Presentation Transcript


Consolidspain

  • http://www.consolidspain.org


Consolidspain

  • http://www.consolidspain.org

  • ¿WHY IS IT IMPORTANT

  • THE STABILIZATION AND WATERPROOFING SOIL?

  • INDIA

  • Rainfall of 3 days on a bad embankment stabilization Consequence :

  • Collapse of the railway embakment

  • 122 dead people

  • COLOMBIA

  • Bad stabilization of the wal of the hill

  • Consequence:

  • Mud Sliding on the town

  • 34 dead people


Consolidspain

  • http://www.consolidspain.org

  • TRADITIONAL SYSTEMS OF SOIL STABILIZATION

CHEMICAL

REACTORS

Products that try to change the soil chemically reacting his properties

Waterproofing, Geotextile membrane, Clay, Concrete

BINDERS AND

RUBBERS

Products that bind the soil as

binders agents

Cement, Lime, Bitumen, Asphalt, Polymers, Resins

HYBRID SYSTEMS

Systems that combine both methiods


Consolidspain

  • http://www.consolidspain.org

  • PROBLEMS OF TRADITIONAL SYSTEMS

CHEMICAL

REACTORS

Products that try to change the soil chemically reacting his properties

Waterproofing, Geotextile membrane, Clay, Concrete

BINDERS AND

RUBBERS

Products that bind the soil as

binders agents

Cement, Lime, Bitumen, Asphalt, Polymers, Resins

HYBRID SYSTEMS

Systems that combine both methiods

  • - The need for a strict relationship between the specific surface of soil to be treated

  • and the amount of binder

  • - Organic Pollution

  • - The reactor needs for the appropriate reaction always the same means, and no soil is identical to another.


Consolidspain

  • http://www.consolidspain.org

  • PROBLEMS OF THE TRADITIONAL

  • SYSTEMS

  • Are applicable only under certain conditions more or less stringent

  • Applicable only in certain soil types and certain soil pellets

Fail due to the fact that a soil rarely presents a homogeneous

composition point to point

  • ¡ It is impossible to predict the outcome of treatment !

  • Does not have these problems, as it is NOT

  • The system

  • NOT A BINDER, is not sticking the particles between them

  • NOT A REACTOR, is not changing the chemical soil structure


Consolidspain

  • http://www.consolidspain.org

Consolid System basics

Consolid systemis a simple copy of whatnaturedoes

CONSOLID SYSTEM

Metamorphic rock

Sedimentary Rocks

Igneous Rock

Hardening

Wear for the atmosferic action, mechanical and chemical

Sediments

Natural soil

But there is a small problem…

Thisprocesstakesmillions of years…

has achievedto reduce this time tozerO


Consolidspain

  • http://www.consolidspain.org

  • Consolid System basics

All cohesive soil has the ability to petrify again, for it needs:

A long period

time

Very high pressure

Has achieved to reduce this time to zero


Consolidspain

  • http://www.consolidspain.org

BUT…WHAT IS THE CONSOLID SYSTEM?

CONSOLID® is a stabilization and

sealing high tech soil system

CONSOLID ® System makes soil compaction been totally irreversible


Consolidspain

  • http://www.consolidspain.org

CONSOLID SYSTEM

Available Soil

IMPLEMENTATION OF CONSOLID Liq® + SOLIDRY®

Stabilized

Material


Consolidspain

  • http://www.consolidspain.org

TECHNICAL EFFECTS OF THE CONSOLID SYSTEM

SUPPORTING BETTER VALUES BETWEEN 3 AND

5 TIMES

RESISTENCE

USE OF 75 TO 100% OF LAND AVAILABLE (SAVING ON COLLECTION, REMOVAL OF MATERIAL AND CONTRIBUTION)

ECONOMY


Consolidspain

  • http://www.consolidspain.org

TECHNICAL EFFECTS OF THE CONSOLID SYSTEM

THE IMPROVEMENT OF THE

PROPERTIES AND THE LIFT

OF THE SOIL IS PERMANENT

ECONOMY

FIRMNESS AND STABILITY OF

THE TREATED SOIL => BEST GROWING DURABILITY

ECONOMY

ACTIVE THE COHESIVE

FORCES IN ANY TYPE OF SOIL AND REDUCE THE INFLUENCE OF WATER

ECONOMY

RESISTENCE


Consolidspain

  • http://www.consolidspain.org

TECHNICAL EFFECTS OF THE CONSOLID SYSTEM

MORE GROUND LIFT :

