  1. CHAPTER Protocols and IEEE Standards

  2. Chapter Objectives • Discuss different protocols pertaining to communications and networking

  3. Module Important Communication and Networking Protocols

  4. Layer 7 Application Layer 6 Presentation Layer 5 Session Layer 4 Transport Layer 3 Network Layer 2 Data Link Layer 1 Physical ISO-OSI Seven Layer Model Recalled Source: http://starter.sdsu.edu/remote/demo/osi-tcp.html

  5. Application Application Presentation Session Transport Host-to-Host Network Internet Data Link Network Access Physical Comparison of ISO-OSI Model and the DOD (TCP/IP) Model Source: http://starter.sdsu.edu/remote/demo/osi-tcp.html

  6. Application Application FTP, Telnet, SMTP, HTTP.. Presentation Session Transport Host-to-Host TCP, UDP Network Internet IP, ICMP Data Link Network Access Ethernet, Token-Ring ... Physical Layer Reference to Protocol Recalled Source: http://starter.sdsu.edu/remote/demo/osi-tcp.html

  7. POP3/SMTP • Protocol used in electronic mail transfer • Between the mail server and the mail client • POP3 • Incoming mail • IMAP • Incoming mail • More advanced and has more features than POP3 • The later version is IMAP4 • SMTP • Outgoing mail

  8. FTP • File Transfer Protocol • File transfer between a client and an FTP server • Uses ports 20 and 21

  9. Telnet • Supports terminal emulation or host sessions • For example, Telnet can be used for accessing a Unix machine and emulating a terminal attached to the Unix computer

  10. DNS • Directory service protocol • Domain Names Service (DNS) • Used for resolving domain names to IP addresses and vise versa

  11. DHCP • Dynamic Host Configuration Protocol • Issues IP addresses to client • Leases IP address • For security, a DHCP server can issue an address based on MAC address

  12. NFS • Protocol for Network File Service • For example, enable a Unix machine to function as a file server and serve files to Windows clients

  13. ARP • Address Resolution Protocol • Enables the IP and MAC addresses of clients to be identified for transmission of data

  14. SNMP • Used by network management utilities to manage network devices • For example, a manageable hub that support SNMP can be managed from a remote location using a SNMP based LAN management software

  15. IGMP • Internet Group Management Protocol • Used in multicasting

  16. ICMP • Internet Management Control Protocol • Used in network error reporting • Used by network administrators to poll devices for troubleshooting

  17. RIP • Routing Information Protocol • Used by routing devices to exchange information such as routing table contents etc. • Determines the shortest path (heuristically) from one node to another and shares the information with routing devices

  18. OSPF • Open Shortest Path First • A more efficient protocol than RIP in determining the fastest path to the destination

  19. RSVP • Resource Reservation Protocol

  20. QoS • Quality of Service

  21. NWLink • A protocol used on Windows clients to access Novel Netware servers • The exchange of information between the Windows client and the Netware server is facilitated by this protocol

  22. NWLink and IPX/SPX • IPX/SPX is Novell’s protocol • It is a routable protocol • If IPX/SPX is to be installed in a Microsoft client then the ODI driver must be installed • The alternative of installing NWLink is preferred • Works with NDIS driver

  23. Sample use of NWL ink • Access NetWare servers • Give Netware clients access to Windows servers • Set a Windows 2003 server as a gateway to NetWare servers

  24. NetBIOS and NetBEUI • NetBEUI • Originally implemented by IBM for networking • NetBIOS • Non-routable protocol

  25. DLC • Protocol used for connecting the LAN to an older IBM system • SNA based IBM network

  26. AppleTalk • Used in networks connecting Apple computers

  27. Protocol Binding • NDIS • Binding driver used with Microsoft • ODI • Binding driver used with Novell

  28. Web Research • Visit a vendor’s web site to obtain information on the configuration of a wireless LAN consisting of 2 workstations and a server

  29. End of Module

  30. END OF CHAPTER
