Presentation Transcript

Agenda l.jpg
Agenda Applications

  • SCXML controls the flow of an application

  • SCXML controls modalities

    • VoiceXML

    • XHTML

    • Others, e.g., InkML, SVG

  • SCXML controls Web services


State chart xml l.jpg
State Chart XML Applications

  • Represents a state transition system

    • States

    • Transitions

A

B


Possible actions within a state l.jpg
Possible Actions within a <state> Applications

  • Multimodal life cycle events

    <start … />

    <cancel … />

    <pause … />

    <resume … />

    <data … />

  • Executable content

    <assign/>

    <var>

    <script/>

    <if/>, <elseif/>, <else/>

    <log/>

A

<if …>

<start … />

<else/> <log …/>

</if>


Scxml l.jpg
SCXML Applications

  • Sequentially perform the actions in two states

<state id="A">

<prepare … />

<transition event= "done" target="B"/>

</state>

<state id="B">

<start … />

</state>

A

<prepare … />

done

<start … />

B


Scxml6 l.jpg
SCXML Applications

  • Conditional branch

<state id="A">

<prepare … />

<transition event= "done"

cond="result='OK̍'" target="B"/>

<transition event= "done"

cond="result='Opps'" target="C"/>

</state>

A

<prepare … />

done

OK

done

Opps

B

C


Scxml7 l.jpg
SCXML Applications

  • Parallel States

<state id="A">

<transition …. target="B"/>

</state>

<state id="B"/>

<parallel>

<state id="C"/>

<state id="D"/>

</parallel>

</state>

A

B

C

D


Agenda8 l.jpg
Agenda Applications

  • SCXML controls the flow of an application

  • SCXML controls modalities

    • VoiceXML

    • XHTML

    • Others, e.g., InkML, SVG

  • SCXML controls Web services


Scxml voicexml l.jpg
SCXML + VoiceXML Applications

<state id="A">

<start name= "getAirport.vxml" />

<transition event= "done"

target="B"/>

</state>

A

<?xml version="1.0"?>

<vxml version="3.0" xmlns = "http://www.w3.org/2001/vxml">

<form id = "destination" >

<field name = "Airport">

<grammar src= "airport.grxml"/>

<prompt>Say your destination airport </prompt>

<grammar src= “Airport.grxml”

</field>

<filled>

<send event= "done" namelist = "Airport" />

</filled>

</form>

</vxml>

getAirport.vxml

done

B

state id="B">

<start … />

</state>


Scxml xhtml l.jpg
SCXML + XHTML Applications

<state id="A">

<start name= "getAirport.xhtml" />

<transition event= "done"

target="B"/>

</state>

A

<html/>

<head>

<ev:listener ev:event="onchange" ev:observer="bodyId" ev:handler= "sendDone()" />

<script> {function sendDone…} </script>

</head>

<!--xhtml code -->

<body id="bodyId"/><p>enter month</p>

<input type="text" id="month"/>

</body>

</html>

getAirport.xhtml

done

B

state id="B">

<start … />

</state>


Scxml xhtml voicexml l.jpg
SCXML + XHTML + VoiceXML Applications

A

B

<state id="A1">

<start name= "getAirport.vxml" />

<transition event= "done"

target="B"/>

</state>

A1

<state id="A2">

<start name= "getAirport.xhtml" />

<transition event= "done"

target="B"/>

</state>

A2

done

done

B

state id="B">

<start … />

</state>


Scxml inkml voicexml l.jpg

Another example of multiple modalities Applications

SCXML + InkML + VoiceXML

A

B

<state id="A1">

<start name= "getStuff.vxml" />

<transition event= "done"

target="B"/>

</state>

A1

<state id="A2">

<start name= "getStuff.Inkml" />

<transition event= "done"

target="B"/>

</state>

A2

done

B

state id="B">

<start … />

</state>


Scxml inkml voicexml13 l.jpg
SCXML + InkML + VoiceXML Applications

A

B

<state id="A1">

<start name= "getStuff.vxml" />

<transition event= "done"

target="B"/>

</state>

A1

<state id="A2">

<start name= "getStuff.Inkml" />

<transition event= "done"

target="B"/>

</state>

A2

<interpretation mode = "speech">

<travel>

<to hook="ink"/>

<from hook="ink"/>

<day> Tuesday </day>

</travel>

</interpretation>

done

B

state id="B">

<start … />

</state>


Scxml inkml voicexml14 l.jpg
SCXML + InkML + VoiceXML Applications

A

B

<state id="A1">

<start name= "getStuff.vxml" />

<transition event= "done"

target="B"/>

</state>

A1

<state id="A2">

<start name= "getStuff.inkml" />

<transition event= "done"

target="B"/>

</state>

A2

<interpretation mode = "ink">

<travel>

<to>Las Vegas </to>

<from>Portland </from>

</travel>

</interpretation>

<interpretation mode = "speech">

<travel>

<to hook="ink"/>

<from hook="ink"/>

<day> Tuesday </day>

</travel>

</interpretation>

done

B

state id="B">

<start … />

</state>


Scxml inkml vxml l.jpg

<interpretation mode = "interp1"> Applications

<travel>

<to> Las Vegas </to>

<from> Portland </from>

<day> Tuesday </day>

</travel>

</interpretation>

SCXML + InkML + VXML

A

B

<state id="A1">

<start name= "getStuff.vxml" />

<transition event= "done"

target="B"/>

</state>

A1

<state id="A2">

<start name= “getStuff.inkml" />

<transition event= "done"

target="B"/>

</state>

A2

<interpretation mode = "ink">

<travel>

<to>Las Vegas </to>

<from>Portland </from>

</travel>

</interpretation>

<interpretation mode = "speech">

<travel>

<to hook="ink"/>

<from hook="ink"/>

<day> Tuesday </day>

</travel>

</interpretation>

done

B

state id="B">

<start … />

</state>


Agenda16 l.jpg
Agenda Applications

  • SCXML controls the flow of an application

  • SCXML controls modalities

    • VoiceXML

    • XHTML

    • Others, e.g., InkML, SVG

  • SCXML controls Web services


Scxml control more than just modalities l.jpg
SCXML Control More Than Just Modalities Applications

vxml

<start … />

  • SQL

  • Complex calculations

  • Web services

<start … />

sql

<start … />

complexCalculation

xhtml

<start …/>


References l.jpg
References Applications

  • State Chart XML (SCXML): State Machine Notation for Control Abstraction

    • http://www.w3.org/TR/scxml/

  • Multimodal Architecture and Interfaces

    • http://www.w3.org/TR/mmi-arch/

  • Commons SCXML (Open Source)

    • http://jakarta.apache.org/commons/scxml/


Summary l.jpg
Summary Applications

  • SCXML controls the flow of an application

  • SCXML controls modalities

    • XHTML

    • VoiceXML

    • Others, e.g., inkML, SVG

  • SCXML controls Web services
