Presentation Transcript

Somatic cell nuclear transfer
Somatic Cell Nuclear Transfer

  • Researchers clone animals by nuclear transplantation

    • SOMATIC CELL NUCLEAR TRANSFER:A nucleus of an egg cell is replaced with the nucleus of a somatic cell from an adult

  • Thus far, attempts at human cloning have not succeeded in producing an embryo of more than six cells

    • Embryonic development depends on the control of gene expression (aka protein synthesis)

  • Reproductive vs therapeutic cloning
    Reproductive vs. Therapeutic Cloning

    • In reproductive cloning, the embryo is implanted in a surrogate mother. The goal is to produce a cloned offspring.

    • In therapeutic cloning, the idea is to produce a source of embryonic stem cells.

      • Stem cells can help patients with damaged tissues.

      • Stem cells are NOT specialized in structure and function, therefore they can take on the role of damaged cells in damaged tissues.

    Dolly the Sheep


    Nucleus fromdonor cell

    Implant blastocystin surrogate mother

    Clone of donoris born(REPRODUCTIVEcloning)

    Removenucleusfrom eggcell

    Add somaticcell fromadult donor

    Grow in culture to producean early embryo (blastocyst)

    Remove embryonic stem cells from blastocyst andgrow in culture

    Induce stemcells to formspecialized cellsfor THERAPEUTICuse

    Reproductive vs. Therapeutic Cloning

    Proteins turn genes on or off
    Proteins turn genes on or off

    • Proteins interacting with DNA turn prokaryotic genes on or off in response to environmental changes.

    • The process by which genetic information flows from genes to proteins is called gene expression.

      • Our earliest understanding of gene control came from the bacterium E. coli (Reminder: Bacteria are prokaryotes.)

    Cellular differentiation
    Cellular Differentiation

    • Differentiation yields a variety of cell types, each expressing a different combination of genes

    • In multicellular eukaryotes, cells become specialized as a zygote develops into a mature organism

      • Different types of cells make different kinds of proteins.

      • Different combinations of genes are active in each type.

    Retain genetic potential
    Retain Genetic Potential

    • Differentiated cells may retain all of their genetic potential. (Even if turned off, the gene is still present.)

    • Most differentiated cells retain a complete set of genes

      • In general, all somatic cells of a multicellular organism have the same genes.

      • So a carrot plant can be grown from a single carrot cell.

    Early nuclear transfer
    Early Nuclear Transfer

    Tadpole (frog larva)

    Frog egg cell



    Intestinal cell


    Transplantationof nucleus




    • The cloning of tadpoles showed that the nuclei of differentiated animal cells retain their full genetic potential

    Dolly again
    Dolly again

    The first mammalian clone, a sheep named Dolly, was produced in 1997

    Dolly provided further evidence for the developmental potential of cell nuclei.

    Applications of nonhuman mammalian cloning
    Applications of Nonhuman Mammalian Cloning

    • Connection: Reproductive cloning of nonhuman mammals has applications in basic research, agriculture, and medicine.

      • Scientists clone farm animals with specific sets of desirable traits.

      • Piglet clones might someday provide a source of organs for human transplant.

    Therapeutic cloning
    Therapeutic Cloning

    • Connection: Because stem cells can both perpetuate themselves and give rise to differentiated cells, they have great therapeutic potential

    • Adult stem cells can also perpetuate themselves in culture and give rise to differentiated cells

      • But they are harder to culture than embryonic stem cells.

      • They generally give rise to only a limited range of cell types, in contrast with embryonic stem cells.

    Liver cells

    Culturedembryonicstem cells

    Nerve cells

    Heart muscle cells

    Different cultureconditions

    Different types ofdifferentiated cells

    Gene regulation in eukaryotes
    Gene Regulation in Eukaryotes

    DNA packing in eukaryotic chromosomes helps regulate gene expression.

    A chromosome contains a DNA double helix wound around clusters of histone proteins.

    DNA packing tends to block gene expression.



