    1. Presented to the SCEA 2002 National Conference Scottsdale, Arizona, 14 June 2002 Jim Price C/S Solutions, Inc. An Implementation of the Lurie-Goldberg Algorithm in Schedule Risk Analysis

    2. Introduction Risk+™ 2.0 is a schedule risk analysis add-in to Microsoft® Project The product implements the Lurie-Goldberg1 algorithms for generating correlated variables and for adjusting inconsistent correlation matrices Details follow

    4. Schedule Risk Analysis Instead of a single-point estimate for duration, the user supplies: A three-point estimate minimum, most likely, and maximum A distribution curve uniform, triangular, normal, beta, other Instead of a single completion date, output is a range of completion dates, with associated probabilities of occurrence

    5. A Schedule Without Risk

    6. A Schedule With Risk

    7. In the presence of risk, each of Design-Code-Test can take on 7200 possible values (in minutes) Leads to 3.7 x 1011 possible outcomes Not all are distinct, nor equally likely We would like to know how they are distributed Too many to enumerate, so the distribution of finish dates is determined by sampling Literally, take samples until a clear picture of the underlying distribution emerges Consider the Possibilities

    8. Monte Carlo Simulation Select and apply a random (remaining) duration from the specified distribution of each lowest-level task Recalculate the network Accumulate summary-level statistics Repeat until the underlying distribution is revealed

    9. Random Number Generation Sampling requires that we generate random numbers from specified distributions General technique is known as the “inversion method” Requires only the cumulative distribution function (CDF) of the desired distribution

    10. The Inversion Method Pick a random number between 0 and 1 Feed that value to inverse CDF to get random sample from specified distribution Events “bunch” where the slope of the CDF is large

    11. Demo In which the inversion method is shown Excel (SCEA1.xls) Risk+ (CORR0.mpp)

    12. Are We Done? Yes, if individual tasks are independent We know how to generate independent random durations for lowest-level tasks No, if individual tasks are correlated Durations at lowest level can no longer be generated in isolation

    13. Instead of N single-variable probability distributions, we are modeling a single N-variable probability distribution Our three-point estimates and distribution curves define the marginal distributions of the underlying multivariate distribution At least, we hope they do To capture the interrelationships, we also need to specify the correlations among tasks The Problem – In Principle

    14. Both plots below show Code vs. Test durations, for the distributions specified Simple application of inversion method produces the plot on the left – values are uncorrelated We want the plot on the right – values are correlated The Problem – In Practice

    15. What Is Correlation? Literally: co-relation Two or more variables share a relationship Mathematically: measures dependence P(A, B) = P(A) · P(B) + something If independent, “something” is zero: the joint distribution is just the product of the marginal distributions

    16. How Is Correlation Measured? Let me count the ways… Product-moment (Pearson) Rank (Spearman, Kendall, …) Others Product-moment correlation is the appropriate measure for cost-schedule risk analysis Durations and costs are interval, not ordinal measures It arises naturally in the consideration of the variance of sums of random variables, e.g. summary task durations and costs Whether product-moment correlation can be well modeled by other measures is a matter of debate

    17. Covariance of X and Y = Cov(X, Y) = E[(X - ?x) · (Y- ?y)] = E[XY] - ?x ?y = Cov(Y, X) Intimately related to Variance Var(X) = E[(X - ?x)2] = Cov(X, X) Scale by standard deviation ? to give the correlation coefficient, ? ?xy = Cov(X, Y) / ?x?y Product-Moment Correlation

    18. Correlation Matrices Suppose M is a k x m vector whose columns Mi are random variables If we form Vi = (Mi - ?i) / ?i, it follows from the definitions above that C = (1/k) VTV is a matrix of correlation coefficients If Mi are uncorrelated, then C = I, the identity matrix

    19. The Cholesky Decomposition For any correlation matrix C, a lower triangular matrix L can be found such that C = LLT L is called the Cholesky decomposition of the matrix C

    20. Correlations cannot be specified arbitrarily If two tasks are each correlated with a third, they are necessarily correlated with each other Mathematically, a consistent correlation matrix is “positive semi-definite” Eigenvalues are non-negative Determinants of principal minors are non-negative Inconsistent matrices are easy to produce Lurie and Goldberg describe an adjustment procedure for inconsistent matrices Inconsistent Correlation Matrices

