Presentation Transcript

Slide1 l.jpg

The Effects of Atrazine Application to the Environment.By: Perry Loken, Tim Weisbrod, Nick Taylor, Sara Schmidt

What is atrazine l.jpg

What is Atrazine?

  • Atrazine is a 6-carbon S-chlorotriazine.

  • Atrazine is the most widely used S-triazine.

  • Other S-triazines used as herbicides are Symazine and cyromazine.

  • Atrazine is not very volatile, reactive or flammable but dissolves readily in water.

How atrazine is released into the environment l.jpg

How Atrazine is released into the environment.

  • Atrazine is a selective herbicide used primarily in the agriculture industry

  • Atrazine is primarily applied to corn, sorghum and sugar cane.

  • Atrazine is a Restricted Use Pesticide (RUP).

Amounts of atrazine released into the environment l.jpg

Amounts of Atrazine released into the environment.

  • In 1993 the total amount of atrazine used in the whole country was 35,000 tons.

  • Atrazine usage have been increasing steadily since the 1960’s to the current level of 70,000-90,000 tons per year.

  • Environmental levels of atrazine in countries that use it average 5ug/L

Map of atrazine application by agriculture in the u s l.jpg

Map of Atrazine application by agriculture in the U.S.

How atrazine works l.jpg

How Atrazine Works

  • Atrazine was designed to block photosynthesis.

  • Crop plants are able to detoxify the atrazine.

  • Atrazine works well as both a pre- and post emergent herbicide.

Why atrazine may be a threat to the environment l.jpg

Why Atrazine may be a threat to the environment

  • The complete effects of Atrazine’s ability to block normal functions of plants and animals (expecially humans) is unknown.

  • Atrazine is being found in surface and drinking water reserves in areas of atrazine use

  • It takes considerable time to biodegrade out of the an aqueous system.

  • Because of our extensive reliance on herbicides.

Outline of atrazine s course through the environment l.jpg

Outline of Atrazine’s course through the environment

Atrazine in the soil l.jpg

Atrazine in the soil

  • Degradation effects of Atrazine while it is in the soil.

    • Microbial degradation is the principle mechanism.

    • The kinetics is based on the nitrogen avalibility in the soil.

Application history l.jpg

Application history

  • Two types of fields

    • Adapted

      • Has had atrazine applied on a consistent basis.

    • Non-adapted

      • Has not had atrazine applied to the soil.

Nitrogen rich soils l.jpg

Nitrogen rich soils

  • Nitrogen rich soils contain nitrogen molecules that are easier for the microbial to break down.

    • So Atrazine will be less likely attacked.

    • If nitrogen is deficient, then Atrazine would be a source of nitrogen for the microbial.

Movement through the soil l.jpg

Movement through the soil

  • Clay and silty soil

    • Movement is limited to soil layers of minimal depth.

      Sandy soil movement reaches depths greater than clay and silty soil.

Atrazine in the air l.jpg

Atrazine in the air

  • Highest Concentration is in Summer, Lowest Concentration is in Winter

  • Remains in the air more in enclosed areas

Atrazine run off to surface water l.jpg

Atrazine run-off to surface water

  • In the spring Atrazine levels are highest.

  • Most of the Atrazine in the soil eventually runs off into surface water.

  • Once in surface water it can be transported long distances before it has time to degrade.

Atrazine s effect on animals l.jpg

Atrazine’s effect on animals

  • Once in surface water, atrazine is in direct contact with many species which drink or live in the water.

  • Atrazine does not bioaccumulate up the food chain.

  • The major effects of atrazine on animals are: Endocrine/Reproductive effects and Neurological effects

Endocrine and reproductive effects l.jpg

Endocrine and Reproductive Effects

  • Atrazine disrupts pregnancy by inhibiting normal ovulatory surges.

  • Which include a release in luteinizing hormone (LH), Prolactin (PRL) and testosterone (in males).

  • Also atrazine has been known to cause detoxification problems.

Nerveous system problems l.jpg

Nerveous system problems

  • Atrazine effects the Purkije cells of the nerveous system.

  • Cellular activity is lowered by 50% in 60 minutes.

  • The exact mechanism of this is unknown.

  • Atrazine causes motor disorders in animals.

Human exposure l.jpg

Human Exposure

  • 2-3 million people are exposed

  • 0.2 ppb exposed to in drinking water

  • Minimal amounts from food

Chemical affects l.jpg

Chemical Affects

  • Atrazine has aromatic activities

    • Estrogen levels reduce

      • Underlying reason for hormonal disruption and tumor promoting properties

The future l.jpg

The Future

  • Womb Exposure

    • Suffer permanent brain defects

  • Breast Feeding Exposure

Children l.jpg


  • Sonora, Mexico

  • Compared preschoolers that were exposed to Atrazine to the students that were not.

  • Differences is:

    • Hand-eye coordination

    • Metal and Physical skills

Long term exposure l.jpg

Long Term Exposure

  • Increase Risk of Ovarian Cancer

  • Increase Risk of Breast Cancer

  • Increase Infertility

  • Increase Reproductive Disorder

Modeling with stella l.jpg

Modeling with Stella

  • Model Logic

  • Method to find Atrazine sink

  • Predict environmental degradation

  • Compare soil, Air, Water degradation

  • Interpretation of Stella

Model l.jpg


Atrazine in soil l.jpg

Atrazine In Soil

  • Outflows

    • Biological Degradation, Half-life 42.5 days

    • Erosion, 55% immediately lost

    • Evaporation, Half-life 97 days

  • Inflows

    • Application of 34 million kg

    • Condensation from Air

Atrazine in air l.jpg

Atrazine In Air

  • Inflows

    • Evaporation, Half Life 97 days

    • initial applicationspraying

  • Outflows

    • Oxidation, Half life 0.11 Days

    • Photodegradation, Half life 0.796 days

    • Condensation

    • Take into account 30% of Earth land

Atrazine in water l.jpg

Atrazine In Water

  • Inflows

    • Erosion, 55%

    • Condensation, F(x) of Air

  • Outflows

    • Sedimentation, Half life 14 days

    • Aquatic Degradation, Half life 3.2 days

    • Ingestion

Atrazine movement l.jpg

Atrazine Movement

Water as the sink l.jpg

Water as the Sink

  • Air is not:Degradation less than 1 day

  • Soil, initially a sink, long run NO

  • The Data suggest that water is the sink

    • the sink is draining, does not acumulate

    • Warning: decrease with one application after years steady increase

Degradation routes l.jpg

Degradation Routes

  • Air initial spike degrades quickly

  • Water Spikes later and degrades slower

  • Soil initial spike but degrades out

Future projection l.jpg

Future Projection

  • Projected to 2020

  • It can be seen that it would take until 2012 or 22 years to be nearly rid of Atrazine

  • Indicates steadily rising levels of ATR over time with yearly application

Demonstration l.jpg


  • Atrazine Movement Through the Environment

    • Begins with application, mainly crops

Stella agreement l.jpg

Stella Agreement

  • Stella agrees with the literature in that atrazine does not persist relatively long in the environment

  • Stella is also in agreement in terms of water being the final sink.

Demonstration34 l.jpg


  • It then works its way to the water supply, by runoff and other mechaisms

  • then it follows tributaries and streams

  • Ends up in Large rivers, Lakes and Oceans

Conclusions l.jpg


  • Banning atrazine would decrease the environmental problem but could increase health and environmental risks.

  • Corn and Sorghum crop yields would be reduced.

  • The banning would increase the use of atrazine alternatives, which are less well understood.

  • A better plan might be to find alternative methods of crop management in order to get the best yeilds with the smallest amount of pesticides.
