Fibre Tracking: From Raw Images ToTract Visualisation

T.R. Barrick

St. George’s Hospital Medical School, London, United Kingdom.


Introduction l.jpg

Introduction

  • Diffusion Tensor Magnetic Resonance Imaging has recently emerged as the technique of choice for representation of white matter pathways of the human brain in vivo


Objectives l.jpg

Objectives

  • To show how Diffusion Tensor Images (DTIs) are generated from Diffusion Weighted Images (DWIs)

  • To demonstrate how freely available software may be used to visualise coloured images and tractography results


Slide4 l.jpg

Overview

  • Section 1: Computing the DTI

  • Section 2: Visualising Coloured Images

  • Section 3: Streamline Tractography

  • Section 4: Visualising Tractograms


Section 1 computing the diffusion tensor l.jpg

Section 1: Computing The Diffusion Tensor

Brownian motion


Water diffusion l.jpg

Water Diffusion

Random, translational motion


Diffusion characteristics l.jpg

Diffusion Characteristics

  • In a large structure the self diffusion of water is more or less free (isotropy)

  • In small structures such as axons the diffusion is restricted in some directions more than others (anisotropy)


Diffusion coefficient d l.jpg

Diffusion Coefficient (D)

  • Diffusion is a time dependent process

  • Molecules diffuse further from their starting point as time increases

  • Units of D are mm2 s-1

  • D is temperature dependent

  • D depends species under consideration

  • Water at 37°C; D = 3.0 x 10-3 mm2 s-1


Slide9 l.jpg

Diffusion-Weighting

  • Make pulse sequence sensitive to diffusion

  • Add additional gradients into sequence

  • Spins move in gradient – phase changes

  • These gradients cause signal dephasing

  • Results in signal loss


Slide10 l.jpg

Diffusion Gradients: Stejskal-Tanner Sequence

90°

echo

180°

RF

gradient

d

d

D


Slide11 l.jpg

Diffusion Sensitivity: b value

  • Amount of diffusion sensitivity is called the b value

  • b value depends on the gradient strength, G, duration d and separation D


Slide12 l.jpg

Diffusion-Weighted Images (DWI)

increasing b factor


Slide13 l.jpg

Diffusion-Weighted Images (DWI)

  • Signal loss is proportional to b and D

  • S(0) is signal without gradients and S(b) is signal with gradients


Slide14 l.jpg

Diffusion Tensor Imaging (DTI)

  • Acquire DWI sensitised in at least 6 different directions

    • (x,y,0), (x,0,z), (0,y,z), (-x,y,0), (-x,0,z), (0,-y,z))

    • Plus image without diffusion weighting (T2)


Slide15 l.jpg

Possible Diffusion Tensor Image Acquisition

  • 1.5T GE Signa MRI (max field 22 mT m-1)

  • Diffusion-weighted axial EPI

    • b=1000 s mm-2

    • 12 directions

    • 4 averages

  • Voxel size: 2.5mm2.5mm2.8mm


Computation of the dti l.jpg

Computation of the DTI

  • Subject DWIs coregistered to image without diffusion weighting(Haselgrove and Moore, 1996)

  • General linear model used to compute D at each voxel

    • Uses observed diffusion weightings and the b-matrix of diffusion sensitisation(Basser et al., 1996)


Slide17 l.jpg

Diffusion Tensor Imaging

  • Provides a full description of the second order diffusion tensor,

  • At each voxel, D is then diagonalised


Slide18 l.jpg

Diffusion Tensor Imaging

  • Eigenvalues and eigenvectors of D correspond to principal diffusivities and principal diffusion directions

  • Necessarily 3 eigenvalues,

    • Principal diffusivities 1, 2, and 3.

    • Invariant under rotation.


Slide19 l.jpg

Diffusion Tensor Imaging

  • For each eigenvalue the corresponding diffusion direction is given by the eigenvector, v1, v2, and v3.

  • Direction of principal diffusivity is eigenvector corresponding to largest eigenvalue (diffusivity).


Slide20 l.jpg

Diffusion Tensor Orientation and Shape

Oblate,1 2 >> 3

Prolate,1 >> 2  3

Disc

3

2

3

1

Spherical,1 2  3

v1

Anisotropic

Isotropic


Slide21 l.jpg

Invariant Diffusion Measures: Mean Diffusivity

  • Apparent Diffusion Coefficient (ADC)

  • Quantitative

  • Bright pixels - high diffusion

  • Uniform across WM

  • Typical WM values;

    ADC = 0.8 x 10-3 mm2 s-1


Slide22 l.jpg

Diffusion Anisotropy

ADCx

ADCy

ADCz


Slide23 l.jpg

Invariant Diffusion Measures: Fractional Anisotropy

  • Fractional anisotropy (Basser et al., 1996)

  • Quantitative, visualizes WM

  • Bright pixels - high anisotropy

Data Range 0 to 1

(isotropic to anisotropic)


