  1. Data Protection Solutions August 12, 2010 Eric G. Harmon Technology Consultant EMC Backup and Recovery Systems (BRS)

  2. Scavenger Hunt Keyword PROTECTION

  3. Question Why do we backup? • Because we have to • So we don’t get fired • Because we so enjoy it!

  4. Answer To RECOVER!

  5. Recovery Classification Recovery Point Objective (RPO) Disaster Recovery (DR) 1 Second 24 Hours Operational Recovery 24 Hours 1 Year Archival Recovery 1 Year Forever?

  6. Data Protection $$$ RPO - Seconds Tier 1 CDP Significant storage requirements RPO - 1 hour Tier 2 Snaps/Clones No Catalog – short term recovery RPO - 24 hours Base Backup Full Catalog for long-term recovery

  7. Today’s Data Protection Challenges Unabated Data Growth Backup typically represents a factor of 4 to 30 times production capacity Daily, weekly, and monthly full backups kept for months or years New requirements to keep more data for longer periods 2,500 2,000 1,500 Exabytes 1,000 500 0 2008 2009 2010 2011 2012 Major trends driving the transformation of backup environments Digital Information Created and Replicated Worldwide 5xgrowth in 4years Source: IDC Digital Universe white paper, sponsored by EMC, May 2009 Source: IDC Digital Universe Study, sponsored by EMC, May 2010; chart does not include data that does not need protection

  8. Traditional Tape to Truck DR/Archive 10TB 1TB 2.5TB 25TB Week 100TB 10TB Month Backup Server(s) Production Data

  9. Introduction of DeduplicationData Domain Basics Backup Server(s) Target Based Deduplication • Inline variable block deduplication Production Data • Seamless integration with existing backup software • FC and IP connectivity • Up to 95% reduction of storage • 95% Bandwidth reduction • Fastest time to DR readiness

  10. Industry’s Most Scalable Inline Deduplication Systems Global Deduplication Array DD880 DD600 Appliance Series DDX Array Series Software Options: DD Boost, DD Virtual Tape Library, DD Replicator, DD Retention Lock and DD Encryption Up to 16 Controllers DD140 Remote Office Appliance

  11. Today’s Data Protection Challenges Hardware ESXServer Major trends driving the transformation of backup environments Server virtualization • Dynamic environment causes increased complexity • Virtual machine sprawl creates protection challenges • Server consolidation creates high server utilization leaving little bandwidth for backup Old Paradigm New Paradigm 80 percent resource utilization 20 percent resource utilization 100% 100% 80% 80% 60% 60% CPU Utilization CPU Utilization 40% 40% 20% 20% Shared Physical Resources 0% 0%

  12. Introduction of Deduplication Avamar Basics Backup Server(s) Source Based Deduplication • Variable segment deduplication Production Data • Client-side, global deduplication; within & across clients • Backup process minimizes data sent and stored • Up to 10:1 reduction in backup times • Replication is built-in • No charge for agents

  13. Making Backup Better • Faster system recovery • Remove hardware dependency • Restore system anywhere • Retain more • Replicate smarter • Restore more reliably

  14. EMC Avamar for VMware Guest backup Application-specific, no-cost, agents assure application consistency Breaks resource contention bottlenecks Image backup Integrated with VMware vStorage API Change-block-tracking minimizes backup time Efficient image backup from virtual proxy Load balancing across proxy virtual machines Easy file-level recovery from image backup Tight VMware vCenter Server integration Central management & control Optimized for VMware Backup

  15. EMC Avamar for Remote Offices Protects remote offices using existing bandwidth Primary Data Center Backup to Local Avamar Data Store Replicate to Main Data Store Large Site Avamar Agents Only Direct to Main Data Store Small Site Backup to Avamar Virtual Edition Replicate to Main Data Store Distributed Virtualization Site Secondary Site

  16. EMC Avamar for Desktops and LaptopsEfficient Protection for Windows and Macintosh WAN/LAN WAN Desktop Replication Web Browser Interface (Windows/Mac) Laptop Primary Data Center Remote Site • Lightweight agent, simple installation - easy, self-service restore for end-users • Backups run in minutes, without interrupting your work! • Administrators’ tools simplify support for thousands of clients • Standard Avamar capacity pricing model; no ‘per-client’ or ‘per-seat’ costs

  17. Archiving Basics Backup Server(s) Archive Infrastructure • Remove dormant data from your production storage device Production Data • Process is transparent to end users • Apply policies to data (last accessed, last modified, etc.) • Logical separation excludes data from backup • Replication for DR protection Archive Data Archive Data

  18. Were you aware… • That nearly 70% of all corporate data stored today is no longer changing (fixed content) • That odds are the storage platforms that you are storing this data on is designed for the exact opposite • That you are backing up that data every day, week or month and it has not changed in… years? • Over 80% of File System data has not been modified in 6 months or more • Over 65% of Emails and Attachments have not been accessed in more than 6 months • That 84% of Net New data created today is fixed content

  19. EMC Centera—An Archive Solution • Assured content authenticity and online access • Speed of disk, with the authenticity of optical, at the price of tape • Easy to manage • Administrators can manage up to 50 times greater quantity of content • Efficient—single-instance storage • Works with any application or any platform • Centralize archive silos from multiple data repositories • Enable thousands of users to share single multi-application repository • Meets governance and compliance requirements Simple Affordable Secure

  20. EMC Centera RAIN Storage Architecture • Self-configuring, self-healing, self-managing • Processing power *increases* as you add capacity • Simple to scale • Seamlessly add capacity without disruption • No software change required to scale • Protection from technology obsolescence • No single point of failure Up to 32 nodes per cabinet

  21. Which Solution is Right for You? Backups are running all day long,the infrastructure is overloaded • Depends on: • Current backup challenges and environment • Application and data type • Service level requirements • Backup, e-mail, & file system assessments, TCO tools • Data Deduplication Assessment • Quick Scripts Backup Assessment • Exchange Assessment • Files System Assessment Deduplication effect ondaily incremental backups Contact TEAMIA to assist with your environment!

  22. Summary • The data protection landscape is shifting • Redesign your backup with deduplication --the move is on! • Retain longer • Replicate smarter • Recover reliably • Calculate how much deduplication can save you • Data Domainwww.dedupecalculator.com • Avamarwww.emc.com/backupdedupe
