  1. Using two recently-developed molecular dynamics protocols for protein folding Timothy H. Click Department of Chemistry and Biochemistry University of Oklahoma Norman, Oklahoma

  2. Outline • Introduction to MD protocols • Previous work • Simulations of tryptophan zipper 2 • Simulation of Streptococcal protein G B1 domain (residues 41-56) • Conclusions • Future directions • Acknowledgements

  3. Protein geometry optimization Dill, K.A.; Chan, H.S. Nat. Struct. Biol., 1997, 4, 10-19.

  4. 1st MD protocol — DIVE • Disrupted Velocity (DIVE) search protocol • Velocity reassignment of coordinate histories • Magnitude rescaling — energy perturbation • Direction changes • Reassignment every n steps (defined by user) • Heating and cooling cycles • Conformations sampled near absolute zero • Overall, protocol disrupts equilibrium • Energy barriers overcome or circumvented • Several potential energy minima sampled

  5. How conformations are selected β βlow to DIP βlow βlow2 to DIP

  6. 2nd MD protocol — DIP • Divergent Path (DIP) search strategy • Coordinate histories at same constant temperature • Simulations involve multiple coordinate histories • Individual coordinate histories randomly assigned initial velocities • Velocities can be altered allowing for different conditions • Constant temperatures maintained by rescaling velocity magnitudes • Broader sampling of potential energy surface allowed

  7. DIP simulation

  8. DIP simulation (cont’d) <E>= -624.22 ± 8.27 kcal/mol <RMSD> = 1.6 ± 0.5 Å <E>= -632.42 ± 8.44 kcal/mol <RMSD> = 1.8 ± 0.2 Å <E>= -587.16 ± 9.50 kcal/mol <RMSD> = 13.2 ± 0.5 Å <E>= -633.94 ± 7.87 kcal/mol <RMSD>= 1.5 ± 0.2 Å nmr <E>= -592.02 ± 8.38 kcal/mol <RMSD> = 12.5 ± 0.5 Å <E>= -600.29 ± 13.05 kcal/mol <RMSD> = 11.3 ± 0.7 Å

  9. Protocol procedures • Modified Amber force field (Okur,A.; Strockbine, B.; Hornak, V.; Simmerling, C., J. Comput. Chem., 2003, 21) • Constraints on atoms covalently bonded to hydrogen • Implicit solvent • 2 fs time step • 4,000,000 steps • Velocity disruption every 20,000 steps (DIVE) • T = 300 ± 20 K (DIP) • 6 independent coordinate histories/simulation

  10. Previous work with α-helices • Zunnan Huang • 13-residue polyalanine • Trp-cage (α-helix and 310-helix • Huang and Zhanyong Guo • Peptide F • Timothy H. Click • C-peptide of ribonuclease A (residues 1-13)

  11. Tryptophan zipper 2 (trpzip2) • De novo 12-residue polypeptide • Sequence (S1WTWENGKWTWK12-NH2) • PDB code 1LE1 (20 NMR models) • Stable β-sheet in aqueous solution by cross-stranded pairs of four tryptophans • Simulations completed by other groups 1 Cochran, A.G.; Skelton, N.J.; Starovasnik, M.A. P. Natl. Acad. Sci. USA, 2001, 98, 5578-5583.

  12. Trpzip2 DIVE Results extlow E = -496.59 kcal/mol RMSD 6.9 Ẳ βlow E = -494.05 kcal/mol RMSD 5.0 Ẳ αlow E = -498.22 kcal/mol RMSD 6.1 Ẳ β* E = -489.44 kcal/mol RMSD 0.9 Ẳ extlow2 E = -499.23 kcal/mol RMSD 7.0 Ẳ βlow2 E = -497.06 kcal/mol RMSD 5.7 Ẳ αlow2 E = -498.17 kcal/mol RMSD 6.1 Ẳ

