Medical device engineering

Medical Device Engineering

Jim Niederjohn

April 2, 2014


Purpose

Purpose

  • Discuss the role that engineers play in the medical device industry


Agenda

Agenda

  • Jim’s Background

    • Education

    • Career History

    • Medical Devices & Projects

  • Medical Device Engineering

    • Engineering Roles & Responsibilities

    • How to develop and release a medical device to market

  • Advice

    • Career

    • College

  • Questions


Who s jim

Who’s Jim?

  • Moved to Newark, CA in 1984

  • Graduated from Newark Memorial High School in 1990

  • Graduated from CSU Chico in 1994

    • BS Mechanical Engineering

  • Graduated from Santa Clara University in 2000

    • MBA


What is a medical device

What is a medical device?

A *medical deviceis "an instrument, apparatus, implement, machine, contrivance, implant, in vitro reagent, or other similar or related article, including a component part, or accessory which is:

  • recognized in the official National Formulary, or the United States Pharmacopoeia, or any supplement to them,

  • intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or prevention of disease, in man or other animals, or

  • intended to affect the structure or any function of the body of man or other animals, and which does not achieve any of its primary intended purposes through chemical action within or on the body of man or other animals and which is not dependent upon being metabolized for the achievement of any of its primary intended purposes."

*http://www.fda.gov/aboutfda/transparency/basics/ucm211822.htm


Career history

Career History

CRYOVASCULAR SYSTEMS

Startup

Acquisition

Acquisition

Big company


Medical device engineering

  • Manufacturing Engineer (1994 – 1998)

    • Support all activities related to building product

    • Make sure that the production line is meeting throughput and yield goals

    • Skills developed

      • Product assembly knowledge

      • Problem solving / troubleshooting – root cause analysis

      • Fixture Design

      • Process Development & Optimization

      • Design of Experiments (DOE)

      • Manufacturing Documentation

      • Engineering Change Orders (ECO)

      • Product non-conformities and dispositioning

      • Protocol and report writing


Medical device engineering

  • R&D Project Engineer (1998 – 2001)

    • Perform development activities to release products to market

    • Skills developed

      • Component design

      • Injection molding familiarity

      • Project planning / Schedule development

      • Coordination of activities with other team members

      • Product Qualification familiarity

        • Biocompatibility testing

        • Sterilization Validation

        • Design Verification (DV) testing

        • Accelerated Aging DV testing

        • Design Validation testing

        • Manufacturing Process Validations

        • Packaging Validation

      • Regulatory requirements for gaining approval


Medical device engineering

  • R&D Manager (2001 –2003)

    • Project Manager responsible for releasing products to market

    • Supervise team of R&D engineers & technicians

    • Lead team of cross functional resources

    • Skills developed

      • General Project Management

        • Getting “buy in” on decisions

        • Setting expectations when working with others

        • Holding individuals accountable

      • Developing (Coaching & mentoring) team


Medical device engineering

CRYOVASCULAR SYSTEMS

  • Manufacturing / Project Manager (2003 –2007)

    • Production supervisor responsible for achieving manufacturing goals

    • Supervise production operators and mfg. engineers

    • Oversee development of Next Generation Device

  • Process Development Manager (2007 – 2009)

    • Manage team of process development engineers and technicians

      • Develop manufacturing processes for new products

      • Perform all manufacturing deliverables to qualify device


Medical device engineering

  • R&D Manager (2009 – present)

    • Manage team of R&D Engineers and technicians

      • Develop and release new products to market

    • Employee Career Development

    • Skills developed

      • Design For Manufacturability

      • Larger scale program management

      • Strategic level planning for product pipeline


Medical devices projects

Medical Devices & Projects


Medical devices

Medical Devices

  • “Off Pump” Coronary Artery Bypass (OPCAB) Grafting – Minimally Invasive approach


Off pump cabg devices

“Off Pump” CABG Devices

Stabilizer

Blower / Mister

Xpose

Coronary Shunt


Medical devices1

Medical Devices

  • Cryoplasty Catheter

    • “Cooling therapy” treatment for blocked leg arteries

  • RF Ablation Catheter

    • Treatment to destroy small areas of heart tissue to prevent abnormal heartbeats


Medical devices2

Medical Devices

  • UROLIFT System

    • Deliver implant(s) to relieve prostate obstruction and open the urethra directly by retracting the obstructing prostatic lobes