    21. Matrix Adjustment Procedure Generate a correlation matrix R = LLT for an initial lower triangular matrix L Calculate the weighted difference between the terms of R and the original matrix C D = ˝ ?? wij(cij – rij)2 Minimize D by iterating over the terms in L, constrain to ensure unit diagonals in R The weights W are supplied by the user Less certain terms should be much smaller than the default value of 1.0

    22. Demo In which the Lurie-Goldberg matrix adjustment procedure is shown Excel (SCEA6.xls) Risk+ (SCEA.mpp)

    23. Fun With Numbers If N is any k x m matrix with standardized, uncorrelated columns, then V = NLT is also in standard form, and NTN = kI If C is a correlation matrix and C = LLT, it follows that VTV = (NLT)TNLT = LNTNLT = LkILT = kLLT = kC Therefore, the columns of V = NLT are correlated according to the matrix C

    24. Is V the Object of Our Desire? V = NLT has the desired correlations, by construction V is in standard form, so mean and standard deviation are easily adjusted But, unless the columns of N are standard normals, the distributions Vi will not match Ni Vi = li1N1 + li2N2 +…+ liiNi A linear combination of normals is itself normal, but this is not generally true

    25. Demo In which the desired correlations, but not necessarily the desired marginal distributions, are obtained Excel (SCEA2.xls)

    26. More Fun with Numbers Well, we can generate correlated normals Recall inversion method – we might be able to do something with correlated uniforms Easy to generate: just apply the standard normal CDF to our correlated standard normals, U = ?(NLT) Then apply desired inverse CDF to U V = F-1(U) = F-1(?(NLT))

    27. The Version-Inversion Method

    28. Is V the Object of Our Desire? V = F-1(?(NLT)) has the desired distributions, by construction Any uniform distribution will work as well as any other as input to the inversion method But, the transformations are non-linear, so correlations are not necessarily preserved Once again, the method is exact only for normal distributions

    29. Demo In which marginal distributions are preserved, but correlations are not Excel (SCEA3.xls) Risk+ (CORR1.mpp)

    30. Sampling Variability In any Monte Carlo simulation, variations are expected from run to run A different subset of the underlying distribution is sampled each time Sampling variability can be greatly reduced by starting with a “clean” set of normals Method due to R.C.H. Cheng2 produces completely uncorrelated normals with exactly zero mean and unit variance

    31. Sample Results – Un-iterated Method with Full Sampling Variability (0)

    32. Sample Results – Un-iterated Method with Reduced Sampling Variability (3)

    33. The Lurie-Goldberg Algorithm Developed by Dr. Phillip Lurie and Dr. Matt Goldberg Iteratively modifies the Cholesky decomposition matrix to achieve the best possible agreement with target correlations “Basic” and “Modified” implementations

    34. Begin as before (version-inversion) V = F-1(?(NLT)) Calculate the realized correlations R among the columns of V Calculate a scalar distance D between the realized and target correlations C D = ˝ ?? (cij – rij)2 (sum taken over super-diagonal terms only) Minimize D by iterating over the terms in L, constrain to ensure unit diagonals in R Steps of the Basic Method

    35. Demo In which the Lurie-Goldberg Basic algorithm is shown Excel (SCEA4.xls) Risk+ (CORR1.mpp)

    36. Sample Results – Iterated Method without Sampling Variability (1)

    37. Modified Sampling Algorithm As noted, a Monte Carlo simulation will experience run-to-run variations The basic Lurie-Goldberg algorithm iterates out this “natural” variability Variation appears in solution time, not result To re-introduce sampling variability, L&G suggest a modified algorithm For schedule risk analysis, primary advantage is probably greater speed, not greater variability

    38. Steps of the Modified Method Run the basic algorithm with a limited number of samples (e.g. 100) N is constructed to have exactly zero mean and unit variance (again, Cheng’s method) Use modified decomposition matrix L to generate the full set of samples Once again, V = F-1(?(NLT)), but with the iterated matrix for L and a full set (e.g. 1000) of uncorrelated normals for N

    39. Sample Results – Iterated Method with Full Sampling Variability (2)

    40. Sample problem from presentation by Book and Young to 24th DODCAS, Sept 1990 4 skewed triangular distributions Apparently arbitrary correlations, 0.9-0.5 “Cross check by analytic fit to beta distribution” Comparison of Results by Method (Costs)

