Arduino week2

Arduino week2

語法:Variables & Functions

實作:Digital out (Button+LED)

簡報:廖崇義


Pinmode

pinMode()

  • pinMode(pin, mode)

    • pin 欲指定的腳位

      數位腳位 D0~D13

    • mode (INPUT, OUTPUT, or INPUT_PULLUP)

      INPUT 將腳位設定為輸入使用

      OUTPUT 將腳位設定為輸出使用

      INPUT_PULLUP將腳位設定為輸入使用,並且使用內部提升電阻(see next page)

      EX1. pinMode ( 13 , OUTPUT )

      EX2. intledpin = 13 ;

      pinMode( ledpin, OUTPUT )


Input pullup

INPUT_PULLUP

  • PULLUP內部提升電阻

    (深紅色部份)

    EX.pinMode(10, INPUT_PULLUP)

    當SWOFF時D10為HIGH

    當SWON時D10為LOW

    實作1.


Digitalread

digitalRead()

  • digitalRead(pin)

    • pin D0~D13

    • 回傳值HIGH或LOW

    • 必需配合變數讀取回傳值,變數可為boolean或int形態

    • booleantrue or false(1、0或HIGH 、LOW)

    • INT -32,768 to 32,767 ,使用digitalRead()回傳值為HIGH時為1 , LOW時為0


Digitalwrite

digitalWrite()

  • digitalWrite(pin, value)

    • pin D0~D13

    • value為HIGH或LOW

    • I/O最大限制40mA

      實作2.


Digitalwrite1

digitalWrite()

  • 實作3.

    • 輸出腳改到pin10,並使用300Ω限流電阻


D elay ms delaymicroseconds us

delay(ms) delayMicroseconds(us)

  • delay(ms)

    • ms :設定程式欲暫停執行的時間,單位為millisecond

      (0.001秒)

  • delayMicroseconds(us)

    • us: 設定程式欲暫停執行的時間,單位為microsecond

      (0.001ms)

      Ex.


Arduino week2

變數型態


Millis

millis()

  • 回傳Arduino晶片的時間計數值

  • 按Reset或程式重載時歸零

  • 回傳值為unsigned long型別

  • 約50天後溢位歸零重數

  • Ex. unsigned long timex ;

    timex =millis() ;


Arduino week2

If判斷式

  • if (conditional)//判斷式

    {

    // do something here

    }

    判斷成立執行大括號內程式碼

  • 判段式運算符 ==, !=, <, >

    • ==ex.if( val== HIGH )

    • != ex.if( val!=HIGH )

    • < ex.if( val< 5 )

    • > ex.if( val>5 )


Arduino week2

按鍵計數實作4-1


Part1 4 2

按鍵計數去抖動part1實作4-2

intledPin = 13; //LED

intbuttonPin = 10; //buttonPin

intval = 0; //按鍵計數值

booleanled_status =1;//LED狀態變數

booleanbtn_status;//按鍵狀態

void setup()

{

pinMode(ledPin,OUTPUT);

pinMode(buttonPin,INPUT_PULLUP);

}

void loop()

{

btn_status=digitalRead(buttonPin);//讀取按鍵狀態

if(btn_status == LOW)//當按鍵被按下時

{

delay(500);//暫停0.5秒避開抖動雜訊

val=val+1;//計數加1

if(val == 3)//當按下button3次時LED燈動作

{

digitalWrite(ledPin,led_status);//LED輸出變換

val=0;//計數歸零

led_status = !led_status;//下次LED輸出狀態反相

}

}

}


Part2 5

按鍵計數去抖動part2實作5

  • 取樣分析(加分題)

10~100次

∞次

10~100次

5V

0V

雜訊區

>100ms

密集區

雜訊區

>100ms


7 0 9 6

7段顯示器(顯示0~9程式碼)實作6


0 9 6

顯示0~9程式碼實作6

10

6

8

7

9

1

4

2

3

10912467


0 9 61

顯示0~9程式碼實作6

void loop()

{

digitalWrite( 2 , seven_disp[i][0] ) ;

digitalWrite( 3 , seven_disp[i][1] ) ;

digitalWrite( 4 , seven_disp[i][2] ) ;

digitalWrite( 5 , seven_disp[i][3] ) ;

digitalWrite( 6 , seven_disp[i][4] ) ;

digitalWrite( 7 , seven_disp[i][5] ) ;

digitalWrite( 8 , seven_disp[i][6] ) ;

delay(500);

i=i+1;

if(i==10)

i=0;

}

byte seven_disp[10][7] = { { 1,1,1,1,1,1,0 }, // = 0

{ 0,1,1,0,0,0,0 }, // = 1

{ 1,1,0,1,1,0,1 }, // = 2

{ 1,1,1,1,0,0,1 }, // = 3

{ 0,1,1,0,0,1,1 }, // = 4

{ 1,0,1,1,0,1,1 }, // = 5

{ 1,0,1,1,1,1,1 }, // = 6

{ 1,1,1,0,0,0,0 }, // = 7

{ 1,1,1,1,1,1,1 }, // = 8

{ 1,1,1,0,0,1,1 } // = 9

};

inti=0;

void setup()

{

pinMode( 2, OUTPUT );

pinMode( 3, OUTPUT );

pinMode( 4, OUTPUT );

pinMode( 5, OUTPUT );

pinMode( 6, OUTPUT );

pinMode( 7, OUTPUT );

pinMode( 8, OUTPUT );

}


0 9 7

按鍵加一顯示0~9實作7

  • 加分題

  • 承上題七段顯示器,按一次按鍵數字加1
