  1. John SinclairMD Sub Ocean

  2. Subocean Offshore Wind-farm Experience

  3. Who are Subocean Group • Subocean is a UK based Marine Contractor who’s • core business is the worldwide installation and burial of • all types of subsea cables working mainly in the Offshore • Renewables Windfarm Market installing power cables

  4. Experienced Leaders with UK Track Record • Our personnel and equipment undertook the • North Hoyle Export Cables Works • Scroby Sands Export / Array Cables Works • Arklow Banks Export Cable Repair Works • Burbo Banks Plough Assessment Works

  5. North Hoyle Scroby Sands

  6. North Hoyle Scroby Sands

  7. CREL Lynn & ID Project Scope – Exports / Array 2007-08 • Lay and bury 6 export cables – 4 km each in length • Lay and bury 43 inter array cables – approximately 43km in total length • Shore end works with bentonite works and cable termination works

  8. Eon Robin Rigg Project Scope - Exports / Array 2008-09 • Lay and bury 2 export cables – 13.2km each in length • Lay and bury 64 inter array cables – approximately 44km in total length Located 15km into the Solway Firth

  9. RWE Npower Rhyl Flats Project Scope - Arrays 2009 Lay and bury 24 inter array cables – approx. 18km Located approx. 15km from North Wales

  10. Vattenfall Thanet Project Scope – Exports / Array 2009-10 • Lay and bury 2 export cables – 26.5km each in length • Lay and bury 100 inter array cables – approximately 70km in total length • Shore end works and cable termination works Located 11.3km off the eastern most tip of Kent

  11. SSEB Greater Gabbard Project Scope - Exports 2009-10 • Lay and bury x 3 export cables – 50km each in length • Lay and bury x 1 export cables – 20km in length • Shore end works with cable jointing and termination works Located 50km off the eastern most tip of Kent

  12. SSEB Greater Gabbard Project Scope - Arrays 2010 • Lay and bury 140 inter array cables between 1-3km in length • Cable termination works Inner Gabbard Array Galloper Array

  13. UR101 Cable Lay Barge • Subocean took delivery of basic barge hull in Mar 07 and fully fitted • out the UR101 barge for cable installation and burial activities • 1000Te Carousel and associated Cable Lay Spread installed • 3.0m Cable plough spread installed • 8 point mooring spread with an additional 200Te pull ahead winch • Track record of export and array cable installation work since May 07 • .

  14. Discoverer Cable Lay Barge • Subocean took delivery of basic barge hull in Jan 09 and fully fitted out • the Discoverer barge for cable installation and burial activities • New 5500Te Carousel and associated Cable Lay Spread installed • New 3.0m Cable plough spread installed • New 8 point mooring spread with an additional 200Te pull ahead winch • Track record of export and array cable installation work since May 07 • .

  15. Polar Prince DP2 Cable Lay Vessel • On charter until 2011 with options to extend • Subocean took delivery in Aug 09 • Cable lay spread installed • Carousel or reel based system – project dependent • 3.0m Cable plough spread • Integrated ROV spread within vessel • Heave compensated crane for concrete mattress installation and • WTG works • A-Frame launch / recovery system for cable plough • 180 Te Bollard Pull • Will conduct mainly array cable work • .

  16. UR141 Transportation Barge • UR141 Transportation barge initially with option to convert to full • installation barge in future • One year Charter party signed May 09 with four by one year • options • Ordered 7000Te carousel (based on existing 5500Te design) and • Cable Load-out Spread placed in May 09 • UR141 Transportation Barge will be complete 1Q 2010. • UR141 Transportation barge will be used to transport cables to • the UK from Cable Manufacturers off the critical path • Can handle both export and array cables shipments • Can handle cable reels with 7000Te carousel in place due to large • deck space availability • .

  17. UK Market – Round 1

  18. Round 1 Projects Summary • Location Status Capacity Developer • North Hoyle Operational (Dec 2003) 60 MW RWE npower • Scroby Sands Operational (Dec 2004) 60 MW E.ON UK • Kentish Flats Operational (Sep 2005) 90 MW Vattenfall • Barrow Operational (Sept 2006) 90 MW Centrica / DONG Energy • Gunfleet Sands Under Construction 108 MW DONG Energy • Lynn/Inner Dowsing Operational (July 2008) 194 MW Centrica • Cromer Withdrawn after approval 108 MW EDF  • Scarweather Sands Approved 100 MW E.ON UK / DONG Energy • Rhyl Flats Operational (Dec 2009) 90 MW RWE npower • Burbo Bank Operational (Oct 2007) 90 MW DONG Energy • Robin Rigg Under Construction 180 MW E.ON UK • Shell Flat Application withdrawn 230 MW Scottish Power /DONG Energy  • Teesside Under Tender for 2010 108 MW EDF  • Tunes Plateau Submitted 108 MW RES/B9 Energy • Ormonde Construction 2010 150 MW Vattenfall / Eclipse Energy •   Total 1856 MW

