  1. The Theory OF Flight Chapter 2

  2. Heavier-than-air flight is made possible by a careful balance of four physical forces: lift, drag, weight, and thrust. For flight, an aircraft's lift must balance its weight, and its thrust must exceed its drag. A plane uses its wings for lift and its engines for thrust. Drag is reduced by a plane's smooth shape and its weight is controlled by the materials it is constructed of (Aluminum, titanium, wood, etc. ).

  3. Bernoulli’s Principle

  4. Airfoil Design

  5. Airfoils In Action Would more lift be provided by a fluid with a greater density than air? http://www.youtube.com/watch?v=fC8q4S4t8Ts

  6. Flight Instruments The altimeter shows the aircraft's height (usually in feet or meters) above some reference level (usually sea-level) by measuring the local air pressure. It is adjustable for local barometric pressure (referred to sea level) which must be set correctly to obtain accurate altitude readings. The attitude indicator shows the aircraft's attitude relative to the horizon. From this the pilot can tell whether the wings are level and if the aircraft nose is pointing above or below the horizon. This is a primary instrument for instrument flight and is also useful in conditions of poor visibility. Pilots are trained to use other instruments in combination should this instrument or its power fail. The airspeed indicator shows the aircraft's speed (usually in knots) relative to the surrounding air. It works by measuring the ram-air pressure in the aircraft's pitot tube. The indicated airspeed must be corrected for air density (which varies with altitude, temperature and humidity) in order to obtain the true airspeed, and for wind conditions in order to obtain the speed over the ground.

  7. Flight Instruments 2 The turn indicator displays direction of turn and rate of turn. Internally mounted inclinometer displays 'quality' of turn, i.e. whether the turn is correctly coordinated, as opposed to an uncoordinated turn, wherein the aircraft would be in either a slip or a skid. The heading indicator displays the aircraft's heading with respect to geographical north. Principle of operation is a spinning gyroscope, and is therefore subject to drift errors (called precession) which must be periodically corrected by calibrating the instrument to the magnetic compass.
