Presentation Transcript
slide1

How to create a…

Lewis Dot Structure

…for CH4

  • #1 Count the total number of valence electrons in the molecule
  • C: 4 electrons x 1 atom = 4 valence electrons
  • H: 1 electron x 4 atoms = 4 valence electrons
                  • Total = 8 valence electrons
slide2

How to create a…

Lewis Dot Structure

…for CH4

  • #2 Find the number of “octet” electrons for the molecule.
  • C: 8 octet electrons x 1 atom = 8 octet electrons
  • H: 2 octet electrons x 4 atoms = 8 octet electrons
                  • Total = 16 octet electrons
                  • Rules: Hydrogen always has 2 octet electrons
                  • Beryllium always has 4 octet electrons
                  • Boron wants 6 for neutral molecules (8 if it’s an anion)
slide3

How to create a…

Lewis Dot Structure

…for CH4

#3 Subtract the number of valence electrons from the number of octet electrons to find the number of bonding electrons.

16 – 8 = 8 bonding electrons

slide4

How to create a…

Lewis Dot Structure

…for CH4

  • #4 Divide the number of bonding electrons by 2 to find the number of bonds in the molecule.
  • 8 / 2 = 4 bonds in CH4
                  • Why 2?
                  • Because there are two electrons in every covalent bond!
slide5

How to create a…

Lewis Dot Structure

…for CH4

#5 Draw an arrangement of atoms that has the number of bonds you found in step 4. Of course, there are more rules…

Hydrogen and Halogens = bond once!

Oxygen’s family and Beryllium bond twice in neutral molecules

Nitrogen’s family and Boron bond 3 times in neutral molecules

Carbon’s family = bonds 4 times!

slide6

How to create a…

Lewis Dot Structure

…for CH4

More hints…

If you bond everything together and you have bonds left over, look for double/triple bonds.

The atom nearest to the left side of the periodic table is probably in the middle of the molecule.
