Presentation Transcript

Types
Types

  • Back-pass solar collectors

    • Used to heat air

    • Glazed surface

    • May be integrated with thermal mass

  • Concentrating solar collectors

    • Best suited for clear skies

    • Steam production

    • Concentrates light at absorber which can increase efficiency at high temperature

    • Four forms: parabolic trough, parabolic dish, power tower, stationary solar collectors

  • Trombe Wall

    • Thermal mass designed to radiate heat during the night

    • Glass to allow sunlight through

    • With added salt fillers stored energy changes from 200 cal/day to 80,000 cal/day

  • Batch Solar Collectors

    • Water heating

    • Glazed water collectors

  • Solar cookers

  • Liquid Solar Collectors

    • Vacuum tubing


Manufacturers and products
Manufacturers and Products

SES Dish Stirling System Technology

  • Designers of large, industrial solar dish systems

  • Product made of huge concentrator (dish reflectors) and power conversion unit (hydrogen heating that runs pistons)

    Industrial Solar Technology

  • Roof mount parabolic troughs

  • Specifications – IST Roof Mounted Trough (RMT) System

  • Reflective Module Size 120.75 in. x 45.2 in. (3067 mm x 1148 mm)

  • Gross Aperture Area 37.9 ft2 (3.52 m2)

  • Net Aperture Area 35 ft2 (3.25 m2)

  • Concentrator Weight 55 lb (25 kg)

  • Materials of Construction Aluminum

  • Reflective Surface Coated polished aluminum

  • With 1120 ft^2 area, produces 52 kWth


Manufacturers and products1
Manufacturers and Products

  • Solarco Manufacturing Ltd.

  • 24 Tube Kit

  • $2,100

  • Works down to -40 Celcius

  • 93% light allowed in

  • 3.6 ft x 4.9 ft


Reflecting surfaces
Reflecting Surfaces

  • Cool roofs

    • White surfaces preferred

    • Metal surfaces offer high albedos but low thermal emittance

    • Reduce heating costs in hot environments


Reflecting options
Reflecting Options

  • Coatings ($.75 – $1.50 per square foot)

    • Elastomeric

    • Polyurethane

    • Acrylic

  • Single-ply Membranes ($1.50 – $3.00)

    • Semi-flexible

    • EPDM, PVC, TPO

  • Reflective tiles ($3.00)

    • Pigments allow for 70% reflection of sun’s energy

  • Metal roofs ($2.00 and up)

    • With additional pigments will reflect infrared as well


Areas of further exploration
Areas of further exploration

  • Alternating cool roof/warming roof material?

  • Designing our own trough system for heat

  • Pigments for roofing

  • Integration of a trough system

  • Current research into reflecting light (moisture barriers)