  13. Trpzip2 DIP Results ext <E> = -360.82 ± 7.66 kcal/mol <RMSD> 6.5 ± 0.8 Ẳ β <E> = -381.65 ± 4.55 kcal/mol <RMSD> 0.9 ± 0.1 Ẳ α <E> = -369.79 ± 9.01 kcal/mol <RMSD> 6.7 ± 0.4 Ẳ extlow <E> = -375.47 ± 6.28 kcal/mol <RMSD> 7.5 ± 0.1 Ẳ βlow <E> = -374.14 ± 7.18 kcal/mol <RMSD> 7.0 ± 0.3 Ẳ αlow <E> = -368.77 ± 7.38 kcal/mol <RMSD> 6.1 ± 0.1 Ẳ β* <E> = -381.65 ± 5.04 kcal/mol <RMSD> 0.8 ± 0.1 Ẳ extlow2 <E> = -381.44 ± 5.74 kcal/mol <RMSD> 7.4 ± 0.1 Ẳ βlow2 <E> = -378.75 ± 6.04 kcal/mol <RMSD> 7.0 ± 0.3 Ẳ αlow2 <E> = -368.93 ± 7.54 kcal/mol <RMSD> 6.2 ± 0.3 Ẳ

  14. Trpzip2 Summary • PES rough at low temperatures • β-hairpin challenging secondary structure • β-hairpin as relative global PE conformation • α-helices metastable conformation

  15. B1 domain of Streptococcal protein G • Natural β-hairpin stable in aqueous solution. • Sequence (G41EWTYDDATKTFTVTE56) • PDB 2GB1 (x-ray crystal structure) • Stabilization factors • Hydrophobic core • Terminal salt bridge • Several simulations 2 Gronenborn, A. M.; Filpula, D. R.; Essig, N. Z.; Achari, A.; Whitlow, M.; Wingfield, P. T.; Clore, G. M. Science, 1991, 253, 657-661.

  16. Protein G DIVE results extlow E = -784.40 kcal/mol RMSD 7.4 Ẳ βlow E = -774.96 kcal/mol RMSD 6.8 Ẳ αlow E = -783.53 kcal/mol RMSD 8.4 Ẳ β* E = -770.54 kcal/mol RMSD 0.9 Ẳ extlow2 E = -785.85 kcal/mol RMSD 7.3 Ẳ βlow2 E = -781.75 kcal/mol RMSD 6.4 Ẳ αlow2 E = -785.64 kcal/mol RMSD 8.4 Ẳ

  17. Protein G DIP results ext <E> = -612.63 ± 9.31 kcal/mol <RMSD> 10.6 ± 0.6 Ẳ β <E> = -638.42 ± 5.84 kcal/mol <RMSD> 1.6 ± 0.4 Ẳ α <E> = -646.18 ± 6.90 kcal/mol <RMSD> 8.9 ± 0.2 Ẳ extlow <E> = -640.60 ± 7.13 kcal/mol <RMSD> 9.1 ± 0.3 Ẳ βlow <E> = -651.05 ± 6.34 kcal/mol <RMSD> 6.9 ± 1.2 Ẳ αlow <E> = -646.14 ± 6.01 kcal/mol <RMSD> 9.0 ± 0.3 Ẳ β* <E> = -644.28 ± 6.08 kcal/mol <RMSD> 1.6 ± 0.2 Ẳ extlow2 <E> = -633.74 ± 7.13 kcal/mol <RMSD> 9.0 ± 0.7 Ẳ βlow2 <E> = -643.91 ± 7.86 kcal/mol <RMSD> 9.0 ± 0.3 Ẳ αlow2 <E> = -650.14 ± 6.33 kcal/mol <RMSD> 9.0 ± 0.2 Ẳ

  18. Protein G summary • β-hairpin stable at 300 K • Helical conformation lower in energy • Better energy compensation3 • Agreement with other simulation4 • Various factors may overstabilize helices (e.g., implicit solvent, salt bridges) 3 Muñoz, V.; Thompson, P. A.; Hofrichter, J.; Eaton, W. A. Nature, 1997, 390, 196-199. 4 Krivov, S. V.; Karplus, M. P. Natl. Acad. Sci., USA, 2004, 101, 14766-14770.

  19. Conclusions • DIVE and DIP locate several PE minima • PES mapped by DIVE • PES of conformations at desired temperature with DIP • Conformations in good, if not excellent, agreement with experimental structures using DIP and DIVE

  20. Future directions • Continue validation of MD protocols with larger β-sheet • Further test MD protocols with tertiary structure • Predict structure of small protein

  21. Acknowledgements • Ralph A. Wheeler • Zunnan Huang and Adam Hixson • National Research Service Award 5 F31 GM067560-03 to THC from the NIH/NIGMS • Oklahoma Center for the Advancement of Science and Technology (OCAST) HR01-148 • Oklahoma Supercomputing Center for Education and Research (OSCER) • NSF/NRAC supercomputer time MCA96-N019
