Presentation Transcript


Variable rate nitrogen application on row crop spinach l.jpg

Variable Rate Nitrogen Application on Row Crop Spinach

2005 ASAE Annual International Meeting

C. L. JonesResearch Engineer

N. O. Maness Professor - Hort./Landscape Architecture

M. L. Stone Regents’ Professor, ASAE Fellow

J. B. SolieSarkey’s Professor, ASAE Fellow

D. Zavodny Research Engineer

Paper Number: 051119


Nitrogen mismanagement causes l.jpg

Nitrogen Mismanagement causes:

  • Nitrogen Use Efficiency (NUE): 40-70 %

  • Leaching and groundwater contamination

  • Ozone depletion from gaseous losses as N2

  • Loss of profit

  • Health hazard due to nitrate build-up in foliage

Paper Number: 051119


Current best practices l.jpg

Current “Best” Practices

  • 50 to 110 kg N/ha applied at planting

  • Side dress application after emergence:

  • Rate depends..

  • soil type

  • seasonal variation

  • cultural practice

  • Soil testing: limited by economics, resolution, time

Paper Number: 051119


Objectives l.jpg

Objectives

  • Answer the following:

    • When should we apply post-emergence N fertilizer in spinach?

    • How should we determine in-season N application rates?

    • Does variable rate application of N in row crop spinach work?

Paper Number: 051119


Past spinach research l.jpg

Past Spinach Research

  • Readily responsive to nitrogen

  • NDVI (normalized difference vegetation index) is a good predictor of chlorophyll content

  • Chlorophyll content and NDVI may be used to estimate photosynthetic capacity and productivity

  • NDVI may be used to estimate nitrogen needs in spinach

Paper Number: 051119


Equipment l.jpg

Equipment

  • GreenSeeker™ active multispectral sensors (NTech Industries, Ukiah, Calif.)

    • Handheld

    • Applicator mounted

  • LED’s emit red and NIR light

  • Photodiode receives reflectedlight, produces a voltage

  • Data used to calculate NDVI:

Paper Number: 051119


Determining in season response l.jpg

0

0

100

125

75

150

0

0

100

Determining In-Season Response

  • Non-N-limiting strips

Stamp Calibration Plots

Paper Number: 051119


Experiment design l.jpg

Experiment Design

  • Oklahoma Vegetable Research Station, Bixby, Oklahoma

  • Spring, 2003… Spring, 2004… Fall, 2004

  • “San Juan” and “Fidalgo” varieties

  • Overhead sprinkler irrigation

  • Severn very fine sandy loam, prior year fallow, preplant herbicide application

Paper Number: 051119


Spring 2003 l.jpg

Spring 2003

Paper Number: 051119


Spring 2003 app rates results l.jpg

Spring 2003 App. Rates/Results

Paper Number: 051119


Spring fall 2004 l.jpg

Spring, Fall 2004

Paper Number: 051119


2004 app rates results l.jpg

2004 App. Rates/Results

Sprayed plots: averaged 10 kg/ha biomass better than hand application

Paper Number: 051119


Comparison vrt vs non vrt l.jpg

Comparison: VRT vs. Non-VRT

2003:

for plots yielding approx. 16,000 kg/ha

non-VRT plot: 132 kg N/ha

VRT plot: 81 kg N/ha

Fall 2004:

VRT plots treated with approx. 75 kg N/ha total: 21,000 kg/ha

non-VRT plot treated with 75 kg N/ha: 13,000 kg/ha

Paper Number: 051119


Conclusions l.jpg

Conclusions

  • When should we apply post-emergence N fertilizer in spinach?

    • Once approximately 45 days post seeding (50% ground cover stage)

Paper Number: 051119


Conclusions15 l.jpg

Conclusions

  • How should we determine in-season N application rates?

    • Compare NDVI of plot to best NDVI in stamp or calibration plots

Paper Number: 051119


Conclusions16 l.jpg

Conclusions

  • Does variable rate application of N in row crop spinach work?

    • Yes! Examples:

      • Spring ‘04: 43% improvement

      • Fall ‘04: 53% improvement over non-VRT plots

        -VRT plots were visibly more uniform in color, texture, and size

Paper Number: 051119


Questions l.jpg

QUESTIONS?

Acknowledgments

Support through funding from the USDA Special Research Grant Number 2003-06134

Paper Number: 051119
