  1. PSS Merlin

  2. SELF CONTAINED BREATHING APPARATUS BODYGUARD II • Combines these safety features in one device: • Digital Pressure reading • ‘Time To Whistle’ based on actual consumption rate • Integrated ADSU / PASS • Manual Distress Signal Alarm • Temperature Display • Electronic acoustic and optical low pressure warnings • 2nd Independent pneumatic low pressure warning • Flexible parameter setting with Windows software • Data logging • Telemetry ready IR Communications port

  3. SELF CONTAINED BREATHING APPARATUS BODYGUARD II FEATURES LCD Display RH button to display temperature LH button to illuminate Manual Distress Button Warning LEDs Pneumatic Whistle

  4. SELF CONTAINED BREATHING APPARATUS BODYGUARD II DISPLAY Digital Cylinder Pressure Clock Icon indicates time Time To Whistle (TTW)

  5. SELF CONTAINED BREATHING APPARATUS BODYGUARD IR LINK II SOFTWARE – DATA LOG/PARAMETER MAINTENANCE

  6. SELF CONTAINED BREATHING APPARATUS BODYGUARD IR LINK II SOFTWARE – ENHANCED DATALOG GRAPHIC Select events to be displayed on graph Graphs can also be produced for analysis with many new options

  7. SELF CONTAINED BREATHING APPARATUS PSS MERLIN - TELEMETRY

  8. SELF CONTAINED BREATHING APPARATUS PSS MERLIN - TELEMETRY Telemetry - What does it provide now? 1. Continuous transmission of Pressure, Time Remaining , Temperature , battery status, etc 2. Two way evacuation/withdrawal signalling with acknowledgements 3. ADSU alarms and manual distress signals Which means vital safety data displayed at the Control Board !

  9. SELF CONTAINED BREATHING APPARATUS PSS MERLIN – ECB DISPLAY Each logged on Fire Fighter permanently displayed on ECB - No Scrolling! Display window - customer preference e.g. TTW Evacuation button ‘On Line’ signal indicator Time to Whistle Display at Bodyguard

  10. SELF CONTAINED BREATHING APPARATUS PSS MERLIN – “I“ BUTTON OPTIONS Time of Whistle Display reverts to default selection after x secs ‘information’ button Pressure Time to Whistle Temperature Time Elapsed

  11. SELF CONTAINED BREATHING APPARATUS PSS MERLIN – TELEMETRY DATA LOGGING Datalog Windows Software and data link cable

  12. SELF CONTAINED BREATHING APPARATUS PSS MERLIN – BA ENTRY CONTROL Safety of Firefighters ! • Disciplined donning and pre-entry checks • Accountability of Firefighters via Entry Control Board • Pressure, time in, personal details on tally • Maintenance of Team and location data • Calculate initial Time To Whistle • Relieve teams prior to whistle • Control of Emergency rescue teams Entry Control Officer with control board

  13. SELF CONTAINED BREATHING APPARATUS PSS MERLIN – BA ENTRY CONTROL Merlin Delivers • Monitoring of TTW and Display Time of Whistle • Calculates Breathing Rate • Displays pressure on demand • Monitors Distress Signals • Evacuation Signals/ Monitor Withdrawal Signals • Electronic Data logging Current information shortfall! • 1. Time to whistle based on initial pressure • 2. Assumes fixed breathing rate of 40 Ltr /min • 3. No continual monitoring of pressure by ECO • 4. No awareness of distress signals • 5. No evacuation / withdrawal signal protocol • 6. No automatic comprehensive evidential record

  14. SELF CONTAINED BREATHING APPARATUS PSS MERLIN - TELEMETRY Telemetry - What will it provide in the future? 1. Physiological Monitoring of core body temperature, pulse, etc 2. Environmental monitoring of ambient 3. Alarms based on environmental and physiological measurements 4. Location? 5. Speech?

  15. PSS MERLIN WORKSHOP COMMISSIONING EXPLAINED “I“ BUTTON DISPLAY OPTIONS • 1.Time of whistle (Bodyguard) • 2.Time to whistle (Bodyguard) • 3.Pressure • 4.Temperature • 5.Elapsed time since log on • Radio low battery status • Time of whistle static (TB1/97 initial pressure + fixed breathing rate) • Time of whistle dynamic (Bodyguard pressure + fixed breathing rate) • Display flashing ‘x’ mins to whistle (factory default 10 mins) Factory Settings

  16. PSS MERLIN ENTRY CONTROL ACCESSORIES ECB Bracket 3351803 Entry Control Board 3351145/3351616 Tripod 3351802

  17. PSS MERLIN ENTRY CONTROL ACCESSORIES Digital Clock 3351903 Manual Operation : ECB Cover PVC 3351812 + =TB 1/1997  Duration Tables 3351845/46/47 Chinagraph pencil 3351237

  18. PSS MERLIN BATTERY CHARGING FLEXIBILITY Power Cords 3351805/6/7 4 Way Portable Unit Charger 3351815 Power Supply 3351804 Vehicle Clip Charger 3351681 ECB Workshop Charger Kit 3351819 ECB Vehicle Charger 3351810

  19. THANK YOU FOR YOUR ATTENTION!