Section 2 visualising coloured images l.jpg

Section 2: Visualising Coloured Images

  • mri3dX – Krish Singh, Aston University

  • Home page:

    • http://www.aston.ac.uk/lhs/staff/singhkd/mri3dX/index.shtml

  • Allows visualisation of:

    • 24 bit RGB images (shade files, *.shd)

    • Analyze format images (*.hdr, *.img)


Slide25 l.jpg

Visualising Coloured Images

  • 24 bit RGB images

    • 3 stacked 8 bit volumes (each 256×256×N)

    • Order: Red, Green, Blue

    • No header

  • N.B. Due to the *.shd file’s lack of a header an image with identical height must be loaded prior to loading the *.shd file


Slide26 l.jpg

mri3dX Environment

Main Window

Axial

Sagittal

Coronal


Slide27 l.jpg

Right-left

Anterior-posterior

Superior-inferior

Principal Diffusion Direction

Direction Encoded

Colour map (DEC)

Red = | vx |

Green = | vy |

Blue = | vz |

Pajevic and Pierpaoli, 1999


Slide28 l.jpg

Diffusion Tensor Shape

Shape Encoded

Colour map (SEC)

Red = 1/1 = 1

Green = 2/1

Blue = 3/1

Prolate

Oblate (Disc)

Sphere


Section 3 streamline tractography l.jpg

Section 3: Streamline Tractography

  • Attempt to ‘connect’ voxels on basis of directional similarity of coincident eigenvectors

Mori et al.,

Ann Neurol 1999


Slide30 l.jpg

Streamline Tractography

  • Tracts generated from DTI

  • Define step vector length, e.g. t = 1.0 mm

  • Define tract termination criteria

    • Fractional anisotropy, e.g. FA < 0.1

    • Angle between consecutive eigenvectors, e.g. angle > 45°

Basser et al., 2000

Mori et al., 1999


Slide31 l.jpg

Streamline Tractography

  • Tracts computed in orthograde and retrograde directions from initial seeds

  • By using multiple seed points white matter structures are extracted


Slide32 l.jpg

Tractography Algorithm

Seed Point

Read

tensor


Slide33 l.jpg

Tractography Algorithm

Seed Point

Diagonalise

tensor

Read

tensor


Slide34 l.jpg

Tractography Algorithm

Seed Point

FA <

threshold?

Diagonalise

tensor

Read

tensor


Slide35 l.jpg

Tractography Algorithm

Seed Point

FA <

threshold?

Diagonalise

tensor

Read

tensor

NO

Angle >

threshold?

Basser et al., 1999

Mori et al., 1999


Slide36 l.jpg

Tractography Algorithm

Seed Point

FA <

threshold?

Diagonalise

tensor

Read

tensor

NO

Step distance, t,

along principal

eigenvector

Angle >

threshold?

NO

Basser et al., 1999

Mori et al., 1999


Slide37 l.jpg

Tractography Algorithm

Seed Point

FA <

threshold?

Diagonalise

tensor

Read

tensor

NO

Interpolate

tensor field

Step distance, t,

along principal

eigenvector

Angle >

threshold?

NO

Basser et al., 1999

Mori et al., 1999


Slide38 l.jpg

Tractography Algorithm

Seed Point

FA <

threshold?

YES

Diagonalise

tensor

Read

tensor

NO

Output

tract

vectors

Interpolate

tensor field

Step distance, t,

along principal

eigenvector

Angle >

threshold?

NO

YES

Basser et al., 2000

Mori et al., 1999


Section 4 visualising tractograms l.jpg

Section 4: Visualising Tractograms

  • GeomView - interactive 3D viewing program for Unix and Linux (openGL)

  • View and manipulate 3D objects

  • Allows rotation, translation, zooming

  • Geometry Center, University of Minnesota, USA (1992-1996).


Geomview l.jpg

GeomView

  • Although the Geometry Center closed in 1998, GeomView is still available and continues to evolve

  • Home page – http://www.geomview.org/

  • Download from:

    • http://www.geomview.org/download/


Geomview environment l.jpg

GeomView Environment

Main Window

Tool Bar

Camera Window


Geomview file format l.jpg

GeomView File Format

  • Documentation available online

  • GeomView input file format:

    • Object Oriented Graphics Library (OOGL)

    • OOGL files may be either text (ASCII) or binary files


Vect file format l.jpg

VECT File Format

  • VECT is an OOGL format that allows visualisation of vectors or strings of vectors in GeomView

    • Number of vectors (steps) in tractogram (N)

    • Start (s) and end (e) points for each vector

    • RGB colour (c) for each vector


Vect file format44 l.jpg

VECT File Format

  • The conventional suffix for VECT files is ‘*.vect’.

