Presentation Transcript

Leaves daun



The primary functions of leaves

The primary functions of leaves:

  • Photosyntesis

  • Transpiration

Leaves daun

  • Leaf Function:

    Leaves are the powerhouse of plants. In most plants, leaves are the major site of food production for the plant. Structures within a leaf convert the energy in sunlight into chemical energy that the plant can use as food. Chlorophyll is the molecule in leaves that uses the energy in sunlight to turn water (H2O) and carbon dioxide gas (CO2) into sugar and oxygen gas (O2). This process is called photosynthesis.

Leaf structure

Leaf Structure:

  • A leaf is made of many layers that are sandwiched between two layers of tough skin cells (called the epidermis). The epidermis also secretes a waxy substance called the cuticle. These layers protect the leaf from insects, bacteria, and other pests. Among the epidermal cells are pairs of sausage-shaped guard cells. Each pair of guard cells forms a pore (called stoma; the plural is stomata). Gases enter and exit the leaf through the stomata.

Dicotyledonous leaves

Dicotyledonous leaves

Is composed of two principal parts:

  • Blade or lamina

  • Petiole or stalk

  • Netted venation

Monocotyledonous leaves

Monocotyledonous leaves:

Is divided into two parts:

  • Sheath

  • Blade

  • Paralled venation

There are two kind of leaves

There are two kind of leaves:

Types of leaves

Types of Leaves

Simple: not divided into leaflets; leaf composed of one blade

Compound: consists of two or more leaflets

Pinnately Compound: feather-like; leaflets along each side of a common axis.

Leaves daun

Bipinnately Compound: primary and secondary divisions are pinnate.

Palmately Compound: 3 or more leaflets radiating from a common point.

Trifoliate: three leaflets

Leaves daun

Single Needle



Leaves daun

Opposite: leaves are directly across from each other on the stem.

Alternate: leaves are arranged singly at different heights and on different sides of the stem.

Cordate: heart-shaped.

Leaves daun

Elliptic: broadest in the middle and narrower at each end.

Flabellate: fan-like.

Lanceolate: longer than wide, broadest below the middle and tapering to the apex.

Leaves daun

Obovate: inversely ovate, broadest above the middle

Ovate: egg-shaped, broadest below the middle

Broad Ovate: wide, egg-shaped

Leaves daun

Leaf Margins:

Leaves come in many sizes and shapes; they are often used to help identify plants. Some leaves are flat and wide; others are spiky and thin. Plant spines (like cactus spines) are actually modified leaves.

Leaf Margins

Plant parts leaf

Plant Parts – Leaf




Vein Pattern

Form – Simple or Compound



Leaf arrangement simple

Leaf Arrangement – Simple

Leaf arrangement compound

Leaf Arrangement – Compound

Leaf shape

Leaf Shape

Vein pattern

Vein Pattern

  • Pinnate

  • Palmate

  • Parallel

  • Dichotomous

Leaf margin

Leaf Margin

Leaf surface

Leaf Surface

  • Glabrous

  • Pubescent

  • Villous

  • Tomentose

  • Scabrous

  • Glaucous

  • Rugose

  • Glandular

  • There are 8 common leaf surfaces.

Leaf surface glabrous

The surface is smooth, not hairy.

Leaf Surface – Glabrous

Leaf surface pubescent

Short, soft hairs cover the surface.

Leaf Surface – Pubescent

Leaf surface tomentose

Covered with wool-like hair.

Leaf Surface – Tomentose

Leaf surface scabrous

Leaf Surface – Scabrous

Covered with short, prickly hairs.

Leaf surface glaucous

Covered with a bluish-white waxy substance.

Leaf Surface – Glaucous

Leaf surface rugose

Surface is wrinkly.

Leaf Surface – Rugose

Leaf surface glandular

Glands filled with oil or resin cover the surface.

Leaf Surface – Glandular

Anatomy of the foliage leaf

Anatomy of the foliage leaf:

In the leaves of most trees, three distinct tissue layers can be discerned in their leaves. These are:

  • 1.The epidermiswith its cuticle and stomata

  • 2.Themesophyll where most of the

    chloroplasts are found and photosynthesis takes place

    3. The leaf veins which transport water and inorganic

    compounds into the leaf, and organic compounds

    produced by photosynthesis away from the leaf, to

    other parts of the plant.

