Direct memory access

Direct Memory Access

Presentation by

Leena Jacob


To be tackled
To be tackled

  • The basic computer

  • Improvements made to the basic computer

    • Interrupt handler

    • DMA

  • DMA Controller in BF533

  • Example code that demonstrates setting up the DMA


The basic computer

Steps involved in storing data to the memory by the I/O device:

CPU signals I/O device

I/O places data on the bus and signals to CPU

CPU reads the data into a register and signals to I/O

CPU signals memory

Memory writes data to some location

Memory signals CPU that it is done.

The basic computer


Deficiencies of cpu i o
Deficiencies of CPU I/O device:

  • No other useful CPU operations can be accomplished while waiting for I/O

  • Early I/O devices were very slow, thus compounding the problem


Interrupt improvements
Interrupt Improvements device:

  • The better option is for the I/O device to interrupt the processor with an interrupt signal whenever it is ready with a data.

  • CPU can then service the interrupt and get back to whatever it was doing before.

  • This requires an interrupt handler.


Direct memory channel improvement
Direct Memory Channel Improvement device:

  • Interrupt processing requires explicit op-code cycles to perform I/O transfers

  • Next improvement is a separate peripheral module to perform direct memory access (DMA).

  • It is also the bus arbitrator.

  • There can only be one user of the data bus so processor must wait if DMA is transferring data.

  • DMA controller tells the processor when the DMA has completed the transfer.


Dma block diagram
DMA Block Diagram device:

Interrupt line

cycle state signals

CPU

DMA Module

External

I/O lines

address setup

Address bus

Data bus

RAM


Sharing of the op code cycles
Sharing of the op-code cycles device:

  • Op-code cycles have two distinct parts:

    • One part involves RAM access

      • Read the OP code from program memory (fetch)

      • Read/write data from/to data RAM addresses (decode and writeback)

    • Second part involves only CPU operations

      (execute)

      • Perform data manipulation using CPU registers as source(s) and destination(s) of data

  • DMA device performs RAM access during this second portion of the op-code cycle


Dma controller in bf533
DMA Controller in BF533 device:

• Between memory and memory (MDMA) (“Memory DMA”)

• Between memory and the I/O through a serial or parallel port (SPI, PPI,UART).

  • There are 12 DMA channels for various transfers.

  • Two ways of programming DMA transfers

    • Descriptor-based

    • Register-based


Descriptor based dma
Descriptor-based DMA device:

  • Descriptor-based DMA transfers require a set of parameters stored within memory to initiate a DMA sequence.

  • This sort of transfer allows the chaining together of multiple DMA sequences.

  • In descriptor-based DMA operations, a DMA channel can be programmed to automatically set up and start another DMA transfer after the current sequence completes.


Register based dma
Register-based DMA device:

  • Register-based DMA allows the processor to directly program DMA control registers to initiate a DMA transfer.

  • On completion, the control registers may be automatically updated with their original setup values for continuous transfer, if needed.


Dma registers
DMA Registers device:

DMA registers fall into three categories:

  • Parameter registers, such as

    DMAx_CONFIG and DMAx_X_COUNT

  • Current registers, such as DMAx_CURR_ADDR and DMAx_CURR_X_COUNT

    • Control/Status registers, such as DMAx_IRQ_STATUS and

    DMAx_PERIPHERAL_MAP


Video interface
Video Interface device:

DMA

VideoInPort

Decoder

Video source

PPI Interface

Memory

Display Unit

PPI Interface

VideoOutPort

Encoder

BF533


Example code for video input
Example code for video Input device:

//Configure the Interrupt service routine

CALL BF533_EZ_KIT_ISR_Config;

//Configure the SDRAM

CALL BF533_EZ_KIT_SDRAM_Config;

//Configure the DMA in Stop Mode

CALL BF533_EZ_KIT_DMA_Config;

//Configure the PPI 8bit, ITU-656 mode, Input Mode, Active Field Only......

CALL BF533_EZ_KIT_PPI_Config;


Example code that sets up dma

Config_DMA_Input: device:

//Target address of the DMA

r0.h = 0x0; r0.l = 0x0;

P0.L = lo(DMA0_START_ADDR);

P0.H = hi(DMA0_START_ADDR);

[P0] = R0;

//DMA0_Y_COUNT

R0.L = 0x020D;

P0.L = lo(DMA0_Y_COUNT);

P0.H = hi(DMA0_Y_COUNT);

W[P0] = R0.L;

//DMA0_Y_MODIFY

R0.L = 0x0001;

P0.L = lo(DMA0_Y_MODIFY);

P0.H = hi(DMA0_Y_MODIFY);

W[P0] = R0.L;

//PPI Peripheral is used

r0 = 0x0000(z);

P0.L = lo(DMA0_PERIPHERAL_MAP);

P0.H = hi(DMA0_PERIPHERAL_MAP);

W[P0] = R0.L;

//DMA Config: Enable DMA | Memory write DMA | Discard DMA FIFO before start | enable assertation of interrupt | | Enable STOP DMA

P0.L = lo(DMA0_CONFIG);

P0.H = hi(DMA0_CONFIG);

r0 = DMAEN | WNR | RESTART | DI_EN(z);

W[P0] = R0.L;

Example code that sets-up DMA


Interrupt service routine
Interrupt service routine device:

//clear DMA interrupt

P0.L = lo(DMA0_IRQ_STATUS);

P0.H = hi(DMA0_IRQ_STATUS);

R0.L = W[P0];

BITSET(R0,0);

W[P0] = R0.L;


Tackled today
Tackled today device:

  • The basic computer

  • Improvements made to the basic computer

    • Interrupt handler

    • DMA

  • DMA Controller in BF533

  • Example code that demonstrates setting up the DMA

  • Importance of DMA transfers in DSP algorithms
