  1. BTE 1013 ENGINEERING SCIENCEs 6. ENGINE POWER NAZARIN B. NORDIN nazarin@icam.edu.my

  2. What you will learn: • Torque and power • Indicated power and brake power • Volumetric efficiency • Thermal efficiency • Mechanical efficiency

  3. Torque & power

  4. Indicated power Indicated power (ip) is the power that is developed inside the engine cylinders. It is determined by measuring the pressures inside the cylinders while the engine is on test, on a dynamometer. Because the pressure varies greatly throughout one cycle of operation of the engine, the pressure that is used to calculate indicated power is the mean effective pressure.

  5. Indicated mean effective pressure (Imep) Because the pressure varies greatly throughout one cycle of operation of the engine, the pressure that is used to calculate indicated power is the mean effective pressure.

  6. Imep Example 6.1 An indicator diagram taken from a single-cylinder 4-stroke engine has an effective area of 600mm2. If the base length of the indicator diagram is 60mm and the constant is 80 kPa/mm calculate the indicated mean effective pressure.

  7. Imep Solution Indicated mean effective pressure or (imep)= (effective area of indicator diagram/base length of the diagram)×constant imep = (600/60)×80 kPa/mm imep = 800 kPa = 8 bar

  8. Calculation of indicated power Indicated power is calculated from the formula Indicated power (ip) = (P×l×a×N)/1000 Unit as kW where P = mean effective pressure in N/m2, l = length of engine stroke in m, a = cross sectional area of cylinder bore in m2, N = number of working strokes per second.

  9. Calculation indicated power Example 6.2 In a test, a certain single-cylinder 4-stroke engine develops a mean effective pressure of 5 bar at a speed of 3000 rev/min. The length of the engine stroke is 0.12 m and the cross-sectional area of the cylinder bore is 0.008m2. Calculate the indicated power of the engine in kW.

  10. Calculation indicated power Solution The engine is single-cylinder 4-stroke, so there is one working stroke for every two revolutions. N, the number of working strokes per second N = 3000÷60/2 = 25; P = 5 bar = 500 000N/m2, l = 0.12m; a = 0.008m2. Substituting these values in the formula gives ip = 500 000×0.12×0.008×25/1000kW = 12kW

  11. Number of working (power) strokes As mentioned, each cylinder of a 4-stroke engine produces one power stroke for every two revolutions of the crankshaft. In a multi-cylinder engine, each cylinder will produce one power stroke in every two revolutions of the crankshaft. A formula to determine the number of power strokes per minute for a multi-cylinder, 4-stroke engine is: number of power strokes per minute = (number of cylinders/2)×rev/min

  12. Indicated power Example 6.3 A 4-cylinder, 4-stroke engine develops an indicated mean effective pressure of 8 bar at 2800 rev/min. The cross-sectional area of the cylinder bore is 0.01m2 and the length of the stroke is 120 mm. Calculate the indicated power of the engine in kW. Solution

  13. Brake power The engine power that actually reaches the output shaft or flywheel of an engine is known as the brake power. It is the power that is measured by a dynamometer and a dynamometer is also known as a brake, hence the term, brake power. The simplest form of dynamometer is shown in Figure

  14. Simple dynamometer

  15. Simple dynamometer Work done per revolution of the flywheel = force × distance = (W−S)×2R joules (W−S×R also = T the torque that the engine is exerting. By substituting T for W−S×R the) work done per revolution becomes = T×2 joules

  16. Brake power Brake power = work done per second = T×2×number of revolutions per second This is normally written as brake power (bp = 2 TN where N = number of revolutions per second.) When the torque is in newtonmetres (N m), the formula bp = 2 TN gives the power in watts. As engine power is given in thousands of watts, i.e. kilowatts, the formula for brake power normally appears as: bp= 2 TN/1000kW

  17. Brake power Example 6.4:

  18. Volumetric efficiency

  19. Volumetric efficiency Example 6.5 A 4-cylinder 4-stroke petrol engine with a bore diameter of 100mm and a stroke of 110mm has a volumetric efficiency of 74% at an engine speed of 4000 rev/min. Determine the actual volume of air at STP that flows into the engine in 1 minute. Solution

  20. Thermal efficiency The thermal efficiency of an engine is a term that is used to express the effectiveness of an engine’s ability to convert heat energy into useful work. Thermal efficiency is the ratio of energy output of the engine to energy supplied to the engine in the fuel.

  21. Thermal efficiency Example 6.6 During a 10-minute dynamometer test on a petrol engine, the engine develops a brake power of 45kW and uses 3 kg of petrol. The petrol has a calorific value of 43 MJ/kg. Calculate the brake thermal efficiency.

  22. Mechanical efficiency The mechanical efficiency of an engine is defined as brake power indicated power. A certain engine develops a brake power of 120kW at a speed of 3000 rev/min. At this speed, the indicated power is 140 kW. Calculate the mechanical efficiency of the engine at this speed.

  23. THANK YOU
