=== 第 7 章 合金鋼及特殊鋼 ===. 7-1 構造用合金鋼 7-2 合金工具鋼 7-3 耐蝕鋼 7-4 其他特殊鋼. 第 7 章 合金鋼及特殊鋼. 合金鋼( Alloy steel ) 係在碳鋼中加入一種或一種以上的金屬或非金屬元素,藉以改變碳鋼的機械性質與物理性質,添加的元素,例如:鎳、鉻、 鉬、鋯、釩、鈷、鋁、錳、鎢、鈦、矽等,加入合金元素之後,期使新的鋼材獲得如下的主要 特性 : 1. 強化鋼的機械性質,例如:強度、硬度、衝擊值、韌性、彈性、硬化能等性能。 2. 延長鋼的使用壽命。 3. 增加鋼的耐蝕及防鏽能力,使鋼的表面保持光亮與美觀。.
