Research activity including geographical ontology modules for efficient semantic web reuse

Research ActivityincludingGeographical Ontology Modules forEfficient Semantic Web Reuse

David George, University of Central Lancashire


Research activities

Research Activities

  • Semantic Heterogeneity

    • Structural and Semantic discrepancies in database conceptualisation and development

  • Data and Information Integration

    • Federated Databases

    • Mediators: Global-as-View, Local-as-View

    • Information Brokering Systems and use of Ontology

  • Semantic Web and Ontology

  • Practical interaction with Semantic Web Technologies

    • Protégé, FaCT++, SWOOP, and Jena API Toolkit


Research activities1

Research Activities

  • Development of Jena-based Java Browser Interface: inc

    • Reading OWL and querying SPARQL

    • RDF storage in MySQL

  • Foundation Ontology: SUMO, DOLCE, CyC, BFO (Snap and Span)

  • Design Best-Practice: Modularity in Ontology development (Rector, 2003)

  • Experimentation with small-scale OWL ontologies

  • Formal Concept Analysis - using Concept Explorer


Structural semantic heterogeneity

Structural & Semantic Heterogeneity

  • Abstraction Level Conflicts

    • generalisation/specialisation/aggregation

  • Schematic Discrepancies

    • Objects represented differently

    • Data, attributes, entity

  • Entity Definition Conflicts

    • naming conflicts (synonyms and homonyms)

    • database identifier conflicts e.g. id# v. name

  • Data Value Conflicts

    • temporal Inconsistency (last update)

    • data representation (integer v. string/precision/scale)


Data integration

Data Integration

Global Domain

Agreements

Knowledge

Digital media

Visual/Spatial/Temporal Data

[Kiosk/Geographic/Flights/Forecasting]

Focus – Semantics

Domain-specific

Information

Structured,

Semi-structured

Text repositories

Data

Structured DBs, Files

Focus – Systems

& Communications

System

Schema Integration

Common Data Models

Virtual Integration

Single Ontologies

Multiple ontologies,

Inter-ontological

Local Task

Schemas

Federated DBS

Federated IS (inc Mediators)

Information Brokering

1985

1995


Research activity including geographical ontology modules for efficient semantic web reuse

Jena Toolkit – OWL interface


Ontology specification best practice

Ontology Specification: Best Practice

Ontology elements can be described as:

  • Primitives: self-standing entities (objects/forms) e.g. Structure, Process, System, Organisation

  • Relations: concept-linking properties e.g. XhasFormY, hasRole …

  • Roles: functions e.g. RailTransportRole

and

  • Definables: dependent concepts defined by combining Primitives, Relations, and Roles:

  • RailwayBridge≡Bridge⊓ (hasForm∃ Structure⊓

  • hasRole∃ RailTransportRole)


Formal concept analysis

Formal Concept Analysis

  • Using Concept Explorer

  • Examined how Concept Analysis may be useful in identifying Classes and Instances in database tables

  • Considered structural heterogeneity:

    • Classes represented by single entity (table)

    • Classes represented by table joins

    • Classes as subset of table records

    • Instances represented by entity, attribute, data (record)


Formal concept analysis1

Formal Concept Analysis

Example:

Classes represented by table joins


Creating geographical ontology modules for efficient semantic web reuse

Creating Geographical Ontology Modules forEfficient Semantic Web Reuse


Ontology and integration

Ontology and Integration

  • Ontology Reuse is a key Integration benefit (Noy and Hafner, 1997 ).

  • Ontology development still at a stage where little interchange between organisations?

  • Merger, Alignment and Mapping complexity issues with Integration.

  • Developer reluctance – easier to re-invent own local ontology than reuse.

  • Reuse of an external ontology will likely result in descriptive and structural irrelevances.

  • Smaller component ontology modules –improvised as required – may encourage wider usage/take-up


Ontology integration

Ontology Integration

Possible Ontology [ On ] Objectives

  • Merger: OA + OB→ OC

  • Alignment: OA≡ OB≡ OC

  • Mapping: a virtual integration where OA, OB and OC concepts are semantically related.

    Methods

  • 1 and 2 are achieved by rewriting (reformulation).

