    1. Universal Interrupted Electronic Oil Primary R7184U Training Module

    2. What you will learn R7184U Product Overview Key Features and Benefits Installation and Set Up Troubleshooting Product Cross Reference R7184U Oil Primary Advantages

    3. R7184U Interrupted Electronic Oil Primary What is the R7184U? It is a line voltage, safety rated, primary control for residential oil fired burners used in boilers, forced air furnaces and water heaters. Applicable for use with both hydronic and forced air systems. Used with a cad cell flame sensor, operates an oil burner and optional oil valve.

    4. R7184U Key Features Universal compatibility This control replaces Carlin, White Rodgers and all prior Honeywell Oil Primary Controls EnviraCOMTM communications enabled: Includes EnviraCOM™ Connection for local networking & diagnostics Compatible with the Honeywell EnviraLINK™ remote monitoring application, which enables dealers to monitor their customers systems remotely.

    5. R7184U Key Features Diagnostic LED Indicator light monitors burner flame status and system lockout The versatile R7184U includes these “Exclusive Features”: Pump priming cycle Cad cell flame strength indicator Limited recycle Extended Service Life (Control and Application)

    6. Additional R7184U Features Available in 15-, 30-, and 45-second lockout times R7184U1004 = 15 second lockout R7184U1012 = 30 second lockout R7184U1020 = 45 second lockout Optional valve-on delay, blower-off delay models: Models: 15 seconds, or selectable 0 or 15 second valve-on delay Zero time or selectable 0-, 2-, 4-, 6-minute blower-off delay Safe start check – check for flame presence prior to lighting the burner Compatible with power venters without integral timers Oil-resistant plastic cover for electronics

    7. R7184U Feature Function Benefit

    8. R7184U Feature Function Benefit

    9. Key Features: Oil Primary R7184U

    10. Installation

    11. Installing the R7184U Follow the installation instructions per the application: Locate proper location Mount Wire per application type Oil fired boiler without EnviraCOMTM Oil fired boiler with EnviraCOMTM Oil fired forced air with EnviraCOMTM Etc.

    12. Set-Up

    13. Set-Up of the R7184U: Setting Delay Times

    14. Setting Delay Times

    15. Setting Delay Times

    16. Troubleshooting

    17. Troubleshooting of the R7184U

    18. Troubleshooting: Diagnostics

    19. Troubleshooting of the R7184U

    20. Product Cross Reference

    21. Product Cross Reference Where do I find Honeywell universal electronic oil primary cross reference information? www.customer.honeywell.com Honeywell Application Selection and Cross Reference Guide – Form 63-9575 Honeywell Laminated Truck Visor – Form 63-9581 Honeywell Oil Primary Countermat – Form 63-9661 Honeywell Residential Technical Support: 1-800-468-1502

    22. Oil Primary Cross Reference Table

    23. www.customer.honeywell.com See Cross Reference Search box in right column.

    24. R7184U Oil Primary Advantages When promoting the R7184U Universal Oil Primary keep these advantages in mind: Universal Compatibility This control replaces Carlin, White Rodgers and all prior Honeywell Oil Primary Controls Honeywell R7184U “Exclusive Features” Pump priming cycle Cad cell flame strength indicator Limited recycle Diagnostic LED Indicator light monitors burner flame status and system lockout EnviraCOM communications enabled It includes EnviraCOM™ Connection for local networking & diagnostics Compatible with Honeywell EnviraLINK™ remote monitoring application

    25. R7184U Interrupted Electronic Oil Primary Knowledge Test

    26. R7184U Oil Primary Knowledge Test Now that you completed this training module, take the short quiz to test your knowledge.

    27. Test The R7184U can be used in both hydronic and forced air systems? T or F The Honeywell R7184U can replace ALL prior Honeywell oil primary controls, as well as Carlin and White Rodgers controls? T or F There is one way to determine cad cell ohms and that is through the diagnostic LED? T of F The R7184U is available in 3 lockout times, 15, 30 and 45 seconds? T or F The pump priming cycle requires that the installer be present at the oil primary to purge the line? T or F

    28. Test Limited reset prevents the homeowner from continually pressing the reset button instead of calling for service? T or F The diagnostic LED can identify system lockout? T or F The valve on and blower off delay times are factory set and cannot be set by the installer during installation? T or F The limited recycle features can help prevent clogging the heat exchanger or flooding? T or F EnviraLink is the remote monitoring service that can be used with R7184U EnviraCOM enabled oil primary? T or F

    29. Answer Key T T F T F T T F T T
