Presentation Transcript


Slide1 l.jpg

Subpart J

Welding & Cutting


Slide2 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.350 Gas welding and cutting

1926.350(a) Transporting, moving, and storing compressed gas cylinders. (1) “Valve protection caps shall be in place and secured.”

1926.350(a)(4) “When cylinders are transported by powered vehicles, they shall be secured in a vertical position.”


Slide4 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.350 Gas welding and cutting

1926.350(a)(6) “Unless cylinders are firmly secured on a special carrier intended for this purpose, regulators shall be removed and valve protection caps put in place before cylinders are moved.”

1926.350(a)(9) “Compressed gas cylinders shall be secured in an upright position at all times except, if necessary, for short periods of time while cylinders are actually being hoisted or carried.”


Slide6 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.350 Gas welding and cutting

1926.350(a)(10) “Oxygen cylinders in storage shall be separated from fuel-gas cylinders or combustible materials (especially oil or grease), a minimum distance of 20 feet or by a noncombustible barrier at least 5 feet high having a fire-resistant rating of at least one-half hour.”


Slide8 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.350 Gas welding and cutting

1926.350(f)(2) “When parallel sections of oxygen and fuel gas hose are taped together, not more than 4 inches out of 12 inches shall be covered by tape.”

1926.350(f)(3) “All hose in use, carrying acetylene, oxygen, natural or manufactured fuel gas, or any gas or substance which may ignite or enter into combustion, or be in any way harmful to employees, shall be inspected at the beginning of each work shift. Defective hose shall be removed from service.”


Slide9 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.350 Gas welding and cutting

1926.351(b)(2) “Only cable free from repair or splices for a minimum distance of 10 feet from the cable end to which the electrode holder is connected shall be used, except that cables with standard insulating connectors or with splices whose insulating quality is equal to that of the cable are permitted.”

1926.351(e) “Whenever practicable, all arc welding and cutting operations shall be shielded by noncombustible or flameproof screens which will protect employees and other persons working in the vicinity from the direct rays of the arc.”


Slide11 l.jpg

OSHA

OCCUPATIONAL SAFETY AND HEALTH

ADMINISTRATION

Subpart J – Welding and Cutting

1926.352 Fire prevention

1926.352(d) “Suitable fire extinguishing equipment shall be immediately available in the work area and shall be maintained in a state of readiness for instant use.”

1926.352(i) Drums containers, or hollow structures which have contained toxic or flammable substances shall before welding, cutting, or heating is undertaken on them either be filled with water or thoroughly cleaned of such substances and ventilated and tested….


Slide12 l.jpg

OSHA Violations

Subpart J