    42. Implementation Details Custom non-linear constrained optimization routine Conjugate-gradient method with quadratic penalty terms, some domain-specific enhancements Similar to Gauss-Newton method analyzed by Lurie and Goldberg Both are successive line-minimization methods with quadratic convergence Conjugate-gradient method requires less storage

    43. Performance Factors Number of correlations Minimization routine searches O(m2) dimensions Number of samples Distance function requires O(nm2) multiplications and O(nm) marginal distribution calculations per evaluation Unrealizable problem specification Results in extended fruitless searching More likely to be a problem when marginal distributions are far from normal

    44. Solution Time is a Random Variable

    45. Why All the Fuss? In schedule analysis, the durations of summary tasks are sums of random variables Variance of sums of random variables is affected by correlation Var(X+Y) = Var(X) + Var(Y) + 2 · Cov(X, Y) If Cov(X, Y) > 0, neglecting correlation leads to an underestimate of the standard deviation of summary tasks

    46. Demo In which the effect of correlation on summary-level standard deviation is shown Risk+ (CORRDEMO.mpp)

    47. Summary How correlation enters a Monte-Carlo simulation Lurie-Goldberg adjustment procedure for inconsistent correlation matrices Non-iterated and iterated (Lurie-Goldberg) methods for generating correlated random variables Implementation and performance factors Why correlation matters in schedule risk analysis

    48. Addendum -- What about Rank Correlation? Commercial software with rank-correlation capability is often used to model product-moment correlation Point: Rank correlation is not product-moment correlation, and using it can lead to misleading (if not meaningless) results. Counter-point: So you say, but it seems to work pretty well. Go figure.

    49. How Are These Rank Correlated Numbers Generated? Almost certainly, by an algorithm due to R.L. Iman and W.J. Conover3 But ask your vendor, to be sure Observation: The Iman-Conover algorithm uses product-moment correlation to approximate rank correlation Yes, really

    50. The Iman-Conover Algorithm Generate a set of uncorrelated normal samples Multiply by the Cholesky decomposition of the target correlation matrix to produce correlated normal samples Determine the rank order of the correlated normal samples Generate uncorrelated samples from any desired set of target distributions Rearrange the target samples so they have the same rank-ordering as the correlated normal samples

    51. Iman-Conover -- Commentary The observed rank correlations will always be approximate Rank correlation is not product-moment correlation If the target distributions are normal, the product-moment correlations will be exact (within sampling error) If the target distributions are non-normal, the resulting product-moment correlations will be inexact, in the now-familiar way Reordering the target distributions is a non-linear transformation comparable to “version-inversion”

    52. Sample Results – Rank Correlations from Iman-Conover

    53. Sample Results – Product-Moment Correlations from Iman-Conover

    54. The Lurie-Goldberg-Iman-Conover Method (LGIC) Iman-Conover is ultimately based on the Cholesky decomposition Consequently, the Lurie-Goldberg algorithm is easily extended to incorporate Iman-Conover Simply substitute IC rank ordering technique for the “version-inversion” method Calculate observed product-moment correlations and iterate as before Of course, we could iterate to improve rank correlation just as easily, if desired

    55. Sample Results – Product-Moment Correlations from LGIC

    56. Sample Results – Rank Correlations from LGIC

    57. Demo In which the Lurie-Goldberg-Iman-Conover algorithm is exercised Risk+ (CORR1.mpp)

    58. Comparison – LG vs LGIC For equal number of samples, Lurie-Goldberg (LG) is significantly faster than Lurie-Goldberg-Iman-Conover (LGIC) For common distributions, it is faster to generate samples than to sort them But, LGIC supports Latin Hypercube sampling, which can reduce the number of samples required Not to mention producing prettier distributions LGIC has an inherent limit in resolution, especially for very small sample sizes Small refinements to Cholesky decomposition may not result in a new ordering Effect is unnoticeable unless target correlations are already at the edge of feasibility

    59. Summary (of Addendum) The Iman-Conover algorithm for generating rank-correlated samples uses product-moment correlation “under the hood” Hence its rather unexpected success in modeling product-moment correlations As with all (Cholesky-based) algorithms, it will be particularly good for normal and near-normal distributions The Lurie-Goldberg algorithm is easily extended to incorporate the Iman-Conover algorithm Combined approach is slower than the original for common distributions, but capable of comparable accuracy Combined approach supports Latin Hypercube sampling

    60. Questions? The Excel files used in this demonstration are available on request. Please email jprice@cs-solutions.com