REDUCING THE ROLLING

LAYERS from 60mm to 20/25mm

ECONOMY

RESISTENCE

SAME QUANTITY OF

ADDITIVES IN ALMOST ALL

KINDS OF SOIL

ECONOMY


Consolidspain

  • http://www.consolidspain.org

TECHNICAL EFFECTS OF THE CONSOLID SYSTEM

THE APPLICATION IS MADE

WITH THE EXISTING MACHINERY PARK

SIMPLICITY

ASSURED OUTCOME IN

ADVANCE FOR LABORATORY

TESTS

ECONOMY

SAFETY ENVIRONMENT

ECOLOGY


Consolidspain

  • http://www.consolidspain.org

CONSOLID SYSTEM APPLICATIONS

  • ROADS AND ACCESS TO LAND, RURAL AND MOUNTAIN (even

  • under heavy traffic, allowing its use and preserving the road under any

  • weather condition, prolonged rainfall, high humidity, snow and high thermal

  • amplitude)

- Stabilization of VERGES AND SLOPES

- Construction of BASES Y SUB-BASES

- Construction of AIRPORT RUNWAY

- Construction of NEW ROADS (Motorway, Highway…)

- Rehabilitation of WAYS, ROADS IN DISREPAIR


Consolidspain

  • http://www.consolidspain.org

CONSOLID SYSTEM APPLICATIONS

- Stabilization, Improvement and reuse of LOW QUALITY LANDS

- Construction of DAMS, LANDFILLS AND WATERPROOFING IN IRRIGATION SYSTEMS

- Construction of INDUSTRIAL AREAS, STOWAGE AREAS, , etc.

- Construction of URBANIZATIONS

- Construction of GOLF COURSES

- Construction of RAIL ROADS

- Construction of SOIL EROSION


Consolidspain

  • http://www.consolidspain.org

APPLICATION SYSTEM FOR STABILIZATION AND / OR WATERPROOFING

1. Analysis of soil samples in laboratory

Determine the optimal mixture

2.Mixture of products with the local soil

3. Compacting


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Rehabilitation of a paved road on a levee in Kraayensteinsedijk, Sommelsdijk, Netherlands

- Improvement of the base and sub-base through CONSOLID system

- Paved by asphalt application with layer of 8 cms

- Performance of 3.5 Kms in lenght . Touch area 12.250 sqm

¡ The time taken for the whole performance was 3 days!

Example of road construction with

CONSOLID system

Conventional Road Construction


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Bulding roads and ways in a Cotton Plantation in Prov. Del Chaco, Argentine

- Making roads with CONSOLID system

- Use of itself existing machinery in the cotton plantation (grinders and rotary disc harrows)

- Performance surface : 100.000m²

Outcome: Easy access to the markets on the production obtained


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Heavy Road Transport. Army General Headquarter in Pakistán, Karachi

- Making roads with CONSOLID System

- Using 80% of the existing sand (cohesionless) + 20% clay

-.Improved C.B.R. from 6% and 7% to 40% and 45%. Increased C.B.R. in a 650%

Outcome: Cost Saving of 30%


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Main Railway Line Budapest-Viena Embankment Hegyeshalom, Hungary

-Base stabilized by Consolid System

- Treated surface : 40.000 m²

-Increases obtained from the pressure plate (MPa increased 5 times):> 100N/

Outcome: Cost Saving of 40%


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Embankment stabilization of Czech railways

- Base stabilized by Consolid System

- Average load of 18 Millon TON/Year

- The Saving around 40% of the conventional cost

Outcome: Radical Increase of the bearing capacity


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Heavy Industrial Area. Aluminium & Chemi BV, Rotterdam

- Dynamic pressure of the untreated plate: 42 Mpa (N / mm ²). After treatment: 179 MPa (N / mm ²)

- Use: Storage of aluminum anodes transported on trailers of 70 tons. Pressure of 23 tons per axle

- Savings of 50% over the prior use of concrete slabs that were replaced every 2 years.

Outcome: Radical Increase of the bearing capacity and durability


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Waste disposal area. Kaposvár, Nyíregyháza, Dunakezi, Dömsöd. Hungary

- Performance Surface of CONSOLID system: 80.000m²

- Implementation of Consolid System to prevent leakage of waste through the soil bases

- K value of land: 1 * 10-5m ³ / s. After the application improves the impermeability 100 times with k = 1 * 10-7m ³ / s

Outcome:Substantial improvement in the impermeability of the soil


Consolidspain

  • http://www.consolidspain.org

PERFORMANCE EXAMPLES WITH CONSOLID SYSTEM

Reconstruction of artificial lake Ziegeleipark Heilbronn-Böckingen. Germany

- Performance surface of Consolid System : 14.000m²

- With values of k = 1 * 10-6m ³ / s reached the lake never filled due to the loss be higher than the contribution

- After application of Consolid System: 100 times improved impermeability with k = 1 * 10-8m ³ / s and the lake is always full with many types of plants, frogs and fish to grow and swim in the lake.

Outcome: Improved soil impermeability and safety to the environment

Outcome: Improved soil impermeability and safety to the environment


Consolidspain

  • http://www.consolidspain.org

EcoSoil de Compactaciones, S.L.

&

Procesos y Aplicación de Césped y Consolid, S.L.

BARCELONA (Barcelona) - España

Contacto: Francisco Pac - Telf: +34.638 277 500

E-mail: [email protected]