  • Original ontologies are subsumed or made consistent (respectively).

  • 3 is achieved by mappings between concepts of imported ontologies. A, B and C endure autonomously.

  • Ontology Reuse, in this presentation, refers to 3: Mapping.

  • (Pinto et al., 1999, Noy and Musen, 1999, de Bruijn et al., 2004, Visser and Tamma, 1999, Kalfoglou and Schorlemmer, 2003, Ding et al., 2002)


1 informal specific class reuse

1 - “Informal” specific Class Reuse

  • Using namespace declaration to explicitly specify a single external concept, e.g.

<rdf:RDF xmlns="http://www.livewiredg.myby.co.uk/rdf/geo-layers/rail.owl#"

xmlns:cyc="http://www.cyc.com/2003/04/01/cyc#" >

<owl:Class rdf:about="&cyc;TransportationCompany"/>

<owl:Class rdf:ID="RailOperator">

<rdfs:subClassOf rdf:resource="#RailwayComponent"/>

<rdfs:subClassOf rdf:resource="&cyc;TransportationCompany"/>

</owl:Class> ……..

  • How would an agent understand the Cyc context of the superclass of “cyc:TransportationCompany”


2 formalised specific class reuse

2 - “Formalised” specific Class Reuse

E-Connections

  • Representation and reasoning with foreign ontologies (Grau et al, 2006)

  • Allows specific concept linking. Few tools available e.g. SWOOP (OWL Ontology Editor)

<rdf:RDF

xmlns:global="http://www.livewiredg.myby.co.uk/rdf/geo-layers/global.owl#"

xmlns=http://www.owl-ontologies.com/flight.owl# ……..>

<owl:Class rdf:about=“&global;Artifact"/>

<owl:Class rdf:ID="Helicopter">

<rdfs:subClassOf>

<owl:Restriction>

<owl:onProperty>

<owl:LinkProperty rdf:about="#hasForm"/>

</owl:onProperty>

<owl:someValuesFrom rdf:resource="&global;Artifact"/>

</owl:Restriction>

</rdfs:subClassOf>

</owl:Class>

<owl:LinkProperty rdf:ID="hasForm">

<owl:foreignOntology rdf:resource="&global;"/>

<rdfs:domain rdf:resource="#Helicopter"/>

<rdfs:range>

<owl:foreignClass rdf:about="&global;Artifact">

<owl:foreignOntology rdf:resource="&global; "/>

</owl:foreignClass>

</rdfs:range>

</owl:LinkProperty>


3 modularity by sub domain separation

3 - “Modularity” by sub-domain separation

  • SWOOP permits ontology partitioning (module extraction)


4 class reuse by ontology import

4 - Class reuse by Ontology Import

Objective:

Map Rail Ontology class “RailOperator” to Cyc Ontology class “TransportationCompany”

Action:

Import Opencyc into Rail > 6.8MB

Effect:

Adds:

2843 classes

1256 properties

load time 1.5 to 7.5 mins

Protégé “out of memory”


Alternative reuse approach

Alternative Reuse approach?

  • Consider the way Ontologies conceptualised and developed?

  • Break down domain ontologies into sub-domains (modules)

  • Try to achieve disjoint structures – minimise redundancy

  • Can be demonstrated using Geographical context

  • Geographical concepts interface with virtually every aspect of daily life and feature prominently in information management systems.

  • Geographical ontologies offer a logical vehicle, to examine how modules can be specified efficiently and effectively.


Ontological inefficiency

Ontological Inefficiency

  • Potential redundancy

  • Vulnerability to change

  • How relevant are they?

  • Ontology Reuse - Imports

    • E.g. if OTN 1 is imported: what do we see?

    • Ontology much smaller than Cyc, but still multiple sub-domains

  • Only for an application that uses ALL concepts

1OTN - Ontology of Transportation Networks (Lorenz et al, 2005)


Ontology permanence

Fixed Classes

Variable Classes

Ontology Permanence


Ontology geo modules

Ontology “Geo-Modules”

Transportation

Tourism

Multi-modal

Geo-Modules


Land transport

multimodal

single-mode ?

