Presentation Transcript
Eth z rich separation technology

ETH Zürich Separation Technology

03. Dec 2013


Chiral column technology new generation of cellulose and amylose columns
Chiral Column TechnologyNew Generation of Cellulose and Amylose Columns

  • Smaller particle size (5µm)

  • High loading capacity

  • Pressure stable up to 300 bar

    • Faster separation

    • Save solvent

  • Stable in NP, Polar Organic, SFC and RP conditions

  • pH stable 2-9

  • Novel selectivity


Chiral column technology lux cellulose 2
Chiral Column TechnologyLux Cellulose-2



Chiral column technology example 1
Chiral Column TechnologyExample 1

Chiralpak AD, 5% EtOH/Heptane

Reprosil Chiral NR, 10% EtOH/Heptane

Peak A -


Chiral column technology example 11
Chiral Column TechnologyExample 1

Lux 2 Cellulose, 3% EtOH/Heptane

Lux 2 Amylose, 20% EtOH/Heptane

Peak A +


Chiral column technology example 2
Chiral Column TechnologyExample 2

Chiralpak AD, 5% EtOH/Heptane

Reprosil Chiral NR, 3% EtOH/Heptane


Chiral column technology example 21
Chiral Column TechnologyExample 2

The devil is in the (D)ethyl

Lux2 Cellulose, 5% EtOH/Heptane

Lux 2 Amylose, 2% EtOH/Heptane


Chiral column technology used column for prep separation 2013
Chiral Column TechnologyUsed Column for prep. Separation 2013


Chiral detection
Chiral Detection

The CHIRALYSER is a high performance Optical Rotation Detector for monitoring Optically Active compounds in HPLC.

Innovative flow cell design in multi path technology together with an optimized measuring wavelength performs outstanding sensitivity and excellent signal to noise ratio.

The approved Faraday Compensation, superior to all other methods, enables the CHIRALYSER - MP to detect optical active molecules not only in analytical but also in preparative LC.

Operation via touch screen or remote controlled by host computer adapts the CHIRALYSER to any chromatography system.


Column lifetime
Column Lifetime

  • dry solvents

    • < 0.01% water

  • clean samples

    • > 90% + no base line Peak in TLC

  • Pressure

    • < 30 bar

  • Chiralpak AD Nov/07 1700 runs

  • Chiralpak AD Nov/06 3200 runs

  • Reprosil Chiral NR Aug/08 2700 runs

    Cost per column ~25`000 CHF

    Cost per sample 10-20 CHF
