Developing the Folding 3-Wheeler. March 6, 2007. Background/Justification. Allow user to gain access to public transportation. Facilitate the process of transporting the user and the wheelchair safely. Goal.

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about ' Developing the Folding 3-Wheeler' - paley


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript
background justification
Background/Justification
  • Allow user to gain access to public transportation.
  • Facilitate the process of transporting the user and the wheelchair safely.
slide3
Goal
  • To design a folding three wheeled wheelchair that has the kinematic advantages of a 3-wheeler, but the portability of a folding 4-wheeler.
original functional requirements
Original Functional Requirements
  • Fold compactly when not in use
  • Be comfortable and ergonomic
  • Light enough so the user can carry it
primary functional requirements
Primary Functional Requirements
  • Ability to fold compactly
  • Made from cheap and available materials
  • Easy to manufacture
  • Sturdy
cheap and available materials
Cheap and Available Materials
  • Design constraints
    • Joints must be prismatic or revolute.
    • Use of only 25mm pipe.
    • 26” wheels.
    • Limited tool set.
  • Design Freedoms
    • Use of bike parts
easy to manufacture
Easy to Manufacture
  • Timeline to completion: 3 days
    • Can extend production time to 4 days.
  • Cost vs. Benefit
sturdy
Sturdy
  • Sacrifice portability for rigidity?
countermeasures
Countermeasures
  • Modularity
    • Easily detachable features
    • “snap together”
    • Only uses one “extra” tool
