Closed Loop System Components. Comparison Unit - at least two inputs - one outputNegative vs Positive feedbackControl Unit - binary, proportional, hardwired, programmableCorrection Unit - actuatorProcess - interfaces with the environmentFeedback - measuring system, sensor, condition
