Ics 156 lecture 2 part 2

ICS 156: Lecture 2 (part 2)

Data link layer protocols

Address resolution protocol

Notes on lab 2


Tcp ip protocol stack

TCP/IP Protocol Stack

  • The TCP/IP protocol stack runs on top of multiple data link layers.

  • Two data link layer technologies

    • Broadcast

    • Point-to-Point


Data link layer

Data Link Layer

  • The main tasks of the data link layer are:

    • Transfer data from the network layer of one machine to the network layer of another machine

    • Convert the raw bit stream of the physical layer into groups of bits (“frames”)


Two types of networks at the data link layer

Two types of networks at the data link layer

  • Broadcast Networks: All stations share a single communication channel

  • Point-to-Point Networks: Pairs of hosts (or routers) are directly connected

  • Typically, local area networks (LANs) are broadcast and wide area networks (WANs) are point-to-point


  • Local area networks

    Bus LAN

    Ring LAN

    Local Area Networks

    • Local area networks (LANs) connect computers within a building or a enterprise network

    • Almost all LANs are broadcast networks

    • Typical topologies of LANs are bus or ring or star

    • We will work with Ethernet LANs. Ethernet has a bus or star topology.


    Mac and llc

    MAC and LLC

    • In any broadcast network, the stations must ensure that only one station transmits at a time on the shared communication channel

    • The protocol that determines who can transmit on a broadcast channel are called Medium Access Control (MAC) protocol

    • The MAC protocol are implemented in the MAC sublayer which is the lower sublayer of the data link layer

    • The higher portion of the data link layer is often called Logical Link Control (LLC)


    Ieee 802 standards

    IEEE 802 Standards

    • IEEE 802 is a family of standards for LANs, which defines an LLC and several MAC sublayers

    Higher layer issues

    LLC

    CSMA/CS

    Token bus

    Token ring

    Wireless lan


    Ethernet

    Ethernet

    • Speed: 10Mbps -10 Gbps

    • Standard: 802.3, Ethernet II (DIX)

    • Most popular physical layers for Ethernet:

      • 10Base5 Thick Ethernet: 10 Mbps coax cable

      • 10Base2 Thin Ethernet: 10 Mbps coax cable

      • 10Base-T 10 Mbps Twisted Pair

      • 100Base-TX100 Mbps over Category 5 twisted pair

      • 100Base-FX100 Mbps over Fiber Optics

      • 1000Base-FX1Gbps over Fiber Optics

      • 10000Base-FX1Gbps over Fiber Optics (for wide area links)


    Bus topology

    Bus Topology

    • 10Base5 and 10Base2 Ethernets has a bus topology


    Star topology

    Star Topology

    • Starting with 10Base-T, stations are connected to a hub in a star configuration


    Ethernet hubs vs ethernet switches

    Ethernet Hubs vs. Ethernet Switches

    • An Ethernet switch is a packet switch for Ethernet frames

      • Buffering of frames prevents collisions.

      • Each port is isolated and builds its own collision domain

  • An Ethernet Hub does not perform buffering:

    • Collisions occur if two frames arrive at the same time.

  • Hub

    Switch


    Ethernet and ieee 802 3 any difference

    Ethernet and IEEE 802.3: Any Difference?

    • There are two types of Ethernet frames in use, with subtle differences:

    • “Ethernet” (Ethernet II, DIX (Digital-Intel-Xerox)

      • An industry standards from 1982 that is based on the first implementation of CSMA/CD by Xerox.

      • Predominant version of CSMA/CD in the US.

  • 802.3:

    • IEEE’s version of CSMA/CD from 1985.

    • Interoperates with 802.2 (LLC) as higher layer.

  • Difference for our purposes: Ethernet and 802.3 use different methods to encapsulate an IP datagram.


  • Ethernet ii dix encapsulation rfc 894

    Ethernet II, DIX Encapsulation (RFC 894)


    Ieee 802 2 802 3 encapsulation rfc 1042

    IEEE 802.2/802.3 Encapsulation (RFC 1042)


    Point to point serial links

    Point-to-Point (serial) links

    • Many data link connections are point-to-point serial links:

      • Dial-in or DSL access connects hosts to access routers

      • Routers are connected by high-speed point-to-point links

    • Here, IP hosts and routers are connected by a serial cable

    • Data link layer protocols for point-to-point links are simple:

      • Main role is encapsulation of IP datagrams

      • No media access control needed


    Data link protocols for point to point links

    Data Link Protocols for Point-to-Point links

    • SLIP (Serial Line IP)

      • First protocol for sending IP datagrams over dial-up links (from 1988)

      • Encapsulation, not much else

  • PPP (Point-to-Point Protocol):

    • Successor to SLIP (1992), with added functionality

    • Used for dial-in and for high-speed routers

  • HDLC (High-level Data Link Control) :

    • Widely used and influential standard (1979)

    • Default protocol for serial links on Cisco routers

    • Actually, PPP is based on a variant of HDLC


  • Ppp ip encapsulation

    PPP - IP encapsulation

    • The frame format of PPP is similar to HDLC and the 802.2 LLC frame format:

    • PPP assumes a duplex circuit

    • Note: PPP does not use addresses

    • Usual maximum frame size is 1500


    Additional ppp functionality

    Additional PPP functionality

    • In addition to encapsulation, PPP supports:

      • multiple network layer protocols (protocol multiplexing)

      • Link configuration

      • Link quality testing

      • Error detection

      • Option negotiation

      • Address notification

      • Authentication

    • The above functions are supported by helper protocols:

      • LCP

      • PAP, CHAP

      • NCP


    Ppp support protocols

    PPP Support protocols

    • Link management: The link control protocol (LCP) is responsible for establishing, configuring, and negotiating a data-link connection. LCP also monitors the link quality and is used to terminate the link.

