Csc endcap muon port card and muon sorter upgrade status may 2013

CSC EndcapMuon Port Cardand Muon Sorter Upgrade StatusMay 2013


Mpc upgrade requirements

MPC Upgrade Requirements

■ Be able to deliver all 18 trigger primitives from the EMU peripheral

crate to the upgraded Sector Processor

■ Preserve sorting capabilities of the Muon Port Card

■ Preserve 3 old 1.6Gbps optical links to the existing CSCTF


Upgrade developments

Upgrade Developments

  • Use existing Muon Port Card main board

    - TMB interface remains unchanged (2 LCTs per TMB @ 80MHz)

    - 3 “old” optical links are still available

  • Original design (2004) was based on Xilinx Virtex-E XCV600E FPGA

  • New prototype (2012) is based on Xilinx Spartan-6 FPGA

    - Inexpensive FPGA ($280 for

    the fastest speed grade

    XC6SLX150T-3FFG900C device)

    - 8 embedded GTP serializers

    - 3.2Gbps/channel data rate

    - Modest power consumption

    (~1A Vccint; <1A GTPs)

    - Pluggable 12-channel

    optical transmitter


New spartan 6 mezzanine

New Spartan-6 Mezzanine

Top

Bottom

Pluggable optical transmitter


Optical transmitter

Optical Transmitter

SNAP12 transmitter

Avago AFBR-810

  • SNAP12 and Avago AFBR-810 are pluggable 12-channel devices

  • Both use the same 10x10 low profile circuit, but pin assignment

  • is different (Avago is intended for higher data rate)

  • ■ uTCA SP12 uses Avago AFBR820 receiver


Old and new mezzanines installed

Old and New Mezzanines Installed


Optical tests at rice 2012 2013

Optical Tests at Rice, 2012-2013

  • Three MPC boards with the

  • new mezzanines

  • SP10 prototype

  • Test software is available,

  • various PRBS and random patterns

  • Random patterns from MPC FIFO to SP10 FIFO under

  • slow VME control: 10K iterations (510 frames each);

  • no errors, all boards

  • PRBS tests OK, BER<10-13

MPC

SP10

CCB


Latency measurements

Latency Measurements

■ Present MPC-to-SP system at CMS:580 ns

- TLK2501 Transmitter (1.6Gbps - 80MHz)

~23 ns

- 100 m optical MMF fiber

~500 ns

- TLK2501 Receiver (1.6Gbps - 80MHz)

~57 ns

■ New system (prototypes):589 ns

- Spartan-6 GTP Transmitter (3.2Gbps – 160MHz)

~20 ns (without Tx buffer, measured)

- 100 m optical MMF fiber

~500 ns

- Virtex-6 GTX receiver (3.2Gbps – 160MHz)

~69 ns (without Rx buffer, estimate)


Other measurements

Other Measurements

■ Power consumption:

- Spartan-6 FPGA

~1A Vccint (1.2V)

~0.15A Vccaux+Vcco (3.3V)

~ 0.8A GTPs (1.2V)

- 3 MIC69501 voltage regulators on a mezzanine board

passed reactor irradiation test at TAMU in 2011

- MPC (main board + Spartan-6 mezzanine)

<4A @ 3.3V


Optical fibers for p 5

Optical Fibers for P.5

● Trunk cable with 4 connectorizedcords (similar to one proposed for

the DT upgrade). Each cord has 12 fibers. Need 36 cables for 60

peripheral crates, one spare cord per crate.

● Cable sample was successfully tested at UF in April 2013

● Purchase order has been placed through CERN in April 2013


Irradiation tests of the fpga 1

Irradiation Tests of the FPGA (1)

■ 66 MeV proton accelerator at Crocker Nuclear Laboratory, UC Davis

■ Wide range of beam fluxes typically from 104 to 109 p/cm2 /s


Irradiation tests of the fpga 2

Irradiation Tests of the FPGA (2)

■ Irradiated with 1 kRad at a rate of ~1 Rad/sec (convenient to detect SEU)

● 75 Single Event Upsets (SEU):

● 5 to 15 seconds between SEU

● Average dose to get an error ~13 Rad. With the accumulated fluence of 3*1011

protons/cm2, the cross section of SEU is 75 / 3x1011 = 2.5x10-9 cm2 .

● Assuming 10-year fluence of ~1011 neutrons per cm2 [1] at full LHC design luminosity,

the worst case SEU rate would be

2.5x10-9cm2 x 1011 neutrons/cm2 / 5x107 sec = 5x10-6, or

1 SEU in ~ 5.5 hours per device [1] http://cmsdoc.cern.ch/~huu/tut1.pdf

■ Irradiated with 30 kRad at a rate 80 Rad/sec (10 years of LHC exposure in

the ME1/1 area with a safety factor 3)

● Many upsets

● FPGA survived the test

■ Irradiated with 100 kRad at a rate of 360 Rad/sec

● Many upsets

● FPGA survived the test

■ Irradiated with ~300 Rad at a rate of ~1 Rad/sec again (repeat of first test)

● 50 SEU in 5 minutes

● Average dose to get an error ~6 Rad, ~2 times higher than in test 1

● FPGA is fully functional


Irradiation tests of the eprom

Irradiation Tests of the EPROM

■ Irradiated with 1 MeV equivalent fluence at ~10.5*1012

n/cm2 at the TAMU cyclotron in April 2013

■ Equivalent to ~30kRad, or 30 years of LHC exposure

in ME1/1 area

■ Device was read back; not a single bit change, as

expected

XCF32P PROM


What needs to be done in 2013 14

What Needs to Be Done in 2013-14

■ Implement new data format MPC-to-SP

- ready for MPC, but not tested with the uTCA SP

■ Need to set up a test stand at Rice:

Track Finder VME crate (exists)

- MPC (special slot)

- SP05 (to be able to check three old optical links)

- CCB

- TTCvi/vx

New uTCA crate (exists)

- controller (need to be purchased)

- AMC13 card (one, currently at UF)

- SP12 (from UF)

Software to run uTCA

■ Will need similar test stand at bld.904 at CERN by summer 2014


Pcb and parts

PCB and Parts

■ Mezzanine board: 10-layer PCB

Optical transmitter board: 4-layer PCB

■ Xilinx FPGA and EPROM are readily available from stock

Optical transmitter: single source (Avago), several weeks delivery

other parts not a concern


Muon sorter upgrade

Muon Sorter Upgrade

■ Upgraded mezzanine board provides direct optical link to the interim

calorimeter trigger