Land Transport


Transport interchange

Transport Interchange

  • multimodal: road-rail

  • within a town, service facility


Visualising our transportation domain

M6

M67

A6

Visualising Our Transportation Domain


Rail transport ontology

PopulationGroupConcept

Road domain

endsAt*

endsAt*

City

City

startsFrom*

startsFrom*

Rail Transport Ontology

Q: rename LevelCrossing → RoadCrossing? But we don’t do Roads in Rail!


Road transport ontology

PopulationGroupConcept

Rail domain

endsAt*

City

startsFrom*

Road Transport Ontology

Q: reclassify ChannelTunnelTerminal → Road Concept? But we don’t do Rail in Roads!


Landtransport ontology

LandTransport Ontology


Landtransport import consequences

LandTransport: Import Consequences

  • We would need to import: Road, Rail, PopGroups into LandTransport

  • For just Road and Rail it results in duplications and redundancy


Revisualisation transportation layers

M6

M67

A6

Revisualisation: Transportation Layers


How do we develop geo modules

How do we develop “Geo-Modules”

  • Need to “de-integrate” to allow low-cost integration

  • Aim towards “effectively” disjoint domains

  • Deliver by removing concept duplication between modules – redundancy

  • Need to promote/relegate multi or single-context concepts and relations


Transportation domain layers

Transportation Domain Layers


Modular ontology ve ve

Modular Ontology: +ve/-ve

  • Advantages

    • Small is manageable

    • Select only required building block modules

    • Independent therefore less vulnerable to change

    • Change is isolated to the module and subsuming domain?

  • Disadvantages

    • Increased mappings?

    • Needs to be examined


References

References

DE BRUIJN, J., DING, Y., ARROYO, S. & FENSEL, D. (2004) Semantic Information Integration in the COG project [online]. Digital Enterprise Research Institute (DERI), University of Innsbruck. Available from: http://www.cogproject.org/publications/sii-wp.pdf. [Accessed 19 December 2004].

DING, Y., FENSEL, D., KLEIN, M. & OMELAYENKO, B. (2002) The semantic web: yet another hip? Data & Knowledge Engineering,41(2), pp. 205-227.

DING, Y. & FOO, S. (2002) Ontology Research and Development: Part 2 - A Review of Ontology mapping and evolving. Journal of Information Science,28(5), pp. 383-396.

GRAU, B. C., PARSIA, B. & SIRIN, E. (2006) Combining OWL ontologies using E-Connections. Journal of Web Semantics: Science, Services and Agents on the World Wide Web,4(1), pp. 40-59.

KALFOGLOU, Y. & SCHORLEMMER, M. (2003) Ontology mapping: the state of the art. The Knowledge Engineering Review,18(1), pp. 1-31.

NOY, N. F. & HAFNER, C. D. (1997) The State of the Art in Ontology Design - A Survey and Comparative Review. AI Magazine,18(3), pp. 53-74.

NOY, N. F. & MUSEN, M. A. (1999) SMART: Automated Support for Ontology Merging and Alignment Stanford, MA, Stanford Medical Informatics. Available from: http://www-smi.stanford.edu/pubs/SMI_Reports/SMI-1999-0813.pdf. [Accessed 22 December 2004].

PINTO, H. S., GÓMEZ-PÉREZ, A. & MARTINS, J. P. (1999) Some Issues on Ontology Integration. In: Proceedings of IJCAI-99 workshop on Ontologies and Problem-Solving Methods (KRR5). Stockholm, Sweden, August 2 1999. CEUR-WS, pp. 7.1-7.12.

RECTOR, A. L. (2003) Modularisation of domain ontologies implemented in description logics and related formalisms including OWL. In: Proceedings of 2nd International Conference On Knowledge Capture. Sanibel Island, FL, USA, 2003. ACM Press, New York, NY, USA, pp. 121-128.

VISSER, P. R. S. & TAMMA, V. A. M. (1999) An Experience with Ontology-based Agent Clustering. In: Proceedings of IJCAI-99 workshop on Ontologies and Problem-Solving Methods (KRR5). Stockholm, Sweden, 2 August 1999. CEUR-WS, pp. 12.1-12.13.
