Presentation Transcript


The periodic table l.jpg

ThePeriodic Table


Elements and the periodic table l.jpg

Elements and the Periodic Table

˚ The Periodic Table is an organized chart of all of the elements in the entire universe

For example:

˚ Iron (Fe) is an element that is found on Earth. The Iron on earth is identical to the iron atoms found on meteorites.

&

˚ The iron atoms on Mars that make the soil red are the same too.


Elements and the periodic table3 l.jpg

Elements and the Periodic Table

˚ Elements are the building blocks of all matter

˚ Elements are the simplest substance in the entire universe. Elements cannot be broken down into other substances by chemical or physical means (except by nuclear means)

- Some examples of elements are: Gold (Au), Oxygen (O), Copper (Cu), Calcium (Ca), Iodine (I), Chlorine (Cl), and Neon (Ne)

˚ Each element has certain properties which distinguishes it from other elements

- These properties are: boiling point & melting point, atomic mass, atomic number, etc.


Elements and the periodic table4 l.jpg

Elements and the Periodic Table

˚ Elements have many uses:

Examples:

*Boron (B) can be found in many soaps. Boron is often found in the compound known as borax and refined for other uses.

*Carbon (C) is used in printer’s ink.

*Paper is composed of Carbon (C), Hydrogen (H), and Oxygen (O).


Organization of the periodic table l.jpg

Organizationof thePeriodic Table

˚ The periodic table is organized into horizontal rows and vertical rows

˚ The horizontal rows are called periods.

˚ The vertical rows are called groups.

˚ There are 7 periods and 18 groups in the periodic table

˚ Groups are numbered 1-18. These numbers refer to the number of electrons in the outer shell of the elements.

(This works for the first 20 elements)


Reading the periodic table l.jpg

ReadingthePeriodic Table

˚ Each square on the periodic table give particular information about the atoms of an element:

The number at the top of the square is the atomic number, which is the number of protons in the nucleus of the element

The element symbol is an abbreviation for the element name (usually 1-2 letters)

The element name is below the symbol

The number below the element symbol is the atomic mass. This is the mass of all of the isotopes of the element.


Fun with math l.jpg

Fun with Math!!!

Much information can be derived about an element’s atomic structure just from the information provided in it’s element box.

*atomic number = number of protons

*atomic mass number= the total number of protons and neutrons

*To find the number of neutrons, you take the atomic number and subtract the atomic mass number

number of neutrons= atomic number - atomic mass number

* The number of protons is equal to the number of electrons

number of protons= number of electrons


Reading the periodic table8 l.jpg

ReadingthePeriodic Table

Open your Chemical Interactions text to page 20-21.

˚Metals on the left side of the periodic table and nonmetals on the right side.

-The zigzag line on the right side of the table separates metals from nonmetals.

˚ Notice: The black bolded elements are solid, the white letters are a gas and there are 2 liquids on the periodic table


Categories of the periodic table l.jpg

  • Metals

  • (general)

  • Hard and shiny

  • 3 or less valence electrons

  • Form positive ions by losing electrons

  • Good conductors of heat and electricity

Categoriesof thePeriodic Table


Categories of the periodic table10 l.jpg

  • Metals – (specific)

  • *Reactive metals (alkali and alkaline earth metals)-

  • -Alkaline earth metals- very reactive and are found in the earth’s crust.

  • -Alkali metals- soft and malleable & ductile ( bendable and can be reshaped)

  • *Transition metals (includes poor metals)-

  • less reactive than most metals

  • found in foods we eat, for industry (steel, copper), modern technology catalytic converters, and incandescent light bulbs), and alloys (steel and brass).

  • *poor metals- soft, low melting points, ex: lead

  • *Rare earth metals (lanthanide series and actinide series)-

  • -previously believed to be rare, however as mining improved, scientist realized that they are not rare, just hard to isolate.

Categoriesof thePeriodic Table


Reading the periodic table11 l.jpg

NonMetals

-Gases or dull, brittle solids

-Do not reflect light

-Cannot be rolled into wires or pounded into sheets

-At room temperature, they can be solids or gases, except Bromine, which is a liquid.

-5 or more valence electrons

-From negative ions by gaining electrons

-Poor conductors of heat and electricity

*Noble gases-Group 18, almost never react with other elements

-Some are used to make colorful lights

*Halogens-Group 17, very reactive nonmetals that form salts when combined with many metals.

-Uses: to kill harmful microorganisms in hospitals, to purify drinking water and prevent growth of algae in swimming pools.

ReadingthePeriodic Table


Reading the periodic table12 l.jpg

  • Metalloids

  • Appearance will vary

  • 3 to 7 valence electrons

  • Form positive and/or negative ions

  • Conduct better than nonmetals but nor as well as metals

  • Properties of metals and nonmetals

  • Often used in semi-conductors for computer chips

  • NOTE: any element above 92 is too unstable to occur in nature and must be done in a lab, scientist were able to predict existence of elements (neon and germaniuim before they were even discovered

ReadingthePeriodic Table


Student misconceptions l.jpg

Student Misconceptions

*All metals are not magnetic

*Iron is not the only metal that has magnetic properties

*Electrical conductivity is not a property of only metals

*Carbon rod (graphite) is actually an element with properties that are intermediate between a metal and a nonmetal

*Not all elements are solids


The end now you get to l.jpg

The End…

now you get to…


Slide15 l.jpg

Memorize the 1st

30 element names

and symbols!!!

There will be pop quiz very soon over this information!!!


Elements and the periodic table16 l.jpg

Elements and the Periodic Table

˚ Even though elements cannot be broken down, they can be combined with other elements in order to form new substances.

˚ For example salt is a compound of sodium and chlorine: NaCl

˚ Elements have many uses:

EX: Boron (B) can be found in many soaps. Boron is often found in the compound known as borax and refined for other uses.
