NAT (1/9)
  • Network Address Translation
  • Convert IP Address and port between private and public realm
  • Works on network layer and transport layer
nat 2 9
NAT (2/9)

NAT

A

B

192.168.0.10

163.13.128.5

140.112.30.8

nat 3 9
NAT (3/9)

NAT

A

B

Port:1234

192.168.0.10

163.13.128.5

140.112.30.8

nat 4 9
NAT (4/9)

NAT

A

B

Port:5678

Port:1234

192.168.0.10

163.13.128.5

140.112.30.8

nat 5 9
NAT (5/9)

NAT

A

B

Port:5678

Port:5555

Port:1234

192.168.0.10

163.13.128.5

140.112.30.8

nat 6 9
NAT (6/9)

NAT

A

B

192.168.0.10

163.13.128.5

140.112.30.8

nat 7 9
NAT (7/9)

NAT

A

B

Port:5678

Port:5555

192.168.0.10

163.13.128.5

140.112.30.8

nat 8 9
NAT (8/9)

NAT

A

B

Port:5678

Port:5555

192.168.0.10

163.13.128.5

140.112.30.8

nat 9 9
NAT (9/9)

NAT

A

B

Port:5678

Port:5555

Port:1234

192.168.0.10

163.13.128.5

140.112.30.8

types of nat
Types of NAT
  • Full Cone NAT
  • Restricted Cone NAT
  • Port-Restricted Cone NAT
  • Symmetric NAT
binding life time of nat 1 4
Binding Life Time of NAT (1/4)
  • When a client sends a UDP packet to public Internet, NAT will allocate a public port for the private address and port
  • If no UDP traffic on the public port for a period, NAT will release the public port
  • The period is “binding life time”
binding life time of nat 2 4
Binding Life Time of NAT (2/4)

Client use privet port to send a UDP packet to public server

NAT

Client

Server

Port:1234

192.168.0.10

163.13.120.90

140.112.30.80

binding life time of nat 3 4
Binding Life Time of NAT (3/4)

NAT will allocate a public port for 192.168.0.10:1234

NAT

Client

Server

Port:1234

Port:5555

192.168.0.10

163.13.120.90

140.112.30.80

binding life time of nat 4 4
Binding Life Time of NAT (4/4)

If no UDP traffic on the public port for a period, NAT will release the public port

NAT

Client

Server

Port:1234

Port:5555

192.168.0.10

163.13.120.90

140.112.30.80

homework 31
Homework 3
  • 了解前述四種類型NAT之運作方式與差異
  • 設計測試NAT類型與Binding Life Time的方法並實作
slide17
測試環境-R219

PC

Internet

PC

Full Cone NAT

Public IP

PC

PC

Public IP

Public IP

Port-Restricted Cone NAT

Restricted Cone NAT

Private IP

PC

PC

PC

PC

PC

PC

PC

PC

slide19
評分標準
  • 書面報告 (共25%)
    • 解釋四種類型NAT的運作方式
    • 測試方法與架構 (須寫出詳細流程)
    • 流程圖
  • 程式&Demo (共65%)
    • 是否位於NAT下 (5%)
    • Binding Life Time (10%)
    • Full Cone NAT (15%)
    • Restricted Cone NAT (15%)
    • Port Restricted Cone NAT (15%)
    • Symmetric NAT (5%)
slide20
注意事項 (1/2)
  • 本次作業所有測試均是針對UDP
  • 本次作業兩個人一組
  • 書面報告字數需1500字以上
  • 書面報告須寫上中文姓名與學號,未寫者各扣2分
  • 書面報告電子檔請繳交.doc或.pdf檔
  • Binding Life Time的誤差必須在10秒以內
  • 可以使用任何程式語言
slide21
注意事項 (2/2)
  • Demo時當場以截止繳交日期前寄出的source code編譯執行檔
  • 執行環境以R219電腦中可提供的為主,如使用特殊的Compiler,請自行準備執行環境
  • 作業驗收標準以可在R219之電腦執行為準,若Demo時程式無法於 R219之電腦執行,則視同作業未完成
  • 作業請勿抄襲
  • Demo 時請攜帶書面報告紙本,並於封面註明中文姓名與學號
  • 每組 Demo 時間為15分鐘,必須於時間內完成四種NAT與Binding Life Time的測試,逾時未測試完畢的部份不予計分
  • Demo時所使用的NAT, Binding Life Time均小於5分鐘
  • 作業三最高分90分 (Term-Project才有可能得到高於90分)
slide22
繳交日期
  • 95年6月24日 24:00 前
  • 於截止時間前將Source Code與書面報告寄至[email protected]
  • Demo地點 : R219
  • Demo時段 : 6/29 , 6/30
  • 請於Demo前一週至R442門口填表預約時段
  • 繳交格式
    • Source Code檔名 : 學號1_學號2.副檔名
    • 書面報告檔名 : hw3_學號1_中文姓名1_學號2_中文姓名2.副檔名
    • 信件標題格式 : hw3_學號1_中文姓名1_學號2_中文姓名2
    • 未依上述格式繳交者各扣2分