Medical devices3

Medical Devices

  • MitraClip – Percutaneous mitral valve repair

    • Treatment of Mitral Regurgitation (MR) - blood flows backward from the heart’s left ventricle to the right ventricle


Medical devices4

Medical Devices

  • MitraClip System

MitraClip


Engineering roles

Engineering Roles


Engineering roles responsibilities

Engineering Roles / Responsibilities

  • Research & Development Engineer

  • Research: Identify a clinical need and evaluate concepts to meet need

  • Development: Develop a concept into a device and release to market

    • Solid modeling (CAD) to design parts

    • Build & test prototypes

    • Interfacing with customers (physicians)

    • Solving technical issues

    • Qualification testing of product

  • Sustaining: Run the business design changes to existing products

    • Corrective and Preventive Action (CAPA) projects

    • Same as Development (above)

  • Manufacturing Engineer

  • Sustaining: Support manufacturing line to achieve throughput and yield goals

    • Address manufacturing line down issues

    • Continuous improvement projects to reduce costs (improve cycle time, reduce # of rejects, etc.) & improve reliability

  • New product support: Develop manufacturing processes to support new product development

    • Fixture & equipment design

    • Process capability studies / DOE’s

    • Qualification testing of processes

    • Developing manufacturing documentation


Engineering roles responsibilities1

Engineering Roles / Responsibilities

  • Quality Engineer

  • Sustaining: Audit and monitor the quality of product built to ensure that it is meeting the customer’s expectations and all the internal requirements

    • Address non-conformities with components and assemblies (incoming inspection & production)

    • Monitor product performance based on complaint analysis

    • Corrective and Preventive Action (CAPA) projects

    • Support audits by regulatory bodies

  • Projects / New Products: support development teams who are making design / process changes

    • Compliance to internal procedures for making changes

    • Risk Management / Failure Mode Effects Analysis

  • Supplier Quality Engineer

  • Sustaining: Audit and monitor supplier performance and ensure that they have capable processes that produce components that meet all the requirements

    • Address line down issues related to component issues

    • Perform supplier audits

  • Projects / New Products: Develop and qualify suppliers for design changes / new products

    • Develop robust and capable inspection methods

    • Supplier capability assessments

    • Qualification testing of supplier processes


Engineering roles responsibilities2

Engineering Roles / Responsibilities

  • Project Manager

  • Manage activities to achieve program goals

    • Develop and execute on project plans to achieve project timeline

    • Facilitate cross functional team activities

    • Manage high risk activities related to the project and develop plans to address

    • Communicate project status to management


New product development process

New Product Development Process


How do you release a medical device to market

How do you release a medical device to market?

  • 5 Design Control Phases

    • “PASS” gates to move on to the next phase


Advice

Advice


Career advice how to succeed

Career Advice – How to succeed

Early Years (1st couple of years out of school)

  • Be a sponge – learn as much as you can!

  • Set daily / weekly goals for yourself (i.e. complete task X by Friday) & prioritize based on importance

  • Put your personal life “on hold” when you are working

  • Be clear on your manager’s expectations and understand what is important to him/her

  • Be pro-active and do more than what is expected

  • Develop good working relations with the team you are working with

  • Find a mentor (engineer) and meet semi-regularly to get input and feedback

  • Don’t be afraid to make a mistake… you’ll learn from it

  • Force yourself to do the things that are hard for you

  • Find out what you really like to do


Career advice how to succeed1

College

Career Advice – How to succeed

College

Early Years (1st couple of years out of school)

  • Be a sponge – learn as much as you can!

  • Set daily / weekly goals for yourself (i.e. complete task X by Friday) & prioritize based on importance – attend classes, complete assignments on time

  • Put your personal life “on hold” when you are working on school projects

  • Be clear on your manager’s expectations and understand what is important to him/heryou

  • Be pro-active and do more than what is expected

  • Develop good working relations with the team you are working with

  • Find a mentor (engineer) and meet semi-regularly to get input and feedback

  • Don’t be afraid to make a mistake… you’ll learn from it

  • Force yourself to do the things that are hard for you

  • Find out what you really like to do

  • Do homework and assignments with a team of 3 to 4 people

  • Go to your professor’s office hours

  • Enjoy the college experience!

your classmates

professor


Questions

Questions
