Google maps and Virtual earth Maps. Both the options are provided on Dashboard Click on Google Map, New window will be opened with logs in terms of balloon on Google Maps. Please refer the next slide for the same. Click on Virtual Earth, New window will be opened with logs in terms of PINPOINT on VE Maps. Please refer the next slide for the same.

  10. For tracking please go through the document below. Click on Live tracking, window will pop up, save the file and open with Google earth same can be repeated with Last Status to get last updated status of vehicle on Google Earth Once this window appears save the file to your system and open with Google earth

  11. Status On Maps • Scotia has launched new service to track your all vehicles in single window. This feature give you last updated status of all your vehicles and will display the same on single window. . Click on status on Maps and get all your vehicles last update on single window

  12. Status on Map. Once clicked on Status on Maps New Window will open which shows Last status of all devices registered in your account

  13. Email Alerts All generated Alerts will be mailed to user on mail ids and will be as below Low Battery Alert SOS Alert Geo Fencing IN Alert Geo Fencing OUT Alert

  14. Scotia Client Base… • UK British Foreign and Commonwealth Office ( FCO ) – Basra / Baghdad, Iraq. • Kyrgyz Republic Emergency Services. • Restoration of Emergency Services ( thro FCO / DFID ) • Pakistan Restoration Emergency Services after Earthquake Oct 2005. • Setting up ERRC to ensure Transparency for Donators. • Setting up Emergency Telecommunications in Northern Pakistan. • USA Department of State, Washington / Baghdad Embassy. - Setting up High Tech Security / Telecom Systems. • Oil Companies Shell / Chevron / Mobil / Texaco / Agip / Conoco Phillips. • Oil Service Companies Schlumberger / Intel / Willbros / African Oil Field Services / Weatherford / Dredger International. • Nigerian Government Projects PTF / NCC / NDDC / Niger Delta States / Alscon / Asferro / Le Meridien Hotel Uyo. • Airlines Lufthansa / United Airlines.

  15. Technical Description of Vehicle Tracking.

  16. Technical Description of Vehicle Tracking.

  17. Technical Operations through our IP Server. GPS Satellites GPS Signal Communications Satellite GSM Network Satellite Ground Station Air Interface Transferring GSM/GPRS Data Mobile Monitoring Anywhere with internet connection Internet Internet Internet SecureLocate Servers Dedicated Control Centre Monitored 24/7 Client Control Centre

  18. Service Features • Successive Locating Automatically • Voice Surveillance: subscriber can listen to conversation inside the vehicle remotely • Alert function – (low battery alert, power off alert, SOS, Geo-fence, movement alert, Over speed alert) • Switch off the Vehicle Engine Remotely via SMS • Door alarm, Sensor Alarm, ACC Alarm • Get Vehicle location on map or via sms with street address

  19. Tracking Service Options • Tracking Service Options: Realtime Monitoring: Our real-time monitoring service options updates the vehicle or asset location to our remote servers at preset time intervals. Users can log on to see vehicle locations and time. On Demand Monitoring: Using our on-demand service, subscribers cannot see a log of vehicle activities. But they can request vehicle location anytime they want via their mobile phones. On Demand with Street Addressing on Mobile Phone: This service add on provides real street address to subscribers mobile phone. Eg. Along Olu Obasanjo road, near Mr Biggs fast food, Rivers State, Nigeria.

  20. Tracking Control Center Setup.

  21. Realtime/On Demand Vehicle Tracking – Hardware & Software. Tracking Device Per Vehicle US$ • Tracking Device Installation Per Vehicle US$ • One Year Renewable Support. US$ • GPRS Monthly Charge. US$ OPTION 1: YOUR OWN CONTROL CENTRE:- System Design & Equipment Procurement RS232 MODEM Routers, Firewall, 12 Port Switch Deep Freeze Network Application Complete GPS Map for Nigeria with at least 10,000 landmarks TnS GPS Tracking Software License Pentium 4, 1Gb Ram, 120GB HDD, servers with database backup 17 inch LCD screen for monitoring Data base application license and server OS 1YR unlimited support US$ OPTION 2 USER TRAINING:- 1 Day Training Clients Staff US$

  22. Realtime/On Demand Mobile Phone Tracking – Hardware & Software. Nokia Phones or All Blackberry Models Mobile Tracking Application License U$ Mobile Tracking Software Installation US$ Mobile Tracking1YR unlimited support US$ Mobile Tracking GPRS / Monthly Charges ( Paid Annually ) US$ Note: Above cost does not include GSM Handset acquisition cost ? Handset to be provided by client ? If Requested we can provide ?

  23. Any Questions.
