Presentation Transcript
On the distribution of responsibility for network security l.jpg

On the Distribution of Responsibility for Network Security

Scott Dexter

Dept. of Computer and Information Science

Brooklyn College


Overview l.jpg
Overview

  • My Perspective

  • My Argument

  • Dramatis Personae

  • Their Roles (and Malfeasances)

  • and Their Eventual Rehabilitation


My perspective l.jpg
My Perspective

  • Theoretician by training and inclination

    • Dissertation: formal/logical analysis of security protocols

    • Implementation details sometimes regarded as abhorrent

  • Interested in relationship between individual empowerment and collective behavior

  • Deeply committed to (public) education


My argument l.jpg
My Argument

  • Network/computer security is really interesting...

  • …mostly because of its social intractability:

  • Any actor, at any level, may (easily) cause a “security breach”

    • Probably due only to ignorance, human error, laziness, or even kindness

    • But could impact many others

  • No easy fix

    • Need some technical solutions

    • Need lots of different kinds of education


Network technologies l.jpg
Network Technologies

  • “The Internet”

    • One of many technologies

    • (and can be said to be composed of many itself)

    • Designed for robustness and reliability

      (which is one aspect of “security”)

    • Designed to accommodate innovation

  • Also need

    • Proprietary/closed networks (e.g. bank machines)

    • Network applications “on top of” Internet


Actors l.jpg
Actors

  • Designers

  • Implementers

  • Administrators

  • Users

  • (“Hackers”)


Design i internet core protocols l.jpg
Design I: Internet Core Protocols

  • Info transmitted in sequence of datagrams

  • Data ‘payload’ plus complex array of control info

  • Achieves robustness and reliability in non-hostile environment

  • Possible to ‘craft’ illegal/bogus datagrams

    • Get information from nature of response

    • Circumvent firewalls & intrusion detectors

  • This is integral aspect of Internet!


Design ii cryptographic security l.jpg
Design II: Cryptographic Security

  • Appropriate use of cryptography has potential to solve many security problems

  • Can support many services:

    • Confidentiality (hide content from others)

    • Integrity (assure that content hasn’t changed)

    • Authenticity (demonstrate/confirm identity)

  • But appropriate is incredibly difficult….





One scenario key distribution12 l.jpg

Mallory

One Scenario: “Key Distribution”

K

Alice

Bob

KA

KB

Solomon


Mallory s machinations l.jpg

Passive Attacks

Eavesdropping

Public Information

Agent Identities

Algorithms

Protocol Design

“Legitimate” Identity

Active Attacks

Modification

Redirection

Suppression

Fake Messages

Mallory’s Machinations


Defenses l.jpg
Defenses

  • Cryptography

    • Encryption {m}kencrypt message m with key k

  • Time

    • Nonces M,N random numbers “used only once”

  • “Handshake” function

    • (e.g. decrement) f(m) relates to “strong encryption”:

      assumption that

      {x}k and {g(x)}k (for any function g)

      are not easily computed from each other


The needham schroeder protocol l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

A

B

S


The needham schroeder protocol16 l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

A

B

S


The needham schroeder protocol17 l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

A

B

S


The needham schroeder protocol18 l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

A

B

S


The needham schroeder protocol19 l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

A

B

S


The needham schroeder protocol20 l.jpg
The Needham-Schroeder Protocol

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

AB: {P}K once protocol completes,

BA: {Q}K A and B can send messages

over secure channel

A

B

S


Slide21 l.jpg
But . . .

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

What if Mallory

  • learns {K,A}KB

  • learns K

    ?


Mallory attacks l.jpg
Mallory Attacks!

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

(M)B: {K,A}KB


Mallory attacks23 l.jpg
Mallory Attacks!

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

(M)B: {K,A}KB

B(M): {M}K


Mallory attacks24 l.jpg
Mallory Attacks!

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

(M)B: {K,A}KB

B(M): {M}K

(M)B: {f(M)}K


Mallory attacks25 l.jpg
Mallory Attacks!

AS: A, B, N

SA: {N, B, K, {K,A}KB}KA

AB: {K,A}KB

BA: {M}K

AB: {f(M)}K

(M)B: {K,A}KB

B(M): {M}K

(M)B: {f(M)}K

. . . and now Bob thinks Mallory is Alice


Design revisited l.jpg
Design Revisited

  • Such mistakes are common even today

  • Protocols disarmingly simple

  • Error may not be discovered (by the “good guys”) for a long time


Implementation l.jpg
Implementation

  • Perfect protocol design is worse than useless if implemented incorrectly

  • Myriad opportunities for that:

    • “Back doors” [ improper software engineering ]

    • Buffer overflow [ unsafe programming ]

    • Hobbled random number generators

    • Improper use of crypto algorithms

  • [ under-rated ]

  • [ fundamentals ]


Administration l.jpg
Administration

  • (Where to start?)

  • Enforcing security policy, e.g.

    • Password policy

    • Rogue modems

  • Internal threats

  • Intrusion prevention and detection

    • Information Gathering

    • Information Analysis

    • Response


Information gathering l.jpg
Information Gathering

  • ‘Normal’ Profiles

  • ‘Abnormal’ Signatures

  • Inbound Traffic Analysis

    • Audit Trail

    • On-the-Fly

  • Daily operational analysis (‘intuitive’)


Information analysis l.jpg
Information Analysis

  • What is an intrusion?

  • Traffic Analysis Indicators

  • Analysis Techniques


Traffic analysis indicators l.jpg
Traffic Analysis Indicators

  • Repetition

  • Vulnerability Exploits

  • Mysterious Behavior / Problems

  • Unexpected/Inconsistent Activity


Analysis techniques l.jpg
Analysis Techniques

  • Pattern-matching & Signatures

  • Dynamic Association

  • Statistical Profiling

  • Audit Reduction


Response l.jpg
Response

  • False Positives

  • Traceback & Anonymity

  • Offensive Action & Traps


Intrusion detection revisited l.jpg
Intrusion Detection Revisited

  • Technical component:

    • Hardware to scan traffic

    • Software to process traffic

  • Crafty component:

    • Clear understanding of normal traffic

    • Finger on the pulse

    • Sensitive viscera

    • Constant re-education


Users l.jpg
Users

  • Increasingly must be network admins at home

  • Personal privacy/security

  • Often must trust integrity of arcane infrastructure

  • Major target of “social engineering”

    • Critical thinking

    • Analytic problem-solving


Conclusions l.jpg
Conclusions…

  • Improving security is fundamentally not technical

  • Must provide access to resources and knowledge

  • Must not let technology of security undermine permissive structure of Internet
