Sheila porter intel ireland

PowerPoint Presentation III

Making Machines and Observing Functionality

Sheila Porter

Intel Ireland


Sheila porter intel ireland

Session 6: Making Machines

  • Understanding the session:

  • Exploration of the mechanics of simple machines

  • Practical based lesson in which the student builds different types of “toys” using basic mechanics

The session is broken down into 3 sections

Section A: Design, Build, & Make It Go

Section B: Gears, Cranks, Crankshafts and Belts

Section C: Using Motors to Produce Motion


Sheila porter intel ireland

Activity 5A: Rolling Kit

Goal: To allow students to become more familiar with the ideas behind basic mechanics, how energy can be stored, transferred and transformed.

Outcome: Make a “Rolling toy which can travel 1-1.5 metres as an introduction to mechanical engineering.

Preparation: To do this you will need “One Rolling Kit” per student

Materials required (“Rolling Kit”):

1 film canister with lid, with holes (8mm – 10mm Ø) drilled in both ends

2 Rubber bands (6.5cm)

2 small washers

1 piece of thick drinking straw

Session 6, Activity A


Sheila porter intel ireland

Rolling Toy Video

Building the Rolling Toy

See Design and Discovery Website - Resources

Note: If film canisters are unavailable use empty coke cans


Sheila porter intel ireland

Gears, Cranks, Crankshafts & Belts

  • Students

  • Are introduced to the concepts of mechanical engineering

  • explore the mechanics of simple machines and learn that most mechanical devices are really a set of simple machines working together

  • learn how machine action can be transferred or change direction by experimenting with gears, wheels and belts, and crankshafts

Crankshaft


Sheila porter intel ireland

Crankshaft Toy Video

Example of a Crankshaft Toy

See Design and Discovery Website - Resources


Sheila porter intel ireland

  • Materials

  • Small milk carton

  • 3 pieces of

  • 16-gauge steel wire

  • - 1 x 20cm long

  • - 2 x 7cm long

  • 1 straw

  • Insulating tape for crank handle

  • Needle nose pliers


The session ends with the students building a wacky racer

The Session ends with the students building a Wacky Racer

Can you build a Wacky Racer?


Sheila porter intel ireland

Ireland

Education