Leaves daun

Cross section of a leaf, showing the anatomical features important to the study of photosynthesis: stoma, guard cell, mesophyll cells, and vein

Leaves daun

  • Epidermis

  • The epidermal tissue functions in prevention of water loss and acts as a barrier to fungi and other invaders. Thus, epidermal cells are closely packed, with little intercellular space. To further cut down on water loss, many plants have a waxy cuticle layer deposited on top of the epidermal cells.

  • Guard Cells

  • To facilitate gas exchange between the inner parts of leaves, stems, and fruits, plants have a series of openings known as stomata (singular stoma). They regulate exchange of water vapor, oxygen and carbon dioxide through the stoma.

Leaves daun

  • Collenchyma cells support the plant. These cells are charcterized by thickenings of the wall, they are alive at maturity. They tend to occur as part of vascular bundles or on the corners of angular stems.

  • Sclerenchyma cells support the plant. They often occur as bundle cap fibers. Sclerenchyma cells are characterized by thickenings in their secondary walls. They are dead at maturity. A common type of schlerenchyma cell is the fiber.

Leaves daun

  • Xylem

  • Xylem is a term applied to woody (lignin-impregnated)walls of certain cells of plants. Xylem cells tend to conduct water and minerals from roots to leaves. While parenchyma cells do occur within what is commonly termed the "xylem" the more identifiable cells, tracheids and vessel elements, tend to stain red with Safranin-O. Tracheids are the more primitive of the two cell types, occurring in the earliest vascular plants. Tracheids are long and tapered, with angled end-plates that connect cell to cell. Vessel elements are shorter, much wider, and lack end plates. They occur only in angiosperms, the most recently evolved large group of plants

Leaves daun

Phloem cells conduct food from leaves to rest of the plant. They are alive at maturity and tend to stain green (with the stain fast green). Phloem cells are usually located outside the xylem. The two most common cells in the phloem are the companion cells and sieve cells. Companion cells retain their nucleus and control the adjacent sieve cells. Dissolved food, as sucrose, flows through the sieve cells.

A part of the leaf

A Part of The Leaf

1. Plastids: A green leaf is green because of the presence of a group of pigments known as chlorophylls. Minute structures called plastids contain the chlorophyll within the leaf.

2. Carotenoid pigments (yellow and orange) are also found in plastids. The carotenoids occure, along with the chlorophyll pigments, in tiny structures - called plastids - within the cells of leaves. Sometimes they are in such abundance iin the leaf that they give a plant a yellow-green color, Carotenoids are in many living things, giving

3. Anthocyanin pigments (reds and purples) occur in the sap of cells. The anthocyanins temporarily color the edges of some of the very young leaves as they unfold from the buds in early spring. They also give the familiar color to such common fruits as cranberries, red apples, blueberries, cherries, strawberries, and plums.

Basic leaf types

Basic leaf types

  • Ferns have fronds.

  • Conifer leaves are typically needle-, awl-, or scale-shaped

  • Angiosperm (flowering plant) leaves: the standard form includes stipules, a petiole, and a lamina.

  • Lycophytes have microphyll leaves.

  • Sheath leaves (type found in most grasses).

  • Other specialized leaves (such as those of Nepenthes)


Scale-shaped leaves

Leaves daun

stellate trichomes

trichomes on the lower surface of a Coleus

Leaves daun

  • Opening and closing of the stomata by the paired guard cells controls the gas exchange rate. In some cases, the guard cells are supported by the subsidiary cells.

  • Guard cells act as ports between the environment and the interior of the leaf. When the guard cells accumulate water they become turgescent and open. Opening and closing in turn is controlled by light conditions, air humidity, temperature and the CO2 concentration.

  • Guard cells, in contrast to other epidermis cells, do possess chloroplasts.

Leaves daun

Stomata open when the internal pressure of the guard cells rises as a result of water absorption. The pressure increases from 1.5 to 3.0 mega Pascal.

Since the walls of the guard cells are relatively flexible at the side of the stoma, the guard cells expand vertically and the stoma subsequentely opens.

Structure of a chloroplast

Structure of a chloroplast

Leaves daun

Pea Leaf Stoma, Vicea sp.

Tip of the leaf

Tip of the leaf

Leaf abscission

Leaf Abscission

  • The formation of a definite abscission zone across a petiole or fruit stem is responsible for leaf fall or fruit drop

  • The function of the abcission zone :

    - to bring about the fall of the leaf or other plant


    - to protect the region of the stem from which

    the leaf has fallen against insect damage or

    rot caused by bacteria or fungi
