  1. Traveling Salesman Problem (TSP) Chris Seto Andrea Smith

  2. Problem description • Given a list of a cities and distance between each pair of cities, what is the shortest possible route that visits each? • NP-hard problem • Problem usually modeled as an undirected graph • Produces a Hamiltonian Cycle

  3. History • Studies started in the 1800s by Sir William Hamilton and Thomas Kirkman of related problems • Icosian game invented in 1857 • TSP first studied in 1930s by Karl Menger, Hassler Whitney, and Merrill Flood • Solutions appeared in papers in mid-1950s • Determined to be NP-hard in 1972 by Richard M. Karp

  4. Application: Pick And Place • Printed circuit board (PCB) with locations where chips must be placed by robot • The faster the robot can place all components, the faster the PCB will be assembled • The faster the PCB can be assembled, the more PCBs can be made in the same amount of time

  5. Application: Logistics • Warehouse with many parts in various locations • Order is received for several parts which must be picked by robot or employee • What path should the picker follow to ensure that they fill the order in smallest amount of time? • Any number of TSP solutions can be applied and compared in parallel

  6. Application: UPS ORION • Route optimization used by UPS • Implementation started in 2008 • Saves ~35 million miles per year • Increased projected annual savings

  7. NP Hard Solution Methods • Devise an algorithm for an exact solution, even though it may only work efficiently for a small problem • Devise “Suboptimal” heuristic algorithms to yield good, but inexact solutions. • Find special cases for the problem for which better or exact heuristics are developed.

  8. Possible Approaches • Brute-force Method • Best for small number of nodes • Greedy Algorithm • Simplest algorithm for larger number of nodes • Genetic Algorithm • Generates “close to optimal” solutions

  9. Approach: Brute Force • Best for small number of nodes • Number of Hamiltonian Circuits = (n-1)! • Guaranteed an Optimal Solution • Complexity: ((n-1)!) • Tries all possible permutations and compares cost

  10. Brute Force Demo

  11. Approach: Greedy • Prim’s Algorithm, Kruskal’s Algorithm • Not guaranteed the optimal solution • “Close enough” solution • Prim’s Complexity: O() • Kruskal’s Complexity: O()

  12. Approach: Genetic Algorithm • New approach which uses natural selection to create close to optimal solutions • Hamiltonian cycles are continually “bred” with mutations • Crossover occurs between solutions • Relatively quickly produces a solution which is probably close to optimal

  13. Conclusion • Studies originally began 1800s, again in 1950s • Optimal solution found in ((n-1)!)time • Close enough solution found in O() • Used by… • UPS in ORION system • Pick and place • Many other graph representable systems

  14. Questions?

  15. References • http://en.wikipedia.org/wiki/Travelling_salesman_problem • https://xkcd.com/399/ (Comic) • http://www.forbes.com/sites/alexkonrad/2013/11/01/meet-orion-software-that-will-save-ups-millions-by-improving-drivers-routes/ • http://www.theprojectspot.com/tutorial-post/applying-a-genetic-algorithm-to-the-travelling-salesman-problem/5