  19. UK Market – Round 2

  20. Round 2 Projects Summary • Location Status Maximum capacity (MW) Developer  • Docking Shoal Planning – Surveys ongoing 500 Centrica • Race Bank Panning – Surveys ongoing 500 Centrica • Sheringham Shoal Construction 2010 315 Statoil Hydo • Humber Planning – Surveys ongoing 300 E.ON UK  • Triton Knoll Pre-planning 1,200 RWE Npower • Lincs Construction 2010-2012 250 Centrica • Westermost Rough Pre Planning 240 DONG Energy  • Dudgeon East Planning 300 Warwick Energy  • Greater Gabbard Construction Phase 1 – 2009/2010 500 Airtricity / Fluor • Gunfleet Sands Construction 2009 64 DONG Energy  • London Array Construction 2011-2012 1,000 DONG Energy / E.ON UK • Thanet Construction 2009-2010 300 Vattenfall • Walney Construction 2010 450 DONG Energy • Gwynt y Mor Construction 2012-2013 750 RWE npower • West Duddon Planning 500 Scottish Power / DONG Energy • TOTAL 7,169MW

  21. In July 2009 the Crown Estates announced the possibility of extensions to Round 1 and 2 projects being granted and the developers of these projects had until the end of Dec 09 to make applications for these extensions. Expect some announcements regarding these in the near future Round 1 and 2 Project Extensions

  22. UK Market - Scottish Projects Summary • ID Site Name Company Size (MW) • Solway Firth E.ON UK Developments 300 • Wigtown Bay Dong Wind (UK) Ltd 280 • Kintyre Airtricity Holdings (UK) Ltd 378 • Islay Airtricity Holdings (UK) Ltd 680 • Argyll Array Scottish Power Renewables 1,500 • Beatrice Airtricity Holdings UK Ltd / SeaEnergy Renewables Ltd 920 • Inch Cape RWE NPower Renewables Ltd / SeaEnergy Renewables Ltd 905 • Bell Rock Airtricity Holdings UK Ltd / Fluor Ltd 700 • Neart na Gaoithe Mainstream Renewable Power Ltd 360 • 10 Forth Array Fred Olsen Renewables Ltd 415 • TOTAL 6348 MW

  23. UK Market – Round 3

  24. UK Market – Round 3 Projects Summary • ID Site Name Company Size (MW) • Moray Firth EDP Renewables / Sea Energy (Moray Offshore Renewables) 3000 • Firth of Forth SSE Renewables / Flour (Seagreen Wind) 3500 • Dogger Bank SSE Renewables / RWE Npower / Statoil / Statkraft (Forewind) 9000 • Hornsea Mainstream Renewables / Siemens (SMartwind) 4000 • Norfolk Bank Scottish Power Renewables . Vattenfall (East Anglia Offshore Wind) 7200 • Hastings Eon 650 • West Isle of Wight Eneco 900 • Bristol Channel RWE Npower 1500 • Irish Sea Centrica 4200 • TOTAL 33950 MW

  25. European Market Requirements to 2020 • Over 200 projects with an overall target of over 100 GW • Based on 5MW Capacity WTG gives 20,000 WTG’s to be installed • Services provided in the UK can be exported to the European and Global Market place

  26. Services Required for the UK Market • Foundation Fabrication and Installation • Wind Turbine Generator Supply and Installation • Substation Platform Supply and Installation • Cable Supply and Installation both offshore and onshore • Electrical infrastructure supply and commissioning both offshore and onshore • Project Management and Engineering • Port Services • Installation Vessel’s • Support Vessel’s – Standby and Crew Support • Operation and Maintenance Services • Civil engineering works for cable landings including HDD • Cables Jointing and Testing Services • Survey services • Support services to all the activities identified above • Technical, Operational and Marine Personnel

  27. Where is the UK market going to get these services ? Presently the majority of the large value supply and services are coming from outside the UK This needs to be changed and a new offshore renewables industry created within this country by UK companies which can eventually be exported globally as we have done in the Oil & Gas sector

  28. How do supply and service companies get into the Market • There are no specific requirements from a regularity perspective with regards to getting into the market although having for example the Quality Certification ISO 9001 – 2000 would be an advantage but not having it is not a barrier to entry as your product and service is required in a supply and demand situation and this certification can be achieved at a later date • Research the Internet as most of the developers have websites associated with each individual project they are involved in which identifies the key contacts with their organisation • Get in contact with various associations like Aberdeen Renewable Energy Group, Subsea UK, Scottish Renewables, Scottish Enterprise and other UK Regional Agencies, Engineering Industries Council, British Wind Energy Association and the European Wind Energy Association as they can all assist from a supply chain perspective • Attend Share Fares like this put on by Scottish Enterprise and the Crown Estates • Attend conferences like the All Energy (Aberdeen in May 10) and the British Wind Energy Offshore Conference (Liverpool in June 10)

  29. The Market Summary • It is here now and we need majority UK content • Requires Construction Supply and Service Companies both Onshore and Offshore • Needs experienced Construction and Technical Personnel both • Onshore and Offshore • There is the opportunity to expand into Europe and Globally