    • Authentication: Authentication is optional. PPP supports two authentication protocols: Password Authentication Protocol (PAP) and Challenge Handshake Authentication Protocol (CHAP).

    • Network protocol configuration: PPP has network control protocols (NCPs) for numerous network layer protocols. The IP control protocol (IPCP) negotiates IP address assignments and other parameters when IP is used as network layer.


    Address resolution protocol arp

    Address Resolution Protocol(ARP)


    Overview

    Overview


    Arp and rarp

    ARP and RARP

    • Note:

      • The Internet is based on IP addresses

      • Data link protocols (Ethernet, FDDI, ATM) may have different (MAC) addresses

    • The ARP and RARP protocols perform the translation between IP addresses and MAC layer addresses

    • We will discuss ARP for broadcast LANs, particularly Ethernet LANs


    Processing of ip packets by network device drivers

    Processing of IP packets by network device drivers


    Address translation with arp

    Address Translation with ARP

    ARP Request: Argon broadcasts an ARP request to all stations on the network: “What is the hardware address of 128.143.137.1?”


    Address translation with arp1

    Address Translation with ARP

    ARP Reply: Router 137 responds with an ARP Reply which contains the hardware address


    Arp packet format

    ARP Packet Format


    Example

    Example

    • ARP Request from Argon:

      Source hardware address: 00:a0:24:71:e4:44Source protocol address: 128.143.137.144Target hardware address: 00:00:00:00:00:00Target protocol address: 128.143.137.1

    • ARP Reply from Router137:

      Source hardware address: 00:e0:f9:23:a8:20 Source protocol address: 128.143.137.1 Target hardware address: 00:a0:24:71:e4:44Target protocol address: 128.143.137.144


    Arp cache

    ARP Cache

    • Since sending an ARP request/reply for each IP datagram is inefficient, hosts maintain a cache (ARP Cache) of current entries. The entries expire after a time interval.

    • Contents of the ARP Cache:

      (128.143.71.37) at 00:10:4B:C5:D1:15 [ether] on eth0

      (128.143.71.36) at 00:B0:D0:E1:17:D5 [ether] on eth0

      (128.143.71.35) at 00:B0:D0:DE:70:E6 [ether] on eth0

      (128.143.136.90) at 00:05:3C:06:27:35 [ether] on eth1

      (128.143.71.34) at 00:B0:D0:E1:17:DB [ether] on eth0

      (128.143.71.33) at 00:B0:D0:E1:17:DF [ether] on eth0


    Proxy arp

    Proxy ARP

    • Proxy ARP: Host or router responds to ARP Request that arrives from one of its connected networks for a host that is on another of its connected networks.


    Things to know about arp

    Things to know about ARP

    • What happens if an ARP Request is made for a non-existing host?

      Several ARP requests are made with increasing time intervals between requests. Eventually, ARP gives up.

    • On some systems (including Linux) a host periodically sends ARP Requests for all addresses listed in the ARP cache. This refreshes the ARP cache content, but also introduces traffic.

    • Gratuitous ARP Requests: A host sends an ARP request for its own IP address:

      • Useful for detecting if an IP address has already been assigned.


    Vulnerabilities of arp

    Vulnerabilities of ARP

    • Since ARP does not authenticate requests or replies, ARP Requests and Replies can be forged

    • ARP is stateless: ARP Replies can be sent without a corresponding ARP Request

    • According to the ARP protocol specification, a node receiving an ARP packet (Request or Reply) must update its local ARP cache with the information in the source fields, if the receiving node already has an entry for the IP address of the source in its ARP cache. (This applies for ARP Request packets and for ARP Reply packets)

      Typical exploitation of these vulnerabilities:

    • A forged ARP Request or Reply can be used to update the ARP cache of a remote system with a forged entry (ARP Poisoning)

    • This can be used to redirect IP traffic to other hosts


    Notes on lab 2

    Notes on Lab 2


    What is a single segment network

    What is a single-segment network?

    • A single-segment network consists of interfaces connected by a single physical link, either a point-to-point link or a broadcast link.

    • Interfaces on the same single-segment network have the same network prefix.

    128.195.2.0/24

    128.195.2.100

    128.195.1.0/24

    128.195.1.100

    128.195.1.1

    128.195.2.1

    128.195.1.200

    128.195.3.1

    128.195.1.300

    128.195.2.200

    128.195.3.0/24

    128.195.3.200

    128.195.3.100


    How to identify a single segment ip network

    How to identify a single segment IP network

    • Detach interfaces from routers or hosts

    • Each isolated island is a single segment IP network

    • Each interface on the same single segment IP network must have the same network address prefix

    128.195.2.100

    128.195.1.100

    128.195.1.1

    128.195.2.1

    128.195.1.200

    128.195.3.1

    128.195.1.300

    128.195.2.200

    128.195.3.200

    128.195.3.100


    Protocol specification vs implementation

    Protocol specification vs implementation

    • According to the ARP protocol specification, a node receiving an ARP packet (Request or Reply) must update its local ARP cache with the information in the source fields, if the receiving node already has an entry for the IP address of the source in its ARP cache. (This applies for ARP Request packets and for ARP Reply packets)

    • Implementation may differ from the specification

    • What you observe in the lab may not be universally true.
