  1. BuzzCard Access System for Westminster Christian Fellowship March 3, 2008 Matthew Habib Ayush Samantroy Daniel van Kley Adam Sakautzky ECE 4007 L01

  2. Overview • Magnetic cards for access into WCF • Database of active users • Audit trail • Web-based administration • Cost: $870

  3. Technical Objectives • ISO 7810/7811 compliance • 5 second response time • 5% false negative rate • Secure offsite backup • 12 hour battery backup

  4. Single Board Computer • Technologic TS-7250 • Small power footprint • Debian Linux • Serial, USB, and Ethernet • Digital I/O • 5V DC • $150

  5. HID Magnetic Stripe Reader • Dorado 6453 • ISO 7810/7811 compliant • Weatherproof • 5V, 30mA DC • $150

  6. Magnetic Card Reader

  7. Door Locks Electric Strike: • Replaces existing door strike • 12V, 300mA DC • $150 Magnetic Lock: • Alternative to door strike • 12V, 100mA DC • $400

  8. User Access Flow

  9. Power Schematic

  10. Demonstration Objectives: • Allow access with valid card only • Generate accurate access log • Administer system via web browser • Operate system on battery backup Quality Assurance: • Test false positive/negative rate

  11. Budget

  12. Current Status Completed: • Acquired hardware • Initialized SBC • Tested hardware • Analyzed existing code Pending: • Develop web interface • Develop backend program • Install hardware at WCF • Test integrated system

  13. Questions?
