  1. SMRR OVERVIEW

  2. Navigating the Site LAUNCH SMRR APPLICATION HERE PORTAL PASSWORDS AND USER ID’S CONTROL ACCESS

  3. Create A SMRR

  4. Create a SMRR TO CREATE A TAG

  5. Create Nonconformance Tag Create NC Tag / View NC Tag Select Create NC Tag

  6. Create Nonconformance Tag Create Discrepancy / Add Multiple Defects SYSTEM EDIT FOR CORRECT PART NUMBER AS LISTED ON VOUGHT PO ANNOTATE FAILED PART NUMBER AT DISCREPANY LEVEL * MANDATORY FIELD FORMAT PURCHASE ORDER AS SHOWN ON NEXT SLIDE FOR MODEL SEE “PROGRAM’ SECTION OF PO EXAMPLE NEXT SLIDE

  7. TA VAD Purchase Order

  8. Create Discrepancy / Add Multiple Defects Initial SMRR submittals require only Immediate Cause and immediate Correction (Ref. SQR-003). Complete Cause and Corrective Action must be available for review upon request.

  9. Add Multiple Defects & Attachments Must select OK to move to next screen for adding attachments

  10. Adding Attachments Only Appears after clicking on finish, then OK on “About to Submit” Dialog Box Only BMP, GIF, JPG or PDF can be attached. File size is limited to 1 Meg.

  11. Search Functions If you know the tag number you are looking for enter the tag and click the “load” button. Click on “search” will bring up all tags. Clicking on the tag Number itself will bring up that specific tag.

  12. Corrective Action RequestsFrom Triumph-Vought

  13. TAG - Corrective Action Requests E-Mail Notification To Supplier of Open Corrective Action Request This Message Is Sent To The Supplier Portal Administrator -----Original Message----- From: MESCA@voughtaircraft.com [mailto:MESCA@voughtaircraft.com] Sent: Thursday, September 18, 2008 11:18 AM To: (Name of Supplier’s Portal Administrator will be displayed here) Subject: Corrective Action for tag #423429, disc #1 has been assigned to you You can access this Corrective Action here: https://selfservice.vought.com/mesnc/home.jsp?site=exed

  14. View The Corrective Action Request Click on View Active CA – Only visible when NEW CA requests exist Open Corrective Action

  15. Update Corrective Action Request Use to attach objective evidence and supporting documentation View Discrepancy Complete Corrective Action REF –SQR-003 Submit Corrective Action Response

  16. Next Lot Verification These fields appear when “Next Lot Verification” is required. Complete the fields with the Lot and Shipper number verified and the date the verification occurred.

  17. Notification of NonconformanceMaterial Rejected at Triumph -Vought

  18. Review of Nonconformance Click on View NC Tag

  19. Review of Nonconformance Click on “Show All” to see open and closed tags If you know the Tag No. you are looking for Enter it here and the “load” button Click on “search” to view only open tags

  20. Notification of Nonconforming Material Rejected at TA VAD E-mail Notification To Supplier’s Portal Administrator -----Original Message----- From: MESCA@voughtaircraft.com.... mailto:MESCA@voughtaircraft.com Sent: Thursday, September 18, 2008 11:17 AM To: (Name of Supplier’s Portal Administrator will be displayed here) Subject: Vought NonConformance423429 Notification of Nonconforming Material at Vought Aircraft. Be advised WT (SMRR) 423429 has been generated on product supplied by your company. Please take immediate action to investigate the reported defect(s). This tag is stored in the Dallas Production MES database. If all access requirements are satisfied, you can access this tag here: https://selfservice.vought.com/mesnc/home.jsp?site=exed

  21. QUESTIONS? CONTACT jxortiz@triumphgroup.com