  • The files must have the following syntax:


Vect file format45 l.jpg

VECT File Format

  • VECT

  • #edges (N) #vertices (N×2) #colours (N)

  • #vertices per edge (i.e. 2, N times)

  • #colours for each vector (i.e. 1, N times)

  • N×2 vertices: N×6floats, s(x,y,z), e(x,y,z)

  • N vector colours: N×4 floats, R G B A)


Vect file format46 l.jpg

VECT File Format

  • Example 1: Drawing two vectors

    • N = 2

    • Edge 1 (2 vertices v1 = (1 0 0), v2 = (0 1 0))

    • Edge 2 (2 vertices v1 = (0 1 0), v2 = (0 0 1))

    • Colours (absolute value DEC)

      • For Edge 1 (R G B A) = (1 1 0 1)

      • For Edge 2 (R G B A) = (0 1 1 1)


Vect file format47 l.jpg

VECT File Format

  • Example 1: Drawing two vectors


Visualising tractograms l.jpg

e

Visualising Tractograms

  • Example 2: Corticospinal pathway

  • Patient: Biopsy proven right temporal glioblastoma

  • ROIs in Brodmann Area 6 and through the base of the corticospinal tract

Clark et al., 2003


Visualising tractograms49 l.jpg

Visualising Tractograms

  • Example 2: Corticospinal pathway

  • Seed regions of interest drawn using…

  • mriCro – Chris Rorden, Nottingham University

  • Home page:

    • http://www.psychology.nottingham.ac.uk/staff/cr1/mricro.html


Visualising tractograms50 l.jpg

Visualising Tractograms

  • Example 2: Corticospinal pathway

    • Streamline tractography (Basser et al., 2000)

    • Angle threshold: 45°

    • FA threshold: 0.1

    • Vector length: 2.0mm

    • Whole brain tractography


Visualising tractograms51 l.jpg

Visualising Tractograms

  • Example 2: Corticospinal pathway


Cquad file format l.jpg

CQUAD File Format

  • CQUAD is an OOGL format that allows visualisation of coloured quadrilaterals in GeomView

    • Positions of the 4 vertices

    • RGB colour for each of the 4 vertices

  • For visualisation of image slices in GeomView


Slide53 l.jpg

CQUAD File Format

  • The conventional suffix for CQUAD files is ‘*.cquad’.

  • The files must have the following syntax:


Cquad file format54 l.jpg

CQUAD File Format

  • CQUAD

  • N×4 vertices for N quadrilaterals (each consisting of N×4, x,y,z coordinates)

  • Corresponding N×4 vertex colours (each consisting of N×4 floats, R G B A)


Visualising image slices l.jpg

Visualising Image Slices

  • Example 3: Drawing a square

    • CQUAD

    • 4 vertices with associated colours

      • v1 = (1 1 0) c1 = (1 0 0 1)

      • v2 = (1 -1 0) c2 = (1 0 0 1)

      • v3 = (-1 -1 0)c3 = (0 1 0 1)

      • v4 = (-1 1 0)c4 = (0 1 0 1)


Slide56 l.jpg

Visualising Image Slices

  • Example 3: Drawing a square

Lighting On

Lighting Off


Slide57 l.jpg

e

Visualising Image Slices

  • Example 4: Constructing an image slice

Clark et al., 2003


Slide58 l.jpg

Visualising Image Slices

  • Example 4: Constructing an image slice


Off file format l.jpg

OFF File Format

  • OFF is an OOGL format that allows visualisation of polygons in GeomView

  • For visualisation of triangulated surfaces output from the marching cubes algorithm (Lorenson and Cline, 1987)


Off file format60 l.jpg

OFF File Format

  • The conventional suffix for OFF files is ‘*.off’.

  • The files must have the following syntax:


Off file format61 l.jpg

OFF File Format

  • OFF

  • #edges #faces (N) #vertices

  • Vertex positions for face N (N×3x,y,z coordinates)

  • For face N,

    • #vertices followed by vertex order

    • Face colour (4 floats, R G B A)


Off file format62 l.jpg

OFF File Format

  • Example 5: Drawing a triangle


Visualising surfaces l.jpg

Visualising Surfaces

  • Example 6: Constructing a surface

    • Draw the region of interest

    • Triangulated surface patch coordinates via the marching cubes algorithm


Visualising surfaces64 l.jpg

Visualising Surfaces

  • Example 6: Constructing a surface


Full visualisation l.jpg

Full Visualisation

  • Example 7: Tractogram/Slice/Surface

Clark et al., 2003


Creating geomview movies l.jpg

Creating GeomView Movies

  • Stage Tools is required

  • Download: http://www.geom.uiuc.edu/ software /download/StageTools.html

  • Stage Tools includes software for:

    • Loading and unloading image objects

    • Specifying rotation, translation and zooming parameters to GeomView objects


Creating geomview movies67 l.jpg

Creating GeomView Movies

Tiff snapshots output

from GeomView

Movie created in

Paint Shop Pro 7


Slide68 l.jpg

Conclusion

  • Computation of the Diffusion Tensor from Magnetic Resonance Images has been described

  • Freely available software has been shown to be capable of visualising coloured images and tractograms


  • Login