    “Beads ona string”

    Nucleosome(10-nm diameter)

    Tight helical fiber(30-nm diameter)

    Supercoil(200-nm diameter)


    Metaphase chromosome

    Female mammals
    Female Mammals



    Cell divisionandX chromosomeinactivation

    Orange fur

    Active X

    X chromosomes

    Inactive X

    Inactive X

    Allele fororange fur

    Black fur

    Active X

    Allele forblack fur

    In female mammals, one X chromosome is inactive in each cell.

    An extreme example of DNA packing in interphase cells is X chromosome inactivation

    Selective breeding
    Selective Breeding

    • Since ancient times, humans have bred animals and plants to increase the likelihood of certain desirable traits.

      • Example: Hunting dogs or larger fruits

    • Two methods are used:

      • Hybridization: crossing different parent organisms with different forms of a trait to produce an offspring with a specific trait

        • Example: hybrid rice that produces greater yield and another hybrid rice that contains greater nutritional properties

        • Disadvantage: Time-consuming and expensive

      • Inbreeding: crossing closely related parent organisms who have been bred to have desired traits to ensure that the traits are passed on

        • Example: German shepherd dogs

        • Disadvantage: Undesirable recessive traits are often passed down with the desirable traits.

    Genetic engineering
    Genetic Engineering

    • A process by which an organism’s DNA is manipulated in order to insert the DNA of another organism (creates recombinant DNA)

      • Purpose: Incorporate the desirable traits of one organism into another organism

      • Example: Bioluminescent trait – A type of jellyfish contains a protein (GFP: green fluorescent protein) that causes it to glow. Scientists insert the DNA that codes for GFP into the DNA of mosquito larvae so that they will glow. Mosquito populations can be controlled as the larvae are more easily located.

      • Produces “genetically modified organisms”

    Dna tools
    DNA Tools

    • Selective breeding and genetic engineering require scientists to use special tools or processes to manipulate DNA.

      • Restriction Enzymes: cut DNA into smaller fragments with “sticky ends” that allow it to connect to other fragments of DNA

      • Gel Electrophoresis: electrical currents separate DNA fragments based on size allowing fragments to be sorted and studied

    Restriction enzymes
    Restriction Enzymes

    Useful in genetic engineering where DNA of one organism is inserted into the DNA of another organism (recombinant DNA)

    Example: EcoRI restriction enzyme cuts a GAATTC sequence

    Restriction enzymes are found naturally in bacteria cells. The bacteria developed the enzymes to fight against viruses. They chop up the viral DNA that gets inserted into their cells.

    Gel electrophoresis
    Gel Electrophoresis

    Electrical currents run through the DNA samples that have been cut into fragments. Smaller fragments travel more quickly from the – electrode to the + electrode.

    Separated fragments can be studied or combined with other fragments to create recombinant DNA.

    Gene cloning
    Gene Cloning

    • When a particular new DNA sequence has been developed in recombinant DNA, bacteria cells are used to make multiple copies.

      • The bacteria cells are heated which causes pores to open in their cell walls.

      • The recombinant DNA moves through the pores into the bacteria cell.

      • As the bacteria cell replicates, the recombinant DNA is replicated, too.

    • Purpose: to create many copies of the desirable sequence that can be used in genetically-modified organisms

    Dna sequencing
    DNA Sequencing

    Learning the sequence of DNA fragments can allow scientists to understand the function of certain sequences of bases.

    Restriction enzymes are used to cut large DNA strands into shorter fragments.

    Dyes are used to color known bases, and the known colored known bases bind to the unknown sequence. The unknown sequence can be read by following complementary base-pairing rules.

    Polymerase chain reaction
    Polymerase Chain Reaction

    Purpose: create copies of selected DNA segments when the sample size of DNA is too small to run all of the needed tests

    Uses a thermal cycler to separate the DNA double helix and DNA polymerase enzymes to create copies of the selected segments.

    Extremely useful in forensic science and medicine

    Gene therapy
    Gene Therapy

    • Purpose: Insert beneficial genes into a needy organism

    • How?

      • A mutated gene is located on a chromosome.

      • A “normal” gene is inserted into a chromosome to replace the dysfunctional one using a “viral vector.”

      • The virus infects a cell and injects its genetic material including the “normal” gene. The cell begins replicated the “normal” gene, and the mutation is corrected.
